Ortronics 407-BBOP-23-10-A Dell SFP+ Module - 10GBase-BX Single-Mode LC Duplex - 20 km Reach
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ module operates at a maximum data transfer rate of 10 Gbit/s using 10 Gigabit Ethernet technology. The 10GBase-BX network technology supports bidirectional communication over a single fiber strand, optimizing fiber utilization for cost-effective deployments.
The module is designed for single-mode fiber optic cables, which maintain signal integrity over extended distances up to 20 km. This makes it suitable for metropolitan area networks, campus backbones, and other applications requiring reliable long-haul connectivity.
This section brings together practical product details such as Application/Usage, Total Number of Ports, Connector Type, Interfaces/Ports Details, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This transceiver combines high-speed performance with extended reach capabilities, making it a versatile choice for expanding network infrastructure without compromising on reliability.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Long-Distance Performance, Compatibility & Integration.
Long-Distance Performance
Supports transmission distances up to 20 kilometers over single-mode fiber, ideal for connecting geographically dispersed network segments.
- 20 km maximum reach
- Single-mode fiber optimization
- Minimal signal degradation
Compatibility & Integration
Designed as a Dell-compatible module for seamless integration with existing network equipment, reducing deployment complexity.
- Dell infrastructure compatibility
- Hot-pluggable design
- Standard SFP+ form factor
Deployment / Use Cases
This SFP+ module is well-suited for various networking scenarios that require high-bandwidth, long-distance fiber optic connections. Its 10GBase-BX technology and single-mode fiber support make it particularly effective in environments where fiber resources are limited or cost optimization is important.
Common deployment scenarios include connecting network switches between buildings in a campus environment, linking data centers across metropolitan areas, and establishing reliable backhaul connections for service provider networks. The module's compact size and standard form factor allow for flexible installation in switch chassis with SFP+ slots.
Campus Network Backbone
Connect multiple buildings across a university or corporate campus with high-speed 10GbE links that span up to 20 kilometers.
Data Center Interconnect
Establish reliable connections between data center facilities using single-mode fiber infrastructure with 10GBase-BX technology.
Physical Profile
The module features a compact SFP+ form factor with dimensions of 0.50 inches in height, 0.54 inches in width, and 2.23 inches in depth (12.80 × 13.70 × 56.60 mm). This standardized size ensures compatibility with SFP+ slots in network switches and routers from various manufacturers. The module is hot-pluggable, allowing for installation or replacement without powering down the host equipment.
- Width
- 0.54" (13.70 mm)
- Depth
- 2.23" (56.60 mm)
- Height
- 0.50" (12.80 mm)
Highlights
- Dell-compatible SFP+ optical transceiver module for 10 Gigabit Ethernet networks
- 10GBase-BX technology supporting bidirectional communication over single fiber
- LC duplex connector for secure fiber optic connections
- Single-mode fiber support with maximum reach of 20 kilometers
- Maximum data transfer rate of 10 Gbit/s
- Compact SFP+ form factor (0.50" H × 0.54" W × 2.23" D)
- Hot-pluggable design for easy installation and maintenance
- RoHS compliant for environmental safety
- Lifetime limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 407-BBOP-23-10-A |
| Brand Name | Approved Networks |
| Product Name | Dell SFP+ Module |
| Product Type | SFP+ |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-BX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-BX |
| Maximum Distance Supported | 20 km (12.43 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.50" (12.80 mm) |
| Width | 0.54" (13.70 mm) |
| Depth | 2.23" (56.60 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What type of fiber optic cable does this SFP+ module support?
This SFP+ module supports single-mode fiber optic cables. Single-mode fiber is designed for long-distance transmission with minimal signal loss, making it ideal for connections spanning up to 20 kilometers. The module uses LC duplex connectors for secure fiber termination.
What is the maximum data transfer rate of this transceiver?
The module operates at a maximum data transfer rate of 10 Gbit/s using 10 Gigabit Ethernet technology. This provides high-bandwidth connectivity suitable for demanding network applications, including data center interconnects and campus network backbones.
How far can this SFP+ module transmit data?
This transceiver supports transmission distances up to 20 kilometers (approximately 12.43 miles) over single-mode fiber. This extended reach makes it suitable for connecting network equipment across buildings, campuses, or metropolitan areas without requiring signal regeneration.
What network technology does this module use?
The module implements 10GBase-BX network technology, which enables bidirectional communication over a single fiber strand. This technology optimizes fiber utilization by allowing both transmit and receive signals to travel on the same fiber, reducing infrastructure costs compared to traditional dual-fiber implementations.
Is this SFP+ module compatible with Dell equipment?
Yes, this is a Dell-compatible SFP+ module designed to work with Dell network switches, routers, and other infrastructure that supports SFP+ transceivers. It follows the standard SFP+ form factor and electrical specifications for seamless integration with Dell networking products.
What type of connector does this transceiver have?
The module features an LC duplex connector, which is a small form-factor fiber optic connector commonly used in high-density networking applications. The LC connector provides reliable connections with low insertion loss, ensuring optimal signal transmission for 10GbE networks.
