APC by Schneider Electric SMTL2K2RM2UCL APC Smart-UPS 2200VA/1920W Line Interactive UPS - 2U Rackmount - Lithium-ion - 120V - 7 Outlets - AVR - LCD
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This line-interactive UPS operates with a 10ms transfer time and provides sine wave output at 60Hz frequency. The input voltage range extends from 75V AC to 154V AC, with normal operation between 82V AC and 143V AC. Automatic voltage regulation corrects minor power fluctuations without switching to battery power, extending battery life and maintaining consistent power quality.
The lithium-ion battery delivers 1209.6 kJ of energy, providing 7.8 minutes of runtime at full load (1920W) and 16.4 minutes at half load. Battery recharge completes in approximately 2 hours under typical conditions. Management features include USB and EPO ports, with PowerChute Serial Edition software included for graceful shutdown capabilities.
This section brings together practical product details such as AVR, Plug/Connector Type, Receptacle Type, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The lithium-ion battery technology represents a significant advancement over traditional lead-acid batteries, offering longer service life, faster recharge times, and reduced maintenance requirements. With a typical 10-year battery lifespan, this UPS minimizes the need for battery replacements during its operational lifetime, reducing total cost of ownership.
SmartConnect Remote Management
Cloud-based monitoring via the integrated Ethernet port enables remote power management, alerting, and diagnostics without requiring additional hardware or software licenses.
- Real-time status monitoring
- Remote alert configuration
- Historical power quality data
Comprehensive Protection
Beyond battery backup, this UPS provides multiple layers of protection including automatic voltage regulation, surge suppression, and frequency stabilization.
- 530 joule surge protection
- Input frequency stabilization
- Output waveform conditioning
Deployment / Use Cases
This 2200VA rackmount UPS is ideally suited for small edge environments, back office infrastructure, and network closet deployments. Its 2U form factor fits standard 19-inch racks while providing sufficient power capacity for critical networking equipment and servers.
Typical applications include protecting hyperconverged infrastructure (HCI) nodes, virtual machine hosts, point-of-sale systems, routers, switches, and communication hubs. The combination of lithium-ion battery technology and remote management capabilities makes this UPS particularly valuable for distributed IT environments where onsite maintenance access may be limited.
Network Infrastructure Protection
Provides backup power for IDF/MDF closets, ensuring continuous operation of switches, routers, and network security appliances during power interruptions.
Server Room Deployments
Supports single servers or small server clusters in edge computing environments, with sufficient runtime for graceful shutdown procedures.
Physical Profile
Designed for standard 19-inch rack installation, this UPS occupies 2U of vertical space with dimensions of 3.39" (86 mm) height, 17.01" (432 mm) width, and 26.89" (683 mm) depth. The black and silver finish matches typical data center equipment, while the 70.33 lb weight requires proper rack mounting hardware and consideration of rack load capacity.
- Width
- 17.01" (432 mm)
- Depth
- 26.89" (683 mm)
- Height
- 3.39" (86 mm)
- Weight
- 70.33 lb (31901.15 g)
- Length
- 8 ft (2.44 m)
What's in the Box
The package includes all necessary components for immediate deployment in rackmount environments.
Highlights
- 2200VA/1920W line interactive pure sine wave UPS
- 2U rackmount form factor for standard 19-inch racks
- Lithium-ion battery with 10-year typical lifespan
- Automatic voltage regulation (AVR) for power conditioning
- 7 outlets: 1× NEMA L5-20R + 6× NEMA 5-20R
- LCD display with real-time status monitoring
- SmartConnect Ethernet for cloud-based remote management
- 5-year warranty covering UPS and battery
- Energy Star certified for energy efficiency
- RoHS compliant environmental design
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SMTL2K2RM2UCL |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Name | Smart-UPS 2200VA Rack-mountable UPS |
| Packaged Quantity | 1 |
| Product Type | Line-interactive UPS |
| Technical Information | |
| AVR | Yes |
| Plug/Connector Type | NEMA L5-20P |
| Receptacle Type | NEMA L5-20P |
| Receptacle Detail | 1 x NEMA L5-20R,6 x NEMA 5-20R |
| Cord Length | 8 ft (2.44 m) |
| Transfer Time | 10 ms |
| Phase | Single Phase |
| Application/Usage | IT,Network,Business,Critical System,Server,Virtual Machine,Hyperconverged Infrastructure (HCI),POS,Router,Switch,Hub |
| Power Description | |
| Load Capacity (VA) | 1.92 kVA |
| Load Capacity (Watt) | 1.92 kW |
| Input Voltage | 120 V AC,110 V AC |
| Input Voltage Range | 75 V AC -154 V AC,82 V AC - 143 V AC |
| Output Voltage | 120 V AC,110 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 530 J |
| Display & Graphics | |
| Display | LCD/LED |
| Management | |
| Alarm | On Battery,Low Battery,Overload |
| Controls/Indicators | |
| Status Indicators | LED Indicators: On Line On Battery Replace Battery Overload |
| Interfaces/Ports | |
| USB | Yes |
| EPO Port | Yes |
| Battery Information | |
| Number of Batteries | 1 |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Energy | 1209.6 kJ |
| Backup/Run Time (Full Load) | 7.80 Minute |
| Backup/Run Time (Half Load) | 16.40 Minute |
| Battery Life | 10 Year |
| Typical Battery Recharge Time | 2 Hour |
| Environmental Conditions | |
| Maximum Operating Elevation | 10000 ft (3048000 mm) |
| Maximum Storage Elevation | 50000 ft (15240000 mm) |
| Storage Temperature | 5°F (-15°C) - 113°F (45°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission | 55 dB |
| Thermal Dissipation | 215 BTU/h |
| Physical Characteristics | |
| Product Color | Black,Silver |
| Height | 3.39" (86 mm) |
| Width | 17.01" (432 mm) |
| Depth | 26.89" (683 mm) |
| Rack Height | 2U |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 70.33 lb (31901.15 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS 2200VA Rack-mountable UPS Rack Mounting brackets Rack Mounting support rails Screw Washer USB cable Ethernet patch cable |
| Software Included | Powerchute Serial Edition |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the runtime of this UPS at full load?
The APC Smart-UPS SMTL2K2RM2UCL provides 7.8 minutes of backup runtime at full load (1920W). At half load (960W), the runtime extends to 16.4 minutes. These runtime figures are based on the lithium-ion battery's 1209.6 kJ energy capacity and assume typical operating conditions.
What types of outlets does this UPS have?
This UPS features seven outlets total: one NEMA L5-20R receptacle and six NEMA 5-20R receptacles. The NEMA L5-20R outlet supports equipment requiring 20A, 125V locking connectors, while the six NEMA 5-20R outlets accommodate standard 20A, 125V equipment. The 8-foot power cord terminates in a NEMA L5-20P plug.
How does the lithium-ion battery compare to traditional UPS batteries?
The lithium-ion battery in this UPS offers several advantages over traditional lead-acid batteries, including a longer typical lifespan of 10 years, faster recharge time of approximately 2 hours, and reduced maintenance requirements. Lithium-ion technology also maintains consistent performance across a wider temperature range and has a higher energy density in a compact form factor.
What management capabilities does this UPS offer?
Management features include an LCD display for local monitoring, USB and EPO ports for connectivity, and SmartConnect Ethernet for cloud-based remote management. The included PowerChute Serial Edition software enables graceful shutdown of connected equipment. Status indicators provide visual alerts for on battery, low battery, replace battery, and overload conditions.
What are the physical dimensions for rack installation?
This UPS occupies 2U of vertical space in a standard 19-inch rack, with dimensions of 3.39 inches (86 mm) height, 17.01 inches (432 mm) width, and 26.89 inches (683 mm) depth. The unit weighs 70.33 pounds (31.9 kg) and includes all necessary rack mounting brackets and support rails for secure installation.
What input voltage range does this UPS support?
The UPS accepts input voltage from 75V AC to 154V AC, with normal operation between 82V AC and 143V AC. It automatically adjusts to provide consistent 120V AC output (with 110V AC capability) regardless of minor input fluctuations, thanks to the automatic voltage regulation (AVR) feature. This wide input range ensures reliable operation in areas with unstable power quality.
What power capacity is listed for this UPS?
The listed power specification is 1.92 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 120 V AC,110 V AC, which helps position the unit for the right load level and installation role.
