AddOn ADD-GMC-MX-SC Gigabit Media Converter - 10/100/1000Base-TX (RJ-45) to 1000Base-MX (SC) MMF 1310nm 2km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The converter features two ports: one 10/100/1000Base-TX RJ-45 port for copper connectivity and one SC port for multimode fiber. It supports both optical fiber and twisted pair media, with compatibility for multi-mode fiber optic cables. The device leverages 1000Base-SX technology for fiber transmission, ensuring stable Gigabit Ethernet performance.
Power is supplied via an external power adapter, providing flexible installation options. The converter is built with environmentally friendly materials and complies with Restriction of Hazardous Substances (RoHS) standards. It includes a 3-year limited warranty for added reliability.
Relevant factors for this section include Total Number of Ports, Network (RJ-45), DVI, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This media converter simplifies network expansion by seamlessly integrating copper and fiber segments. Its plug-and-play design requires no configuration, reducing deployment time and complexity. The compact form factor allows for discreet placement on desktops, in racks, or alongside networking equipment.
Extended Reach
Supports distances up to 2 km over multimode fiber, eliminating the limitations of copper cabling for long-range connections.
- Ideal for campus networks
- Reduces signal degradation
High-Speed Conversion
Delivers full Gigabit Ethernet performance, ensuring no bottleneck in data transfer between copper and fiber networks.
- 10/100/1000Base-T auto-negotiation
- Low-latency operation
Deployment / Use Cases
The ADD-GMC-MX-SC is suited for environments where fiber optic cabling is used to extend network reach beyond the limits of traditional copper Ethernet. It enables connectivity between switches, routers, or servers located in separate buildings or across large facilities.
Common applications include connecting network segments in office complexes, educational campuses, healthcare facilities, and industrial sites. It can also be used in data centers to link equipment over fiber for improved noise immunity and security.
Building-to-Building Links
Connect networks across different structures using existing fiber infrastructure, maintaining high-speed data transfer over long distances.
Network Upgrades
Integrate fiber optic backbones into legacy copper networks without replacing entire cabling systems, providing a cost-effective upgrade path.
Physical Profile
The media converter has a compact design with dimensions of 4.10" (104.14 mm) wide, 3.80" (96.52 mm) deep, and 1" (25.40 mm) high. It weighs approximately 9.55 oz (270.74 g), making it lightweight and easy to mount or place in tight spaces. The small footprint minimizes desk or rack space usage, while the durable construction ensures reliable operation in standard office or industrial environments.
- Width
- 4.10" (104.14 mm)
- Depth
- 3.80" (96.52 mm)
- Height
- 1" (25.40 mm)
- Weight
- 9.55 oz (270.74 g)
- Length
- 1310 nm
Highlights
- Converts 10/100/1000Base-TX RJ-45 to 1000Base-MX SC multimode fiber
- Supports Gigabit Ethernet speeds up to 1000 Mbps
- Operates at 1310 nm wavelength with 2 km distance support
- Features 1 x RJ-45 port and 1 x SC port for flexible connectivity
- Plug-and-play design with no configuration required
- Compact form factor for easy desktop or rack placement
- Powered by external power adapter for simple installation
- RoHS compliant and environmentally friendly
- Includes a 3-year limited warranty
- Ideal for extending network reach in office or campus settings
Specifications
| Specifications | |
|---|---|
| Manufacturer | AddOn |
| Manufacturer Part Number | ADD-GMC-MX-SC |
| Brand Name | AddOn |
| Product Name | 10/100/1000Base-TX(RJ-45) to 1000Base-MX(SC) MMF 1310nm 2km Media Converter |
| Packaged Quantity | 1 |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| DVI | No |
| USB | No |
| Management Port | No |
| Number of Network (RJ-45) Ports | 1 |
| Number of SC Ports | 1 |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Wavelength | 1310 nm |
| Maximum Distance Supported | 2 km (1.24 Mile) |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-SX |
| Power Description | |
| Power Source | Power Adapter |
| Physical Characteristics | |
| Height | 1" (25.40 mm) |
| Width | 4.10" (104.14 mm) |
| Depth | 3.80" (96.52 mm) |
| Weight (Approximate) | 9.55 oz (270.74 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| TAA Compliant | No |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What does this media converter do?
This media converter bridges copper and fiber optic networks by converting 10/100/1000Base-TX Ethernet signals from an RJ-45 port to 1000Base-MX signals over multimode fiber via an SC connector. It enables data transmission over distances up to 2 km, extending network reach beyond typical copper limitations while maintaining Gigabit Ethernet speeds.
What types of fiber does it support?
The converter supports multi-mode fiber optic cables with an SC connector. It operates at a 1310 nm wavelength and is compatible with standard multimode fiber used in many enterprise and campus networks. It does not support single-mode fiber, so ensure your infrastructure uses multimode fiber for proper compatibility.
What is the maximum distance supported?
The media converter supports a maximum distance of 2 km (approximately 1.24 miles) over multimode fiber. This extended reach makes it suitable for connecting network segments across buildings or large facilities, reducing the need for additional networking equipment and minimizing signal degradation over long runs.
How is the converter powered?
The converter is powered by an external power adapter included with the unit. This provides flexible installation options, allowing placement away from power outlets if needed. The power adapter ensures stable operation without drawing power from the network ports, maintaining reliable performance in various deployment scenarios.
Does it require any configuration?
No, this media converter features a plug-and-play design with no configuration required. Simply connect the RJ-45 port to your copper network and the SC port to your multimode fiber cable, then power it on. It auto-negotiates speeds and settings, making deployment quick and straightforward for IT professionals or network installers.
What warranty is included?
The converter includes a 3-year limited warranty from AddOn, covering defects in materials and workmanship. This warranty provides added confidence in the product's reliability for business and industrial use, ensuring support over an extended period in line with typical network hardware lifecycle expectations.
