Ortronics 3HE01545AA-100-A Alcatel-Lucent XFP Module - 10GBase-ZR LC Duplex 80 km Single-Mode Fiber
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This XFP module operates on 10GBase-ZR network technology, delivering a maximum data transfer rate of 10 Gbit/s. It utilizes a single LC duplex port for bidirectional communication over single-mode optical fiber, supporting wavelengths optimized for long-haul transmissions. The module's design incorporates advanced optics to maintain signal integrity across distances up to 80 kilometers, reducing the need for signal repeaters in extended network setups.
Built to industry standards, the module ensures interoperability with compatible networking equipment from Alcatel-Lucent and other vendors. Its environmental compliance with RoHS (Restriction of Hazardous Substances) underscores a commitment to safety and sustainability. The lifetime limited warranty provides long-term reliability assurance for network deployments.
Key Product Advantages
The Ortronics XFP Module offers distinct advantages for network architects seeking robust optical connectivity. Its 10GBase-ZR technology enables high-speed data transfers over extensive distances, crucial for backbone and metropolitan area networks. The use of single-mode fiber ensures minimal signal loss and interference, enhancing data integrity across long links.
Extended Reach Capability
Supports transmissions up to 80 kilometers, ideal for connecting remote data centers or campus networks without intermediate equipment.
- Reduces infrastructure costs
- Minimizes latency over long distances
High-Speed Performance
Delivers 10 Gbit/s data rates, meeting the demands of bandwidth-intensive applications like video streaming and large data transfers.
- Enables scalable network growth
- Supports 10 Gigabit Ethernet standards
Reliable Connectivity
Features an LC duplex connector for secure fiber optic connections, ensuring stable performance in varied environmental conditions.
- Low insertion loss design
- Compatible with standard fiber patch panels
Deployment / Use Cases
This XFP module is versatile for multiple networking scenarios, particularly where high-speed, long-distance fiber optic links are required. It excels in backbone connections between data centers, enabling seamless data flow across geographically dispersed locations. The module's 80 km reach makes it suitable for metropolitan area networks (MANs), linking corporate offices or campus buildings over fiber infrastructure.
In enterprise environments, it supports server-to-switch connections in data centers, facilitating rapid data access and storage networking. For service providers, the module can be deployed in optical transport networks to enhance bandwidth capacity and reliability. Its compatibility with Alcatel-Lucent equipment ensures smooth integration into existing network architectures, reducing deployment complexity.
Data Center Interconnects
Use for linking data centers over long distances, supporting disaster recovery and data replication with high-speed 10 Gbit/s links.
Enterprise Network Backbones
Ideal for core network segments in large organizations, providing reliable connectivity for critical business applications across campuses.
Physical Profile
The module has a compact design with dimensions of 0.33 inches in height, 0.64 inches in width, and 3.07 inches in depth, making it suitable for high-density installations in network switches and routers. Its small form factor allows for efficient use of rack space in data centers. The module is hot-pluggable, enabling installation or replacement without powering down the network equipment, which minimizes downtime during maintenance or upgrades.
- Width
- 0.64" (16.30 mm)
- Depth
- 3.07" (78 mm)
- Height
- 0.33" (8.40 mm)
Highlights
- 10GBase-ZR technology for 10 Gbit/s data transfer over optical fiber
- LC duplex connector ensures reliable fiber optic connections
- Supports single-mode fiber with a reach of up to 80 kilometers
- Hot-pluggable design for easy installation and maintenance
- Compatible with Alcatel-Lucent and standard networking equipment
- RoHS compliant for environmental safety
- Lifetime limited warranty for long-term reliability
- Compact dimensions ideal for high-density network deployments
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 3HE01545AA-100-A |
| Brand Name | Approved Networks |
| Product Name | Alcatel-Lucent XFP Module |
| Product Type | XFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-ZR Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-ZR |
| Maximum Distance Supported | 80 km (49.71 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.40 mm) |
| Width | 0.64" (16.30 mm) |
| Depth | 3.07" (78 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What is the maximum distance supported by this XFP module?
This XFP module supports a maximum distance of 80 kilometers (approximately 49.71 miles) over single-mode fiber optic cable. This extended reach makes it suitable for long-haul network connections, such as between data centers or across metropolitan areas, without requiring signal repeaters.
What type of connector does this module use?
The module uses an LC duplex connector, which provides a secure and precise connection for single-mode fiber optic cables. LC connectors are widely used in high-density networking environments due to their small size and low insertion loss, ensuring stable performance in data transmission.
Is this XFP module hot-pluggable?
Yes, this XFP module is hot-pluggable, meaning it can be installed or removed from compatible networking equipment without powering down the system. This feature reduces downtime during maintenance or upgrades, allowing for seamless network management in live environments.
What is the data transfer rate of this module?
The module delivers a maximum data transfer rate of 10 Gbit/s using 10GBase-ZR network technology. This high-speed performance supports bandwidth-intensive applications, such as video streaming, data backups, and enterprise network traffic, ensuring efficient data flow across optical fiber links.
