APC by Schneider Electric SMT1000CUS Smart-UPS 1000VA/700W Line Interactive Tower UPS - 120V - 8x NEMA 5-15R Outlets - AVR - LCD - SmartConnect - TAA
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This line interactive UPS operates with a single-phase 120V AC input and delivers a stable 120V AC sine wave output at 60Hz. The automatic voltage regulation (AVR) function corrects under-voltage and over-voltage conditions without switching to battery power, extending runtime and reducing wear. The input voltage range of 110V to 125V AC accommodates typical North American power variances.
The unit includes serial, network (RJ-45), and USB (HID compliant) ports for flexible monitoring and shutdown control. The lead-acid battery provides 5 minutes of runtime at full load and 19 minutes at half load, with a typical recharge time of 3 hours. Energy Star certification confirms efficient operation, while RoHS compliance ensures environmentally responsible manufacturing.
This section brings together practical product details such as AVR, Plug/Connector Type, Receptacle Type, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The SMT1000CUS offers several distinct advantages for business power protection. Its combination of high capacity, intelligent management, and flexible deployment makes it a versatile solution for diverse IT environments.
Reliable Power Conditioning
Automatic voltage regulation maintains stable output during brownouts and overvoltage events, protecting sensitive electronics from damage and reducing unnecessary battery usage.
- Corrects utility voltage fluctuations
- Extends battery life
- Pure sine wave output
Comprehensive Monitoring
The LCD display provides immediate status information, while SmartConnect Ethernet enables cloud-based remote monitoring without additional management cards.
- Local LCD status display
- Cloud monitoring via SmartConnect
- Serial and USB connectivity
Flexible Deployment
The rack/tower design with 0U rack height allows placement in server racks or as a standalone tower, adapting to various office and data center layouts.
- Rack or tower mounting
- 0U rack height
- Compact footprint
Deployment / Use Cases
This 1000VA UPS is engineered for commercial applications where uninterrupted power is critical to operations. Its 700W capacity supports moderate loads typically found in small to medium business environments.
The unit excels in protecting network infrastructure, including switches, routers, and VoIP systems, ensuring communication continuity during power events. Retail point-of-sale systems benefit from the clean power output and surge protection, preventing transaction interruptions and hardware damage.
This section brings together practical product details such as AVR, Plug/Connector Type, Receptacle Type, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Network Closet Protection
Ideal for securing network switches, routers, and small servers in distributed network closets where space is limited but reliability is essential.
Business Desktop & POS Support
Provides backup power for critical workstations and point-of-sale systems, preventing data loss and maintaining business operations during brief outages.
Physical Profile
The black tower enclosure measures 8.62" high, 6.73" wide, and 17.28" deep, with a weight of approximately 44.31 pounds. The 0U rack height allows for flexible placement in standard server racks without consuming vertical space. The compact footprint and integrated handle facilitate installation in various environments, from server rooms to office floors.
- Width
- 6.73" (170.94 mm)
- Depth
- 17.28" (438.91 mm)
- Height
- 8.62" (218.95 mm)
- Weight
- 44.31 lb (20098.68 g)
- Length
- 8 ft (2.44 m)
What's in the Box
The package includes the PowerChute Serial Edition software for automated shutdown and management of connected systems.
Package contents include Powerchute Serial Edition. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 1000VA/700W line interactive tower UPS with pure sine wave output
- Automatic voltage regulation corrects brownouts and overvoltage without battery use
- 8 NEMA 5-15R outlets for connecting multiple devices
- LCD display provides real-time status and diagnostic information
- SmartConnect Ethernet port enables cloud-based remote monitoring
- Serial and USB ports support graceful shutdown via PowerChute software
- Rack/tower design with 0U rack height for flexible deployment
- TAA compliant for government and institutional procurement
- Energy Star certified for energy efficiency
- 3-year limited warranty for long-term protection
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SMT1000CUS |
| Brand Name | APC by Schneider Electric |
| Product Model | SMT1000CUS |
| Product Name | SMT1000CUS 1000VA Rack/Tower UPS |
| Product Type | Line-interactive UPS |
| Technical Information | |
| AVR | Yes |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15P |
| Receptacle Detail | 8 x NEMA 5-15R |
| Number of Surge-only Outlets | 0 |
| Cord Length | 8 ft (2.44 m) |
| Phase | Single Phase |
| Application/Usage | Commercial,Equipment,Network Device,Switch,Business |
| Power Description | |
| Load Capacity (VA) | 1 kVA |
| Load Capacity (Watt) | 700 W |
| Input Voltage | 120 V AC |
| Input Voltage Range | 110 V AC - 125 V AC |
| Output Voltage | 120 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Sine Wave |
| Interfaces/Ports | |
| Serial Port | Yes |
| Network (RJ-45) | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Backup/Run Time With External Battery Cabinet (Full Load) | 5 Minute |
| Backup/Run Time With External Battery Cabinet (Half Load) | 19 Minute |
| Typical Battery Recharge Time | 3 Hour |
| Physical Characteristics | |
| Product Color | Black |
| Height | 8.62" (218.95 mm) |
| Width | 6.73" (170.94 mm) |
| Depth | 17.28" (438.91 mm) |
| Rack Height | 0U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 44.31 lb (20098.68 g) |
| Miscellaneous | |
| Software Included | Powerchute Serial Edition |
| Energy Star | Yes |
| Country of Origin | United States |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this UPS?
The APC SMT1000CUS provides 1000VA (1 kVA) and 700W of power capacity. This rating supports moderate loads typically found in small business environments, including servers, network equipment, and multiple desktop systems. The line interactive design with automatic voltage regulation ensures stable power delivery to connected devices.
How long does the battery last during a power outage?
At full load (700W), the battery provides approximately 5 minutes of runtime. At half load (350W), runtime extends to about 19 minutes. These figures allow for graceful shutdowns of connected equipment or brief ride-through of power interruptions. The lead-acid battery typically recharges within 3 hours after use.
What types of outlets does this UPS have?
This unit features 8 NEMA 5-15R outlets, all of which provide battery backup and surge protection. There are no surge-only outlets. The NEMA 5-15P plug connects to standard North American 120V wall outlets, and the included 8-foot power cord offers placement flexibility.
Can this UPS be mounted in a server rack?
Yes, the SMT1000CUS has a rack/tower form factor with 0U rack height, meaning it can be placed in a server rack without consuming vertical rack units. The compact dimensions (8.62"H × 6.73"W × 17.28"D) allow installation in standard racks or use as a standalone tower unit, providing deployment flexibility for different environments.
What monitoring and management features are included?
The UPS includes an LCD display for local status monitoring, plus serial, network (RJ-45), and USB (HID compliant) ports for remote management. The SmartConnect Ethernet port enables cloud-based monitoring without additional hardware. PowerChute Serial Edition software, included with the unit, facilitates graceful shutdowns of connected systems during extended outages.
Is this UPS compliant with government procurement requirements?
Yes, the SMT1000CUS is TAA (Trade Agreements Act) compliant, making it suitable for government and institutional procurement in the United States. It is manufactured in the United States and meets the required sourcing standards. The unit also complies with RoHS (Restriction of Hazardous Substances) environmental regulations.
What power capacity is listed for this UPS?
The listed power specification is 1 kVA, which helps position the unit for the right load level and installation role.
How many outlets are available?
The product includes 0, which helps buyers understand how many connected devices it can support in its intended deployment.
