Ortronics SPLX40-A Allied SFP Module - 1Gbps LC Duplex 1000Base-EX Singlemode 40km Fiber Optic Transceiver
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP module operates on Gigabit Ethernet technology, specifically utilizing the 1000Base-EX standard for long-distance singlemode fiber applications. It features a single LC duplex port that supports full-duplex communication, ensuring high-speed data transfers with minimal latency.
The module is optimized for singlemode fiber, which uses a single wavelength of light to carry data over miles, making it ideal for backbone links, campus networks, and other scenarios requiring extended reach without signal degradation. Its design includes Digital Diagnostic Monitoring (DDM) capabilities, allowing for real-time performance tracking and troubleshooting.
Key Product Advantages
The Ortronics SPLX40-A offers several advantages for network deployments, including extended reach, high reliability, and ease of integration. Its 40-kilometer support enables connectivity over long distances without the need for repeaters, reducing infrastructure costs and complexity.
High-Speed Performance
Delivers up to 1 Gbps data transfer rates, which is up to 10 times faster than standard Ethernet connections, ensuring efficient handling of data-intensive applications.
- Gigabit Ethernet technology
- 1000Base-EX compliance
- Low latency operation
Durable Fiber Optic Support
Utilizes singlemode fiber for minimal signal loss and high durability, making it suitable for harsh environments and long-term deployments.
- Singlemode fiber compatibility
- Resistant to EMI/RFI interference
- Long lifespan
Deployment / Use Cases
This SFP module is ideal for a variety of networking scenarios that require reliable, high-speed fiber optic connections over extended distances. It is commonly used in enterprise networks, data centers, and telecommunications infrastructure.
Typical applications include connecting switches and routers across campus buildings, providing backbone links for internet service providers, and supporting video surveillance or audio/video transmission systems that demand stable, long-range connectivity.
Enterprise Backbone Links
Connect core networking equipment across different floors or buildings within a corporate campus, ensuring seamless data flow and network redundancy.
ISP and Telco Networks
Deploy in telecommunications networks to extend fiber optic reach for broadband services, supporting high-bandwidth demands and future scalability.
Physical Profile
The module has a compact design with dimensions of 0.33 inches in height, 0.53 inches in width, and 2.23 inches in depth, making it suitable for high-density installations in switches and routers. Its small footprint allows for efficient use of rack space while maintaining robust performance.
- Width
- 0.53" (13.40 mm)
- Depth
- 2.23" (56.65 mm)
- Height
- 0.33" (8.50 mm)
Highlights
- 1 Gbps data transfer rate with 1000Base-EX technology for high-speed networking
- LC duplex connector ensures secure and reliable fiber optic connections
- Supports singlemode fiber with a reach of up to 40 kilometers (24.85 miles)
- Hot-pluggable SFP form factor for easy installation and upgrades
- Digital Diagnostic Monitoring (DDM) for real-time performance tracking
- RoHS compliant and environmentally friendly design
- Lifetime warranty for long-term reliability and peace of mind
- Compact dimensions ideal for high-density network equipment
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | SPLX40-A |
| Brand Name | Approved Networks |
| Product Name | Allied SFP Module |
| Product Type | SFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 1000Base-EX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-EX |
| Maximum Distance Supported | 40 km (24.85 Mile) |
| Maximum Data Transfer Rate | 1 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.50 mm) |
| Width | 0.53" (13.40 mm) |
| Depth | 2.23" (56.65 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What is the maximum distance supported by this SFP module?
This SFP module supports a maximum distance of 40 kilometers (approximately 24.85 miles) over singlemode fiber, making it suitable for long-range network links without signal degradation.
What type of connector does this SFP module use?
It uses an LC duplex connector, which provides a secure and efficient connection for fiber optic cables, ensuring minimal signal loss and reliable performance in data networking applications.
Is this module compatible with singlemode or multimode fiber?
This module is designed for singlemode fiber, which uses a single wavelength of light to carry data over long distances, offering better performance for extended reach compared to multimode fiber.
What is the data transfer rate of this SFP module?
It supports a maximum data transfer rate of 1 Gbps (Gigabit per second) using 1000Base-EX technology, delivering high-speed connectivity for optical and data networking needs.
