Altronix NETWAYSP8X Ethernet Switch - 8 Ports - 115W PoE Budget - 2 SFP Uplinks - Layer 2 Managed
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The NetWaySP8X supports a mixed port configuration: six 10/100 Mbps RJ-45 ports and two 10/100/1000 Mbps RJ-45 ports, all capable of delivering PoE+ power up to 30W per port or Hi-PoE up to 60W on two ports. This flexibility allows it to power high-demand devices while maintaining data throughput. The 125 MB/s maximum data transfer rate ensures efficient handling of network traffic across all ports.
Network management features include IEEE 802.1Q VLAN for creating virtual LANs, which isolates broadcast domains and enhances security. The switch is compliant with IEEE 802.3at and IEEE 802.3af PoE standards, and includes PoE activity LED indicators for real-time monitoring. Its Layer 2 switching capabilities provide basic traffic management without the complexity of higher-layer protocols.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This switch stands out for its high PoE budget and uplink readiness, making it ideal for expanding network infrastructure with power-hungry devices. The 115W total PoE budget supports up to eight PoE+ devices or two Hi-PoE devices simultaneously, reducing the need for additional power injectors. The inclusion of two SFP slots allows for fiber or long-distance copper uplinks, future-proofing your network for growth.
Robust PoE Delivery
Delivers PoE+ (30W) on all eight ports or Hi-PoE (60W) on two ports, accommodating devices like PTZ cameras and high-performance access points without external power.
- 115W total budget
- IEEE 802.3at/af compliant
- Hi-PoE support up to 60W
Uplink Flexibility
Two Gigabit SFP slots enable fiber or copper uplinks, providing options for high-bandwidth backbone connections or extending network reach beyond copper limitations.
- Fiber or copper SFP modules
- Gigabit speed
- Scalable connectivity
Enhanced Network Management
Layer 2 switching with IEEE 802.1Q VLAN support allows for network segmentation, improving traffic flow and security in multi-device environments.
- VLAN for traffic isolation
- Basic QoS capabilities
- PoE activity LEDs
Deployment / Use Cases
The Altronix NetWaySP8X is designed for small to medium business networks, surveillance systems, and VoIP deployments where PoE power and uplink flexibility are critical. Its 115W PoE budget makes it suitable for powering multiple IP cameras, wireless access points, and IP phones in a single rack unit, simplifying cabling and reducing power clutter.
In retail or office settings, the switch can segment traffic between departments or user groups using VLANs, enhancing network performance and security. The SFP uplinks allow connection to a central server or another switch via fiber for reduced interference over long distances. Its automatic battery backup switchover ensures continuous operation during power fluctuations, ideal for security and communication systems.
Physical Profile
The switch features a compact gray enclosure constructed from metal and plastic, measuring 13.50 inches in height, 13 inches in width, and 3.25 inches in depth. This 1U rack-mountable design fits standard server racks, with a weight of 6.66 pounds making it easy to install and integrate into existing infrastructure. The durable build ensures reliable operation in controlled environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 13.50" (342.90 mm), 13" (330.20 mm), 3.25" (82.55 mm), 6.66 lb (3020 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 13" (330.20 mm)
- Depth
- 3.25" (82.55 mm)
- Height
- 13.50" (342.90 mm)
- Weight
- 6.66 lb (3020 g)
Highlights
- 8 total network ports with PoE/PoE+ support
- 115W total PoE budget for high-power devices
- 2 Gigabit SFP slots for fiber or copper uplinks
- Layer 2 managed with IEEE 802.1Q VLAN support
- Supports Hi-PoE up to 60W on two ports
- Dual voltage input (120V/230V AC)
- Automatic switchover to battery backup on AC failure
- PoE activity LED indicators for monitoring
- UL listed in the U.S. and Canada, CE certified
- Lifetime warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Altronix Corporation |
| Manufacturer Part Number | NETWAYSP8X |
| Brand Name | Altronix |
| Product Model | NetWaySP8X |
| Product Name | NetWaySP8X Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 6 x Fast Ethernet PoE+ RJ-45 Network Port,2 x 10/100/1000BASE-T Gigabit Ethernet PoE+ RJ-45 Network Port,2 x Gigabit Ethernet SFP Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet,Fast Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X,10/100Base-T |
| Maximum Data Transfer Rate | 125 MB/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3at,IEEE 802.3af,IEEE 802.1Q |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 115 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | PoE+,PoE,AC,Power Supply |
| Physical Characteristics | |
| Product Color | Gray |
| Product Material | Metal,Plastic |
| Height | 13.50" (342.90 mm) |
| Width | 13" (330.20 mm) |
| Depth | 3.25" (82.55 mm) |
| Weight (Approximate) | 6.66 lb (3020 g) |
| Miscellaneous | |
| Country of Origin | United States |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the total PoE budget of the Altronix NetWaySP8X switch?
The Altronix NetWaySP8X has a total PoE budget of 115 watts. This budget supports Power over Ethernet delivery across all eight ports, allowing for simultaneous powering of devices like IP cameras, wireless access points, and VoIP phones. It can allocate up to 30W per port for PoE+ or up to 60W for Hi-PoE on two ports, providing flexibility for high-power applications.
How many SFP uplink ports does this switch have?
This switch includes two Gigabit Ethernet SFP expansion slots. These slots allow for the use of SFP modules to connect via fiber optic or copper cables, enabling high-speed uplinks to core network switches or routers. The SFP ports support Gigabit speeds, providing scalable bandwidth options for network expansion and long-distance connections.
What types of Ethernet ports are available on the NetWaySP8X?
The NetWaySP8X features eight RJ-45 network ports: six are Fast Ethernet (10/100 Mbps) PoE+ ports, and two are Gigabit Ethernet (10/100/1000 Mbps) PoE+ ports. All ports support Power over Ethernet, with the Fast Ethernet ports ideal for standard devices and the Gigabit ports offering higher throughput for bandwidth-intensive applications.
Does this switch support VLAN for network segmentation?
Yes, the Altronix NetWaySP8X supports VLAN (Virtual Local Area Network) through IEEE 802.1Q networking standards. This Layer 2 feature allows you to create subnetworks by grouping devices, which improves network traffic management and enhances security by isolating broadcast domains. It is suitable for segmenting departments or device types in business environments.
What input voltage does the switch require?
The switch accepts dual input voltages of 120 V AC and 230 V AC, making it compatible with standard power sources in North America and many international regions. This flexibility allows for deployment in various locations without requiring voltage converters. The power source includes PoE+, PoE, AC, and power supply options, with automatic switchover to a standby battery if AC power fails.
What is the warranty coverage for the Altronix NetWaySP8X?
The Altronix NetWaySP8X comes with a lifetime limited warranty. This warranty covers defects in materials and workmanship for the product's lifetime, providing long-term reliability and support. It is backed by Altronix Corporation, with the switch being manufactured in the United States and certified UL in the U.S. and Canada, as well as CE for European markets.
