APC by Schneider Electric SMT3000RMI2UNC Smart-UPS 3000VA LCD RM 2U Rack-mountable UPS with Network Card - 3 kVA / 2. 70 kW - 230V - 12 Outlets
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Smart-UPS model operates as a line-interactive UPS, providing voltage regulation and battery backup during power disturbances. The 4 ms transfer time ensures minimal interruption to connected loads, while the sine wave output maintains power quality for servers, networking gear, and storage systems. The unit includes a temperature probe for environmental monitoring, helping to protect battery life and overall system reliability.
The Web/SNMP management card supports remote configuration, alerts, and shutdown commands via network protocols. Local connectivity options include USB and RS-232 interfaces for direct management from a connected computer. The UPS is environmentally friendly and backed by a three-year limited warranty from APC by Schneider Electric.
This section brings together practical product details such as Number of Battery & Surge Outlets, Transfer Time, Load Capacity (VA), Load Capacity (Watt), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Smart-UPS 3000VA LCD RM combines high-capacity power protection with advanced management features in a compact rack-mountable design. The integrated network card eliminates the need for separate management hardware, reducing complexity and cost in networked environments.
High-Efficiency Operation
Engineered for lower energy costs, this UPS optimizes power usage while delivering reliable backup performance. The line-interactive design reduces wear on the battery during normal operation, extending service life.
- Reduces energy consumption
- Extends battery lifespan
Comprehensive Management
Local LCD display and remote network management provide complete visibility and control over power conditions. The included software and documentation support easy deployment and ongoing monitoring.
- Real-time status display
- Remote IP management
- Temperature probe included
Deployment / Use Cases
This UPS is ideal for protecting critical infrastructure in business and industrial settings where rack space is at a premium. The 3 kVA capacity supports multiple servers, switches, and storage devices, making it suitable for small to medium server rooms or network distribution points.
Common deployment scenarios include securing VoIP systems, network switches, and surveillance equipment in telecommunications closets. The 230V output aligns with European and other international power standards, while the rack-mount design integrates seamlessly with standard 19-inch server racks. The UPS can also serve as a centralized power backup solution for distributed IT equipment in office environments.
Server Room Protection
Provides backup power for rack-mounted servers, storage arrays, and network switches during outages, ensuring business continuity.
- Supports multiple devices
- 2U rack footprint
Network Infrastructure
Protects core networking equipment such as routers, switches, and firewalls, maintaining network availability during power disturbances.
- 12 outlets for connectivity gear
- Network management capabilities
Physical Profile
The UPS features a black enclosure with dimensions of 3.39 inches in height, 18.90 inches in width, and 26.89 inches in depth, occupying 2U of vertical rack space. The rack mounting support rails included in the package facilitate secure installation in standard server racks. The approximate weight of 97.42 pounds reflects the robust construction and internal battery capacity, ensuring stability when mounted.
- Width
- 18.90" (480 mm)
- Depth
- 26.89" (683 mm)
- Height
- 3.39" (86 mm)
- Weight
- 97.42 lb (44190 g)
What's in the Box
The package includes all necessary components for immediate deployment and management of the UPS system.
Highlights
- 3 kVA / 2.70 kW load capacity for reliable backup power
- 2U rack-mountable form factor saves space in server racks
- 12 battery and surge-protected outlets support multiple devices
- Integrated network management card enables remote monitoring
- Pure sine wave output ensures compatibility with sensitive electronics
- Lead-acid battery with 3-hour typical recharge time
- LCD display provides real-time status and diagnostics
- 230V AC output voltage for international power standards
- Includes temperature probe for environmental monitoring
- 3-year limited warranty from APC by Schneider Electric
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SMT3000RMI2UNC |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Name | Smart-UPS 3000VA LCD RM 2U 230V with Network Card |
| Product Type | Line-interactive UPS |
| Technical Information | |
| Number of Battery & Surge Outlets | 12 |
| Transfer Time | 4 ms |
| Power Description | |
| Load Capacity (VA) | 3 kVA |
| Load Capacity (Watt) | 2.70 kW |
| Output Voltage | 230 V AC |
| Waveform Type | Sine Wave |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Typical Battery Recharge Time | 3 Hour |
| Physical Characteristics | |
| Product Color | Black |
| Height | 3.39" (86 mm) |
| Width | 18.90" (480 mm) |
| Depth | 26.89" (683 mm) |
| Rack Height | 2U |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 97.42 lb (44190 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS 3000VA LCD RM 2U 230V with Network Card CD with software Country-specific detachable power cord Documentation CD Installation guide Rack mounting support rails Smart UPS signalling RS-232 cable Temperature probe USB cable Web/SNMP management card |
| Environmentally Friendly | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this UPS?
This APC Smart-UPS delivers 3 kVA (3000 VA) and 2.70 kW of backup power capacity. It supports connected loads up to this rating, making it suitable for protecting multiple servers, network switches, or storage devices in a rack environment.
How many devices can I connect to this UPS?
The UPS includes 12 battery and surge-protected outlets, allowing you to connect up to 12 devices directly. This outlet count supports typical server room configurations with servers, networking equipment, and auxiliary devices.
Is this UPS rack-mountable?
Yes, this UPS is designed for rack-mount installation with a 2U form factor. It includes rack mounting support rails for secure attachment in standard 19-inch server racks, optimizing space in data centers and network closets.
What type of output waveform does this UPS provide?
The UPS delivers a pure sine wave output, which is essential for compatibility with sensitive electronic equipment like servers, networking gear, and medical devices. Sine wave power reduces the risk of damage or malfunction compared to simulated sine wave outputs.
How long does the battery take to recharge?
The lead-acid battery typically recharges within three hours after a complete discharge. This recharge time ensures the UPS is ready for subsequent power outages, maintaining reliability in environments with frequent power disturbances.
What management features are included?
The UPS includes an LCD for local status monitoring, plus a Web/SNMP management card for remote control over IP networks. It also supports USB and RS-232 connectivity for direct management, and includes a temperature probe for environmental monitoring to protect battery health.
What power capacity is listed for this UPS?
The listed power specification is 3 kVA, which helps position the unit for the right load level and installation role.
How many outlets are available?
The product includes 12, which helps buyers understand how many connected devices it can support in its intended deployment.
