Ortronics SPLX10-A Allied SFP Module - 1G Gigabit Ethernet LC Duplex 1000Base-LX Single-mode 10 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The SPLX10-A operates on Gigabit Ethernet standards, specifically 1000Base-LX, which is optimized for long-wavelength transmission over single-mode fiber. It features one LC duplex port, supporting full-duplex communication for simultaneous data send and receive operations. The module's design ensures low power consumption and reliable performance in various networking conditions, making it a dependable choice for both new installations and upgrades.
This SFP module supports a maximum data transfer rate of 1 Gbit/s, providing high-bandwidth connectivity for data-intensive applications. Its single-mode fiber capability allows for extended reach up to 10 km with minimal integrity loss, which is essential for maintaining data quality over long distances. The module is also environmentally compliant with RoHS standards, ensuring it meets regulatory requirements for hazardous substance restrictions.
Key Product Advantages
The Ortronics SPLX10-A offers several advantages for network deployments, including high-speed performance, extended reach, and reliable fiber optic connectivity. Its compact SFP form factor allows for flexible installation in space-constrained environments, while the hot-pluggable design enables easy maintenance and upgrades without network downtime.
High-Speed Data Transfer
With a 1 Gbit/s data transfer rate, this module supports bandwidth-intensive applications, reducing latency and improving network efficiency for tasks like file transfers, video streaming, and cloud access.
- Up to 10x faster than standard Ethernet
- Ideal for gigabit-speed transmissions
Long-Distance Connectivity
The 10 km reach over single-mode fiber makes it suitable for connecting remote network segments, such as between buildings or across large campuses, without signal degradation.
- Minimal integrity loss over hundreds of miles
- Supports expansive network layouts
Environmental Compliance
RoHS compliance ensures the module meets environmental standards, reducing hazardous substances and supporting sustainable IT practices.
- Environmentally friendly design
- Meets global regulatory requirements
Deployment / Use Cases
The SPLX10-A is versatile for various networking scenarios, particularly in environments requiring reliable, high-speed fiber optic connections. It is commonly used in data centers to link switches and servers, in enterprise networks for backbone connectivity, and in telecommunications for extending network reach. Its compatibility with optical fiber infrastructure makes it a go-to solution for upgrading existing networks to gigabit speeds.
Typical use cases include connecting network switches in different buildings within a campus, linking data center racks over long distances, and integrating with media converters for fiber-to-copper transitions. The module's single-mode fiber support ensures it performs well in applications where data integrity over extended ranges is paramount, such as in surveillance systems, VoIP deployments, or high-performance computing clusters.
Data Center Interconnects
Use this SFP module to connect servers and storage devices across data center aisles, ensuring high-throughput and low-latency communication for critical operations.
Enterprise Network Backbones
Deploy in corporate networks to establish reliable links between floors or buildings, supporting seamless data flow for applications like ERP systems and video conferencing.
Physical Profile
The SPLX10-A has a compact design with dimensions of 0.50" (12.80 mm) in height, 0.54" (13.70 mm) in width, and 2.23" (56.60 mm) in depth, making it suitable for high-density installations in network equipment. Its small form factor allows for efficient use of rack space and easy integration into SFP slots on compatible devices. The module's robust construction ensures durability in various operating conditions, from controlled data centers to industrial settings.
- Width
- 0.54" (13.70 mm)
- Depth
- 2.23" (56.60 mm)
- Height
- 0.50" (12.80 mm)
Highlights
- 1 Gbit/s data transfer rate for high-speed networking
- LC duplex connector for secure fiber optic connections
- 1000Base-LX technology optimized for long-wavelength transmission
- Single-mode fiber support with up to 10 km reach
- Hot-pluggable SFP form factor for easy installation
- RoHS compliant for environmental safety
- Compact dimensions for space-efficient deployments
- Lifetime limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | SPLX10-A |
| Brand Name | Approved Networks |
| Product Name | Allied SFP Module |
| Product Type | SFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 1000Base-LX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-LX |
| Maximum Distance Supported | 10 km (6.21 Mile) |
| Maximum Data Transfer Rate | 1 Gbit/s |
| Physical Characteristics | |
| Height | 0.50" (12.80 mm) |
| Width | 0.54" (13.70 mm) |
| Depth | 2.23" (56.60 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum data transfer rate of the Ortronics SPLX10-A SFP module?
The Ortronics SPLX10-A SFP module supports a maximum data transfer rate of 1 Gbit/s, which is equivalent to 1000 Mbps. This Gigabit Ethernet speed enables high-performance networking for applications like data backups, video streaming, and large file transfers, providing up to 10 times faster throughput compared to standard Ethernet connections.
What type of fiber optic cable is compatible with this SFP module?
This SFP module is compatible with single-mode fiber optic cables, which are designed for long-distance transmissions with minimal signal loss. It uses an LC duplex connector, ensuring a reliable connection for data networking over distances up to 10 km, making it ideal for extending network reach in campuses or data centers.
How far can the SPLX10-A transmit data over fiber optic cable?
The SPLX10-A can transmit data up to 10 km (approximately 6.21 miles) over single-mode fiber optic cable. This extended reach is achieved through 1000Base-LX technology, which maintains data integrity over long distances, reducing the need for repeaters and supporting efficient network layouts across large areas.
Is this SFP module hot-pluggable?
Yes, the SPLX10-A is hot-pluggable, allowing for installation or removal without powering down the network device. This feature minimizes downtime during maintenance or upgrades, enabling seamless integration into live networks and enhancing operational flexibility in dynamic IT environments.
What environmental standards does the SPLX10-A comply with?
The SPLX10-A complies with the Restriction of Hazardous Substances (RoHS) standard, ensuring it is environmentally friendly by limiting the use of certain hazardous materials. This compliance supports sustainable IT practices and meets regulatory requirements for electronic products in various markets.
What warranty is offered with the Ortronics SPLX10-A SFP module?
The Ortronics SPLX10-A comes with a lifetime limited warranty, providing long-term assurance against defects in materials and workmanship. This warranty underscores the module's reliability and durability, offering peace of mind for network deployments in critical applications.
