Ortronics AT-SPEX-A Allied SFP Module - 1G Gigabit Ethernet - LC Duplex - 1000Base-LX - Single-mode - 10 km Reach
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP transceiver operates on Gigabit Ethernet technology with 1000Base-LX network compatibility, ensuring seamless integration with compatible switches, routers, and network interface cards. The module supports single-mode fiber optic media, which utilizes a single wavelength of light to transmit data over extended distances with minimal signal degradation.
The transceiver's LC duplex connector provides a secure, low-loss connection for optical fiber cables, while the compact form factor allows for high-density installations in network equipment. With a maximum supported distance of 10 kilometers (6.21 miles), this module extends network reach beyond typical copper-based Ethernet limitations.
Key Product Advantages
The Ortronics AT-SPEX-A Allied SFP Module delivers reliable optical connectivity with several distinct advantages for network infrastructure.
Extended Reach Capability
With support for distances up to 10 kilometers, this transceiver enables long-haul network connections between buildings, campuses, or data center facilities without requiring intermediate signal boosting equipment.
- 10 km maximum distance
- Single-mode fiber optimization
- Minimal signal loss over distance
High-Speed Data Transmission
The 1000Base-LX technology provides Gigabit Ethernet performance at 1 Gbit/s, delivering up to 10 times the throughput of standard Fast Ethernet connections for bandwidth-intensive applications.
- 1 Gbit/s data transfer rate
- Gigabit Ethernet compatibility
- Low-latency performance
Environmental Compliance
Manufactured in compliance with RoHS (Restriction of Hazardous Substances) standards, this SFP module meets environmental regulations for reduced hazardous material content in electronic components.
- RoHS compliant
- Environmentally friendly design
- Lifetime warranty coverage
Deployment / Use Cases
The Ortronics AT-SPEX-A Allied SFP Module is designed for various network deployment scenarios where reliable, high-speed fiber optic connectivity is essential. Its single-mode fiber support and extended reach capability make it particularly valuable for infrastructure spanning multiple locations.
In data center environments, this transceiver facilitates connections between switches and servers across different racks or rooms. For enterprise networks, it enables secure links between buildings on a campus or between geographically separated offices. Telecommunications providers can utilize these modules for last-mile fiber connections or backbone network segments requiring stable, long-distance transmission.
Data Center Interconnects
Connect servers, storage arrays, and network switches across data center floors or between colocation facilities with reliable 10 km fiber optic links.
Campus Network Backbones
Establish high-speed connections between buildings on university campuses, corporate parks, or hospital complexes using single-mode fiber infrastructure.
Physical Profile
The compact SFP form factor measures 0.53" (13.40 mm) in width, 0.33" (8.50 mm) in height, and 2.23" (56.65 mm) in depth, allowing for high-density installations in network equipment. This standardized size ensures compatibility with SFP slots in switches, routers, and media converters from various manufacturers.
- Width
- 0.53" (13.40 mm)
- Depth
- 2.23" (56.65 mm)
- Height
- 0.33" (8.50 mm)
Highlights
- 1000Base-LX Gigabit Ethernet SFP transceiver module
- LC duplex connector for single-mode fiber optic connections
- 1 Gbit/s maximum data transfer rate for high-speed networking
- 10 km (6.21 mile) maximum distance support
- Single-mode fiber optic media compatibility
- Hot-pluggable design for easy installation and replacement
- RoHS compliant for environmental safety
- Lifetime limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | AT-SPEX-A |
| Brand Name | Approved Networks |
| Product Name | Allied SFP Module |
| Product Type | SFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 1000Base-LX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-LX |
| Maximum Distance Supported | 10 km (6.21 Mile) |
| Maximum Data Transfer Rate | 1 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.50 mm) |
| Width | 0.53" (13.40 mm) |
| Depth | 2.23" (56.65 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of fiber optic cable does this SFP module support?
The Ortronics AT-SPEX-A Allied SFP Module supports single-mode fiber optic cables. Single-mode fiber uses a single wavelength of light to transmit data over longer distances with minimal signal loss compared to multimode fiber, making it ideal for connections up to 10 kilometers.
What is the maximum data transfer rate of this SFP transceiver?
This SFP module supports a maximum data transfer rate of 1 Gbit/s (Gigabit per second) using 1000Base-LX network technology. This provides ten times the throughput of standard 100 Mbps Fast Ethernet connections, enabling high-speed data transmission for bandwidth-intensive network applications.
How far can this SFP module transmit data over fiber optic cable?
The transceiver supports a maximum distance of 10 kilometers (approximately 6.21 miles) over single-mode fiber optic cable. This extended reach capability allows network connections between geographically separated buildings or across large campus environments without requiring signal regeneration equipment.
What type of connector does this SFP module use?
This SFP module features an LC duplex connector. The LC connector is a small form-factor fiber optic connector that provides secure, low-loss connections for single-mode fiber cables. The duplex configuration supports both transmit and receive fibers in a single compact interface.
