APC by Schneider Electric BE650G1 APC Back-UPS 650VA Tower UPS - 390W - 120V - 8 Outlets - 4 Battery+Surge - 3-Minute Full Load Runtime - 1-Day
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The APC Back-UPS 650VA (BE650G1) is a tower-form uninterruptible power supply engineered to protect desktop computers, networking equipment, and critical electronics from power disturbances. With 650 VA/390 W capacity, this standby UPS provides reliable battery backup during outages while delivering comprehensive surge protection for connected devices. The unit features eight NEMA 5-15R outlets—four with combined battery backup and surge protection plus four with surge-only protection—offering flexible power distribution for both essential and peripheral equipment.
Designed for single-phase 120V electrical systems, this compact tower UPS fits easily under desks or in tight spaces where rack mounting isn't required. The included USB connectivity enables basic power management through compatible software, while front-panel indicators and audible alarms provide clear status updates. With Energy Star certification and RoHS compliance, this unit combines practical protection with environmentally responsible manufacturing standards suitable for home offices, small business workstations, and network infrastructure deployments.
Technical Overview
Engineered for reliable power protection, the Back-UPS 650VA delivers stepped approximated sine wave output at 120V, compatible with most desktop electronics and network equipment. The unit provides 3 minutes of runtime at full 390W load and extends to 12 minutes at half load, offering adequate time for graceful shutdowns during power interruptions. Battery management features include hot-swappable capability for maintenance without downtime and a typical 1-day recharge cycle, supported by a maintenance-free, sealed lead-acid battery that's spill-proof and designed for consistent performance.
Electrical specifications include 12A input current, 340 joule surge energy rating, and RJ-45 data line protection that safeguards network equipment from surges traveling through Ethernet connections. The 5-foot (1.52 m) power cord provides flexible placement options, while the compact tower enclosure measures 3.46" H × 7.09" W × 11.89" D (88 × 180 × 302 mm) with a weight of approximately 13.67 lb (6.2 kg). This combination of technical features makes the unit suitable for protecting typical desktop configurations including computers, monitors, and basic peripherals in various deployment environments.
Key Product Advantages
The compact tower form factor makes this UPS suitable for space-constrained environments while providing substantial protection capacity. Energy Star certification confirms efficient operation, and RoHS compliance ensures environmentally responsible manufacturing.
Comprehensive Protection
Combines battery backup for outages with surge protection for all connected devices, plus RJ-45 data line protection to safeguard network equipment from power surges traveling through Ethernet cables.
- 8 total outlets with flexible configuration
- 340 joule surge energy rating
- Data line protection for network safety
User-Friendly Operation
Designed for straightforward setup and monitoring with clear status indicators and basic USB connectivity for power management software compatibility.
- LED status display
- Audible alarm notifications
- USB connectivity for basic monitoring
Deployment / Use Cases
This 650VA UPS serves as reliable protection for home offices, small business workstations, point-of-sale systems, and network infrastructure where brief runtime is sufficient for graceful shutdowns. The tower format works well under desks or in equipment closets where rack mounting isn't required.
With 390W capacity, it can support typical desktop configurations including the computer, monitor, and basic peripherals. The surge-only outlets allow you to protect additional non-critical devices without consuming battery capacity.
Desktop Computer Protection
Ideal for protecting individual workstations, providing enough runtime to save documents and shut down properly during power interruptions while protecting peripherals from surges.
Network Equipment Backup
Suitable for small network setups including routers, switches, and modems, with data line protection to prevent surge damage through Ethernet connections.
Physical Profile
The black tower enclosure measures 3.46" H × 7.09" W × 11.89" D (88 × 180 × 302 mm) and weighs approximately 13.67 lb (6.2 kg). This compact footprint fits easily in standard desktop environments while providing substantial protection capacity. The included 5-foot (1.52 m) power cord offers flexible placement options relative to wall outlets.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 3.46" (88 mm), 7.09" (180 mm), 11.89" (302 mm), 13.67 lb (6200.61 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 7.09" (180 mm)
- Depth
- 11.89" (302 mm)
- Height
- 3.46" (88 mm)
- Weight
- 13.67 lb (6200.61 g)
- Length
- 5 ft (1.52 m)
What's in the Box
The package includes everything needed for immediate deployment: the Back-UPS 650VA desktop UPS unit, USB cable for connectivity, and user manual with setup instructions and safety information.
Highlights
- 650 VA / 390 W power capacity for desktop and network equipment
- 8 total outlets: 4 with battery backup + surge, 4 with surge-only protection
- 3-minute runtime at full load, 12 minutes at half load
- 120V input and output with stepped approximated sine wave
- Hot-swappable, maintenance-free lead-acid battery
- USB connectivity for basic power management
- RJ-45 data line protection for network equipment
- Compact tower form factor fits under desks or in tight spaces
- Energy Star certified for energy efficiency
- 3-year warranty with 1-year battery coverage
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | BE650G1 |
| Brand Name | APC by Schneider Electric |
| Product Line | Back-UPS |
| Product Name | Back-UPS 650 VA Desktop UPS |
| Packaged Quantity | 1 Each |
| Product Type | Standby UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15P |
| Receptacle Detail | 4 x NEMA 5-15R,4 x NEMA 5-15R Surge |
| Number of Battery & Surge Outlets | 8 |
| Dataline Protection | RJ-45 |
| Cord Length | 5 ft (1.52 m) |
| Phase | Single Phase |
| Power Description | |
| Load Capacity (VA) | 650 VA |
| Load Capacity (Watt) | 390 W |
| Input Voltage | 120 V |
| Input Current | 12 A |
| Output Voltage | 120 V AC |
| Waveform Type | Stepped Approximated Sine Wave |
| Surge Energy Rating | 340 J |
| Interfaces/Ports | |
| USB | Yes |
| Battery Information | |
| Battery Characteristics | Maintenance-free, Sealed, Spill-proof |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3 Minute |
| Backup/Run Time (Half Load) | 12 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 1 Day |
| Physical Characteristics | |
| Product Color | Black |
| Height | 3.46" (88 mm) |
| Width | 7.09" (180 mm) |
| Depth | 11.89" (302 mm) |
| Form Factor | Tower |
| Weight (Approximate) | 13.67 lb (6200.61 g) |
| Miscellaneous | |
| Package Contents | Back-UPS 650 VA Desktop UPS USB cable User manual |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | UPS: 36 month(s)|Battery: 12 month(s) |
User Manual
FAQ
What is the power capacity of this APC Back-UPS unit?
This UPS provides 650 VA / 390 W power capacity, suitable for protecting desktop computers, monitors, and basic networking equipment from power interruptions and surges.
How long will this UPS run on battery during a power outage?
At full 390W load, the unit provides 3 minutes of runtime for graceful shutdowns. At half load (195W), runtime extends to 12 minutes, offering flexibility for different equipment configurations.
How many devices can I connect to this UPS?
The unit features 8 NEMA 5-15R outlets: 4 with combined battery backup and surge protection for critical equipment, plus 4 with surge-only protection for additional peripherals without consuming battery capacity.
What voltage does this UPS support for input and output?
Designed for standard North American electrical systems, this UPS operates at 120V input and delivers 120V AC output with stepped approximated sine wave compatibility for most desktop electronics and networking gear.
Is this UPS designed for rack mounting or desktop use?
This unit features a tower form factor optimized for desktop deployment under desks or in equipment closets where rack mounting isn't required, with compact dimensions of 3.46" H × 7.09" W × 11.89" D.
What management and connectivity options are available?
The UPS includes USB connectivity for basic power management software compatibility, RJ-45 data line protection to safeguard network equipment from surges traveling through Ethernet cables, and front-panel LED indicators with audible alarms for clear status monitoring.
