APC Symmetra RM 6kVA N+1 Frame 208/240V - 8U Rack-mountable - 4 Hour Recharge - 208 V AC Input - 208 V AC Output - Single Phase - Sine (SYHF6KT)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Symmetra 6000VA Rack-mountable UPS
- User Manual
- Rack Mounting Brackets
- Rack Mounting Support Rails
- CD with Software
Plug/Connector Type: NEMA L6-30P
Receptacle Type: NEMA L6-20R,NEMA L6-30R
Receptacle Detail: 2 x NEMA L6-20R,1 x NEMA L6-30R
Cord Length: 5.9 ft (1.80 m)
Phase: Single Phase
Application/Usage: Network,Server
Load Capacity (VA): 6 kVA
Input Voltage: 208 V AC
Input Current: 30 A
Output Voltage: 208 V AC
Waveform Type: Sine Wave
Battery Chemistry: Lead Acid
Typical Battery Recharge Time: 4 Hour
Product Color: Black
Height: 14.02" (356.11 mm)
Width: 19.02" (483.11 mm)
Depth: 28.74" (730 mm)
Rack Height: 8U
Form Factor: Rack-mountable
Weight (Approximate): 99.21 lb (45000.90 g)
Package Contents:
Environmental Compliance: Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Limited Warranty: 2 Year
[custom-specifications]
| Specifications | |
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SYHF6KT |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Symmetra |
| Product Name | Symmetra 6000VA Rack-mountable UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | NEMA L6-20R,NEMA L6-30R |
| Receptacle Detail | 2 x NEMA L6-20R,1 x NEMA L6-30R |
| Cord Length | 5.9 ft (1.80 m) |
| Phase | Single Phase |
| Application/Usage | Network,Server |
| Power Description | |
| Load Capacity (VA) | 6 kVA |
| Input Voltage | 208 V AC |
| Input Current | 30 A |
| Output Voltage | 208 V AC |
| Waveform Type | Sine Wave |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Typical Battery Recharge Time | 4 Hour |
| Physical Characteristics | |
| Product Color | Black |
| Height | 14.02" (356.11 mm) |
| Width | 19.02" (483.11 mm) |
| Depth | 28.74" (730 mm) |
| Rack Height | 8U |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 99.21 lb (45000.90 g) |
| Miscellaneous | |
| Package Contents |
|
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-options]
| Product | APC Symmetra LX/Symmetra RM Two Post Rail Kit - Silver |
| SKU | SYOPT12 |
| Sale Price | $287.95 |
| Product | APC Symmetra RM XR Frame w/2 SYBT2 Scalable to 4 208/240V - 19" |
| SKU | SYRMXR2B4 |
| Sale Price | $4875.95 |
| Product | Cable, Extension Cable for use w/ UPS communications cable 15'/5m - DB-9 Male - DB-9 Female - 4.57m - Gray |
| SKU | AP9815 |
| Sale Price | $42.95 |
| Product | Cable, UPS Communications Simple Signalling - DB-9 Male - DB-9 Female - 1.83m - Gray |
| SKU | 940-0020 |
| Sale Price | $63.95 |
