Ortronics 45W4973-A Citrix XFP Module - 10GbE SR LC Duplex Multimode 0. 30 km (0. 19 Mile) Optical Transceiver
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Engineered for optical network and data networking applications, this transceiver features a single LC duplex port that interfaces with multimode fiber optic cables. It operates at an 850 nm wavelength, typical for short-range multimode deployments, and supports distances up to 0.30 km (0.19 mile).
The module leverages 10 Gigabit Ethernet technology to optimize network performance, providing low-latency, high-bandwidth connectivity essential for modern IT infrastructure. Its design includes digital diagnostics monitoring (DDM) capabilities, allowing for real-time performance tracking and proactive network management.
Key Product Advantages
This XFP module delivers robust, high-speed optical connectivity with a focus on reliability and ease of integration. Its key advantages include consistent performance in data-intensive environments and straightforward compatibility with existing XFP infrastructure.
High-Speed Data Transfer
Supports 10 Gbps data rates, enabling fast transmission for bandwidth-heavy applications like video streaming, large file transfers, and virtualized workloads.
- 10 Gbit/s maximum transfer rate
- Low-latency operation
- Ideal for backbone links
Reliable Fiber Connectivity
Uses LC duplex connectors and multimode fiber to provide stable, long-distance connections with minimal signal loss, ensuring data integrity across network segments.
- LC duplex interface
- Multimode fiber support
- Up to 0.30 km reach
Industry-Standard Compliance
Adheres to RoHS environmental standards and comes with a lifetime warranty, offering peace of mind for sustainable and long-term deployments.
- RoHS compliant
- Lifetime warranty
- Hot-pluggable design
Deployment / Use Cases
This transceiver is ideal for expanding or upgrading network capacity in enterprise data centers, campus networks, and service provider environments. It facilitates high-speed connections between switches, servers, and storage arrays, supporting scalable network architectures.
Common use cases include connecting top-of-rack switches to aggregation layers, linking servers in high-performance computing clusters, and extending network backbones across buildings within a campus. Its multimode fiber compatibility makes it suitable for short to medium-distance runs where cost-effective fiber solutions are preferred.
Data Center Interconnects
Enables 10GbE links between switches and servers, supporting virtualization, cloud services, and storage area networks (SANs) with high throughput and low latency.
Network Backbone Upgrades
Upgrades existing fiber infrastructure to 10 Gigabit speeds, enhancing performance for core routing and aggregation without replacing entire cabling systems.
Physical Profile
The module measures 0.55" (13.90 mm) in height and width, with a depth of 2.26" (57.50 mm), conforming to the standard XFP form factor for easy installation in compatible slots. Its compact size allows for high-density deployments in network equipment, maximizing port utilization without sacrificing performance.
- Width
- 0.55" (13.90 mm)
- Depth
- 2.26" (57.50 mm)
- Height
- 0.55" (13.90 mm)
Highlights
- 10 Gigabit Ethernet XFP optical transceiver for high-speed data networking
- Supports 10GBase-SR standard over multimode fiber optic cable
- LC duplex connector interface for reliable fiber connectivity
- Maximum reach of 0.30 km (0.19 mile) for short to medium-distance runs
- Hot-pluggable design for easy installation and maintenance
- Digital diagnostics monitoring (DDM) for real-time performance tracking
- RoHS compliant and environmentally friendly
- Backed by a lifetime limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 45W4973-A |
| Brand Name | Approved Networks |
| Product Name | Citrix XFP Module |
| Product Type | XFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-SR Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-SR |
| Maximum Distance Supported | 0.30 km (0.19 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.55" (13.90 mm) |
| Width | 0.55" (13.90 mm) |
| Depth | 2.26" (57.50 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of fiber optic cable is compatible with this XFP module?
This module is compatible with multimode fiber optic cables, typically using OM3 or OM4 grades for optimal performance. It supports the 10GBase-SR standard, which is designed for short-range multimode deployments up to 0.30 km (0.19 mile) with an 850 nm wavelength.
What is the maximum data transfer rate supported by this transceiver?
The transceiver supports a maximum data transfer rate of 10 Gbit/s (10 Gigabits per second), enabling high-speed connectivity for demanding network applications such as data center interconnects, server aggregation, and backbone links.
Does this XFP module include digital diagnostics monitoring (DDM)?
Yes, this XFP module includes digital diagnostics monitoring (DDM) capabilities, allowing for real-time tracking of parameters like temperature, voltage, and optical power. This feature helps in proactive network management and troubleshooting.
