Ortronics 407-BBOV-A Dell SFP+ Module - 10GbE LC Duplex 10GBase-ER Single-mode 40 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ module operates on 10 Gigabit Ethernet standards, specifically utilizing 10GBase-ER network technology for extended reach over single-mode fiber. It employs a 1550 nm wavelength, which is standard for 10GBase-ER applications, ensuring reliable performance over distances up to 40 km. The module supports a maximum data transfer rate of 10 Gbit/s, providing the bandwidth necessary for high-speed data centers, enterprise networks, and telecommunications backbones.
The LC duplex connector interface offers a secure and low-loss connection, critical for maintaining signal integrity in optical networks. The module is designed with digital diagnostics monitoring (DDM) capabilities, allowing for real-time monitoring of temperature, voltage, bias current, and optical power. This feature enhances network management by providing visibility into module performance and health, helping to prevent potential issues before they affect connectivity.
Key Product Advantages
The Ortronics 407-BBOV-A Dell SFP+ Module offers several advantages for network deployments requiring high-speed, long-distance optical connectivity. Its compatibility with Dell equipment ensures seamless integration into existing Dell-based networks, reducing compatibility concerns and simplifying procurement. The extended reach of 40 kilometers makes it ideal for connecting geographically dispersed sites, such as between data centers or across campus networks, without the need for additional signal boosters.
High-Speed Performance
Delivers 10 Gbit/s throughput, supporting bandwidth-intensive applications like video streaming, large file transfers, and cloud services without bottlenecks.
- 10GbE connectivity
- Low latency transmission
- Efficient data handling
Reliable Long-Distance Connectivity
Utilizes single-mode fiber and 10GBase-ER technology to maintain signal integrity over distances up to 40 km, ensuring stable network links.
- 40 km reach
- Single-mode fiber optimized
- Reduced signal loss
Deployment / Use Cases
This SFP+ module is well-suited for a variety of deployment scenarios in enterprise and service provider networks. In data center environments, it can be used to interconnect switches and servers across different racks or buildings, supporting high-speed data replication and backup operations. For telecommunications, it enables long-haul connections between central offices or network nodes, facilitating reliable voice and data transmission over extended distances.
In enterprise campus networks, the module connects wiring closets to core switches, ensuring fast access to network resources across large facilities. It is also effective in storage area networks (SANs) for linking storage arrays to servers, improving data accessibility and performance. The hot-pluggable design allows for easy upgrades or replacements without disrupting network operations, making it a flexible solution for evolving network needs.
Physical Profile
The module has compact dimensions of 0.50 inches in height, 0.55 inches in width, and 2.30 inches in depth, making it suitable for high-density installations in switches and routers. Its small form factor allows for efficient use of space in network equipment, supporting deployments where rack space is limited. The design includes a robust housing that protects internal components from environmental factors, ensuring durability in various operating conditions.
- Width
- 0.55" (13.90 mm)
- Depth
- 2.30" (58.40 mm)
- Height
- 0.50" (12.60 mm)
Highlights
- 10 Gigabit Ethernet SFP+ optical transceiver module for high-speed data networking
- Compatible with Dell networking equipment for seamless integration
- Supports 10GBase-ER technology with a maximum reach of 40 kilometers over single-mode fiber
- Features an LC duplex connector for secure and low-loss optical connections
- Hot-pluggable design allows for easy installation and maintenance without network downtime
- Digital diagnostics monitoring (DDM) provides real-time performance and health insights
- Operates at a 1550 nm wavelength, standard for extended-reach 10GbE applications
- Compact dimensions enable high-density deployments in switches and routers
- RoHS compliant and environmentally friendly, meeting regulatory standards
- Backed by a lifetime limited warranty for long-term reliability and support
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 407-BBOV-A |
| Brand Name | Approved Networks |
| Product Name | Dell SFP+ Module |
| Product Type | SFP+ |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-ER Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-ER |
| Maximum Distance Supported | 40 km (24.85 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.50" (12.60 mm) |
| Width | 0.55" (13.90 mm) |
| Depth | 2.30" (58.40 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What is the maximum data transfer rate of this SFP+ module?
This SFP+ module supports a maximum data transfer rate of 10 Gbit/s, utilizing 10 Gigabit Ethernet technology. It is designed for high-speed optical networks, enabling efficient handling of bandwidth-intensive applications such as data center interconnects, video streaming, and large file transfers without performance degradation.
What type of fiber and connector does this module use?
The module uses single-mode optical fiber with an LC duplex connector. Single-mode fiber is optimized for long-distance transmissions up to 40 kilometers, while the LC duplex connector provides a secure, low-loss interface that ensures reliable signal integrity in network connections.
Is this SFP+ module compatible with Dell equipment?
Yes, this SFP+ module is specifically designed for compatibility with Dell networking equipment. It can be integrated into Dell switches and routers that support SFP+ slots, making it a suitable choice for expanding or upgrading Dell-based optical networks without compatibility issues.
What is the reach capability of this module?
This module supports a maximum distance of 40 kilometers (24.85 miles) over single-mode fiber using 10GBase-ER technology. This extended reach makes it ideal for connecting geographically dispersed sites, such as between data centers or across large campus networks, without requiring additional signal amplification.
