Ortronics 7SV-10G-T-A Accedian SFP+ Module - 10GbE RJ-45 Copper Transceiver for Twisted Pair - Single-mode - 0. 03 km Reach
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ module utilizes 10GBase-TX technology to achieve a maximum data transfer rate of 10 Gbit/s over standard twisted pair cabling. The RJ-45 interface ensures compatibility with existing copper network infrastructures, while single-mode fiber support enhances signal integrity over the supported 0.03 km reach.
The module's physical dimensions of 0.55" H x 0.54" W x 2.80" D (13.97 mm x 13.66 mm x 71.12 mm) conform to the SFP+ MSA specification, ensuring proper fit in compatible slots. Environmental compliance with RoHS standards and a lifetime limited warranty provide added reliability and sustainability for enterprise deployments.
Key Product Advantages
Copper-Based 10GbE Connectivity
Delivers 10 Gigabit Ethernet performance over standard twisted pair cabling, eliminating the need for costly fiber upgrades in short-reach scenarios.
- RJ-45 interface for easy integration
- Supports existing copper infrastructure
- 10GBase-TX technology for reliable throughput
Compact and Hot-Pluggable Design
The SFP+ form factor allows for easy installation and replacement without powering down networking equipment, minimizing downtime.
- Standard SFP+ dimensions
- Hot-pluggable for maintenance flexibility
- Low-profile design for high-density deployments
Deployment / Use Cases
This Ortronics Accedian SFP+ module is ideal for data center top-of-rack switching, server connectivity, and network aggregation points where 10GbE copper links are required. Its 0.03 km reach makes it suitable for intra-rack or adjacent rack connections within server rooms and networking closets.
Common use cases include connecting switches to servers, storage arrays, or uplink ports in environments where fiber optic cabling is impractical or cost-prohibitive. The module's support for twisted pair media allows for seamless integration with Cat6a or higher cabling, providing a cost-effective upgrade path to 10GbE networks.
Physical Profile
The module measures 0.55" in height, 0.54" in width, and 2.80" in depth (13.97 mm x 13.66 mm x 71.12 mm), adhering to the SFP+ multi-source agreement specifications. This compact size ensures compatibility with a wide range of networking equipment while maintaining proper thermal management for reliable operation.
- Width
- 0.54" (13.66 mm)
- Depth
- 2.80" (71.12 mm)
- Height
- 0.55" (13.97 mm)
Highlights
- 10 Gigabit Ethernet SFP+ transceiver with RJ-45 copper interface
- Supports twisted pair cabling for 10GBase-TX networking
- Single-mode fiber compatibility for enhanced signal integrity
- Maximum data transfer rate of 10 Gbit/s
- 0.03 km (0.02 mile) reach for short-distance connections
- Hot-pluggable SFP+ form factor for easy installation
- RoHS compliant for environmental safety
- Lifetime limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 7SV-10G-T-A |
| Brand Name | Approved Networks |
| Product Name | Accedian SFP+ Module |
| Product Type | SFP+ |
| Technical Information | |
| Application/Usage | Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | RJ-45 |
| Interfaces/Ports Details | 1 x RJ-45 10GBase-TX Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-TX |
| Maximum Distance Supported | 0.03 km (0.02 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.55" (13.97 mm) |
| Width | 0.54" (13.66 mm) |
| Depth | 2.80" (71.12 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of connector does this SFP+ module use?
This Ortronics Accedian SFP+ module uses an RJ-45 connector, which is standard for copper Ethernet connections. The RJ-45 interface allows it to work with twisted pair cabling like Cat6a or higher, making it compatible with existing copper network infrastructures without requiring special adapters.
What is the maximum data transfer rate supported?
The module supports a maximum data transfer rate of 10 Gbit/s using 10GBase-TX technology. This provides 10 Gigabit Ethernet performance over twisted pair media, enabling high-speed data networking for applications such as server connectivity, storage access, and network aggregation.
How far can this module transmit data?
It supports a maximum distance of 0.03 km (approximately 0.02 miles). This reach is typical for copper-based SFP+ modules and is suitable for short-distance connections within data centers, server racks, or adjacent networking equipment where fiber optic cabling may not be necessary.
