APC by Schneider Electric SRTL2K2RM1UNC APC Smart-UPS Ultra 2200VA Lithium-ion Dual Conversion Online UPS - 1U Rack/Tower Mount - 120V - 6 Outlets
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The APC Smart-UPS Ultra 2200VA Lithium-ion Dual Conversion Online UPS delivers enterprise-grade power protection for critical IT infrastructure, network equipment, and industrial applications. This 1U rack-mountable unit provides 2200VA/2200W of pure sine wave output with advanced battery technology that eliminates routine battery replacements.
Engineered for Schneider Electric's EcoStruxure Ready platform, the UPS supports remote monitoring and management through its included network card. The lithium-ion battery chemistry offers three times the lifespan of traditional VRLA batteries while maintaining consistent performance across a wide operating temperature range.
With six NEMA outlets (five 5-20R and one L5-20R), this UPS accommodates diverse equipment configurations. The 1U form factor optimizes rack space while supporting five mounting options: rack, tower, wall, ceiling, or desktop installation. Extended support rails ensure secure mounting in standard 19-inch racks.
Technical Overview
This dual conversion online UPS provides complete isolation between input and output power, ensuring clean, regulated electricity regardless of utility power quality. The 2.20 kVA/2.20 kW capacity supports substantial server loads, network switches, and industrial equipment while maintaining sine wave output for sensitive electronics.
The 50V lithium-ion battery system delivers 1123.2 kJ of energy storage with rapid 1.5-hour recharge capability. Runtime specifications include 6.05 minutes at full load and 12.65 minutes at half load, providing sufficient time for graceful shutdowns or generator transfer. Input and output voltages operate at 120/125 V AC with 60 Hz frequency synchronization.
Management features include an LCD display for local status monitoring, USB and RJ-45 connectivity for software integration, and an EPO (Emergency Power Off) port for safety compliance. The network card enables SNMP, HTTP, and HTTPS management with one year of secure subscription included.
Key Product Advantages
Lithium-ion Battery Technology
The lithium-ion battery lasts three times longer than traditional VRLA batteries, eliminating routine battery replacements during the UPS lifespan while maintaining consistent performance across temperature variations.
- 3× lifespan vs VRLA batteries
- No scheduled battery replacements
- Wide operating temperature tolerance
Flexible Deployment Options
Five mounting styles provide installation versatility for any environment: rack, tower, wall, ceiling, or desktop configurations. The 1U height maximizes rack density while extended rails ensure secure mounting.
- 1U rack-optimized design
- Five mounting configurations
- Extended support rails included
Advanced Management Capabilities
EcoStruxure Ready integration enables remote monitoring and management through the included network card. Local interfaces include LCD display, USB connectivity, and alarm notifications.
- EcoStruxure Ready platform
- Network card with 1-year subscription
- LCD display with status indicators
Deployment / Use Cases
The Smart-UPS Ultra 2200VA serves as primary power protection for voice/data network equipment, medical laboratory instruments, light industrial applications, retail point-of-sale systems, and server infrastructure. Its dual conversion topology makes it ideal for environments with unstable utility power or sensitive electronic equipment.
In data center applications, the 1U form factor allows dense deployment in server racks while providing runtime for graceful shutdowns or transfer to backup generators. The six-outlet configuration supports mixed equipment loads, with the L5-20R outlet accommodating higher-amperage devices.
For industrial settings, the UPS operates reliably at elevations up to 10,000 feet and temperatures up to 104°F (40°C). The lithium-ion battery maintains performance across storage temperatures from -15°C to 45°C, making it suitable for challenging environmental conditions.
Physical Profile
The silver gray enclosure measures 1.69 inches high, 17.01 inches wide, and 22.05 inches deep, occupying a single rack unit (1U) with standard 19-inch mounting compatibility. At 35.05 pounds, the unit provides substantial power capacity in a compact footprint.
Extended support rails facilitate secure installation in server racks, while the versatile form factor supports tower, wall, ceiling, or desktop mounting where rack space is unavailable. The 7.9-foot detachable power cord provides installation flexibility, and RoHS compliance ensures environmentally responsible manufacturing.
- Width
- 17.01" (432 mm)
- Depth
- 22.05" (560 mm)
- Height
- 1.69" (43 mm)
- Weight
- 35.05 lb (15898.41 g)
- Length
- 7.9 ft (2.40 m)
What's in the Box
The package includes all necessary components for immediate deployment: the Smart-UPS Ultra 2200VA UPS unit, RJ45 cable for network connectivity, USB cable for local management, country-specific detachable power cord, rack mounting brackets, extended rack mounting support rails, installation guide, and warranty card.
Highlights
- 2200VA/2200W dual conversion online UPS with pure sine wave output
- Lithium-ion battery lasts 3× longer than VRLA with no scheduled replacements
- 1U rack/tower/wall/ceiling/desktop mountable with extended support rails
- Six NEMA outlets: five 5-20R and one L5-20R for diverse equipment
- Network card included with 1-year secure subscription for remote management
- EcoStruxure Ready for integration with Schneider Electric monitoring platforms
- 5-year warranty covering both UPS unit and internal batteries
- LCD display with status indicators and alarm notifications
- USB, RJ-45, and EPO ports for comprehensive connectivity
- RoHS compliant with environmentally responsible manufacturing
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SRTL2K2RM1UNC |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS Ultra |
| Product Name | Smart-UPS Ultra Rack/Tower/Wall/Ceiling/Desktop Mountable 2200VA UPS |
| Packaged Quantity | 1 |
| Product Type | Dual Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type | NEMA 5-20P |
| Receptacle Detail | 1 x NEMA L5-20R,5 x NEMA 5-20R |
| Cord Length | 7.9 ft (2.40 m) |
| Phase | Single Phase |
| Application/Usage | Voice/Data Network,Medical Laboratory,Light Industrial Application,Retail,Server |
| Power Description | |
| Load Capacity (VA) | 2.20 kVA |
| Load Capacity (Watt) | 2.20 kW |
| Input Voltage | 120 V AC,125 V AC |
| Output Voltage | 120 V AC,125 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Sine Wave |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | Network Card |
| Alarm | Yes |
| Interfaces/Ports | |
| USB | Yes |
| Network (RJ-45) | Yes |
| EPO Port | Yes |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Size | 50V |
| Battery Energy | 1123.2 kJ |
| Backup/Run Time (Full Load) | 6.05 Minute |
| Backup/Run Time (Half Load) | 12.65 Minute |
| Typical Battery Recharge Time | 1.50 Hour |
| Environmental Conditions | |
| Maximum Operating Elevation | 10000 ft (3048000 mm) |
| Maximum Storage Elevation | 50000 ft (15240000 mm) |
| Storage Temperature | 5°F (-15°C) - 113°F (45°C) |
| Storage Relative Humidity | 0% - 95% |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission | 55 dB |
| Physical Characteristics | |
| Product Color | Silver Gray |
| Height | 1.69" (43 mm) |
| Width | 17.01" (432 mm) |
| Depth | 22.05" (560 mm) |
| Rack Height | 1U |
| Form Factor | Rack/Tower/Wall/Ceiling/Desktop Mountable |
| Weight (Approximate) | 35.05 lb (15898.41 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS Ultra Rack/Tower/Wall/Ceiling/Desktop Mountable 2200VA UPS RJ45 Cable USB Cable Country-Specific Detachable Power Cord Rack Mounting Brackets Rack Mounting Support Rails Installation Guide Warranty Card |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the runtime of this UPS at full load?
The APC Smart-UPS Ultra 2200VA provides 6.05 minutes of runtime at full load (2200W). At half load (1100W), runtime extends to 12.65 minutes. These specifications support graceful shutdown procedures or transfer to backup power sources during utility outages.
How does the lithium-ion battery compare to traditional UPS batteries?
The lithium-ion battery lasts approximately three times longer than traditional VRLA (Valve Regulated Lead Acid) batteries. This eliminates scheduled battery replacements during the UPS lifespan and maintains consistent performance across a wider temperature range from -15°C to 45°C storage conditions.
What mounting options are available for this UPS?
This UPS supports five mounting configurations: standard 1U rack mount (with included extended rails), tower placement, wall mounting, ceiling installation, or desktop use. The versatile form factor accommodates diverse deployment scenarios from data centers to industrial environments.
What network management capabilities are included?
A network management card is included with a 1-year secure subscription. This enables remote monitoring and management via SNMP, HTTP, and HTTPS protocols. The UPS is also EcoStruxure Ready for integration with Schneider Electric's power management platforms.
What types of outlets does this UPS provide?
The unit features six NEMA outlets: five standard NEMA 5-20R outlets and one NEMA L5-20R twist-lock outlet. This configuration supports mixed equipment loads, with the L5-20R accommodating higher-amperage devices that require secure locking connections.
What is the warranty coverage for this UPS?
APC provides a 5-year warranty covering both the UPS unit and its internal lithium-ion batteries. This comprehensive warranty ensures long-term protection for your power infrastructure investment without separate battery replacement costs during the coverage period.
