Ortronics 7G17A03130-A SFP+ Module - 10GbE RJ-45 Copper Transceiver - 10GBase-TX over Twisted Pair
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ transceiver implements 10GBase-TX technology over Category 6A or better twisted pair cabling. The module operates at the full 10 Gigabit Ethernet specification, providing backward compatibility with lower-speed Ethernet standards while maximizing throughput for modern applications.
The compact form factor measures just 0.33" × 0.53" × 1.65", allowing dense deployment in switch and server ports. The single RJ-45 port supports standard Ethernet cabling up to 100 meters, eliminating the need for fiber optic infrastructure in many deployment scenarios.
Key Product Advantages
This SFP+ module delivers significant advantages for network administrators seeking to upgrade to 10GbE without replacing existing copper cabling infrastructure.
Cost-Effective 10GbE Migration
Utilize existing Category 6A twisted pair cabling instead of investing in fiber optic infrastructure, reducing upgrade costs while achieving 10 Gigabit performance.
- Leverages existing copper cabling
- Eliminates fiber transceiver costs
- Reduces overall deployment expense
Simplified Network Management
Standard RJ-45 connectors and familiar twisted pair media simplify installation and maintenance compared to fiber optic alternatives.
- RJ-45 connector familiarity
- Standard Ethernet cabling
- Easy troubleshooting and testing
Deployment / Use Cases
The Ortronics 7G17A03130-A SFP+ module is ideal for environments requiring high-bandwidth connectivity over copper infrastructure. Its 10GBase-TX implementation makes it particularly valuable for specific networking scenarios.
Server-to-switch connections in data centers benefit from the 10 Gbps throughput for virtualized environments and storage networks. Campus backbone links can leverage existing copper cabling plants while upgrading to 10GbE performance for aggregated traffic.
Data Center Server Connectivity
Connect servers to top-of-rack switches using standard twisted pair cabling, providing 10GbE performance for virtual machine traffic, storage access, and application workloads.
Network Aggregation Links
Use as uplinks between switches in wiring closets or between distribution and core layers, maximizing throughput for aggregated user traffic without fiber optic conversion.
Physical Profile
The compact SFP+ form factor measures 0.33" in height, 0.53" in width, and 1.65" in depth, allowing high-density deployment in switch chassis and network interface cards. The small footprint maximizes port utilization while maintaining full 10GbE performance over copper media.
- Width
- 0.53" (13.40 mm)
- Depth
- 1.65" (41.80 mm)
- Height
- 0.33" (8.50 mm)
Highlights
- 10 Gigabit Ethernet SFP+ copper transceiver with RJ-45 connector
- 10GBase-TX technology over twisted pair cabling
- Maximum data transfer rate of 10 Gbit/s
- Compatible with Lenovo networking equipment
- Supports standard Category 6A Ethernet cabling
- Compact dimensions: 0.33" × 0.53" × 1.65"
- Hot-pluggable for easy installation and replacement
- RoHS compliant for environmental responsibility
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 7G17A03130-A |
| Brand Name | Approved Networks |
| Product Name | Lenovo SFP+ Module |
| Product Type | SFP+ |
| Technical Information | |
| Application/Usage | Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | RJ-45 |
| Interfaces/Ports Details | 1 x RJ-45 10GBase-T Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-TX |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.50 mm) |
| Width | 0.53" (13.40 mm) |
| Depth | 1.65" (41.80 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
FAQ
What type of cabling does this SFP+ module support?
This SFP+ module supports standard twisted pair Ethernet cabling, specifically Category 6A or better copper cables. It uses 10GBase-TX technology to deliver 10 Gigabit Ethernet performance over copper media up to 100 meters, making it compatible with existing structured cabling infrastructure in many environments.
What is the maximum data transfer rate of this transceiver?
The Ortronics 7G17A03130-A SFP+ module delivers a maximum data transfer rate of 10 Gbit/s using 10 Gigabit Ethernet technology. This provides ten times the throughput of standard Gigabit Ethernet, supporting bandwidth-intensive applications and high-speed network connections between switches, servers, and storage systems.
Is this SFP+ module compatible with my existing network equipment?
This SFP+ module is designed for compatibility with Lenovo networking equipment that supports SFP+ form factor transceivers. It uses standard 10GBase-TX technology over RJ-45 connectors, which is widely supported by modern switches and network interface cards. Always verify specific compatibility with your equipment manufacturer before deployment.
