Ortronics 7427-2-A Omnitron XFP Module - 10GBase-ER LC Duplex Single-mode 40 km Optical Transceiver
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This XFP transceiver leverages 10GBase-ER technology to enable 10 Gbps Ethernet over single-mode fiber, supporting distances up to 40 km. It uses an LC duplex interface for secure fiber connections and is built for durability with minimal signal loss.
The module operates on a single wavelength of light, typical for long-reach single-mode applications, and is compliant with industry standards for 10 Gigabit Ethernet. It is environmentally friendly and meets Restriction of Hazardous Substances (RoHS) requirements.
Key Product Advantages
The Ortronics Omnitron XFP Module offers extended reach and high-speed connectivity for demanding network environments. Its design prioritizes reliability and performance in optical infrastructure.
Long-Distance Performance
Supports data transmission up to 40 km, ideal for connecting geographically dispersed network segments without signal degradation.
- 40 km maximum distance
- Single-mode fiber optimization
- Minimal signal loss
High-Speed Connectivity
Delivers 10 Gbps data transfer rates using 10GBase-ER technology, ensuring fast and efficient network throughput for data-intensive applications.
- 10 Gbit/s maximum rate
- 10 Gigabit Ethernet technology
- Optical fiber media support
Deployment / Use Cases
This XFP module is suited for optical network and data networking deployments where long-distance, high-speed fiber connections are required. It enables scalable and flexible network expansion in enterprise, data center, and service provider environments.
Common use cases include backbone links between buildings or campuses, connections to remote data centers, and high-capacity uplinks in network aggregation points. Its compatibility with standard XFP ports allows for easy integration into existing network infrastructure.
Enterprise Backbone Links
Connect network switches across large campuses or between buildings using single-mode fiber for reliable, high-bandwidth backbone connections.
Data Center Interconnects
Enable fast data transfers between data centers or within large facilities, supporting 10 Gbps speeds over distances up to 40 km.
Physical Profile
The module has a compact design with dimensions of 0.33" (8.40 mm) in height, 0.64" (16.30 mm) in width, and 3.07" (78 mm) in depth. This small form factor allows for high-density installations in networking equipment without occupying excessive space.
- Width
- 0.64" (16.30 mm)
- Depth
- 3.07" (78 mm)
- Height
- 0.33" (8.40 mm)
Highlights
- XFP format optical transceiver for 10 Gigabit Ethernet networks
- 10GBase-ER technology supporting 10 Gbps data transfer rates
- LC duplex connector for secure single-mode fiber connections
- Maximum reach of 40 km (24.85 miles) over optical fiber
- Single-mode fiber support for long-distance data transmission
- Hot-pluggable design for easy installation and maintenance
- Environmentally friendly with RoHS compliance
- Compact dimensions for high-density deployment
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | 7427-2-A |
| Brand Name | Approved Networks |
| Product Name | Omnitron XFP Module |
| Product Type | XFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-ER Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-ER |
| Maximum Distance Supported | 40 km (24.85 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.40 mm) |
| Width | 0.64" (16.30 mm) |
| Depth | 3.07" (78 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
FAQ
What type of connector does this XFP module use?
This XFP module uses an LC duplex connector, which is a standard interface for single-mode fiber optic connections. The LC connector provides a secure and reliable fit, minimizing signal loss and ensuring stable performance in optical networking environments.
What is the maximum distance supported by this transceiver?
The transceiver supports a maximum distance of 40 kilometers (approximately 24.85 miles) over single-mode fiber optic cable. This extended reach makes it suitable for long-distance network links, such as connections between buildings, campuses, or data centers.
What network technology does this module support?
This module supports 10GBase-ER technology, which is a 10 Gigabit Ethernet standard for extended reach over single-mode fiber. It operates at a data transfer rate of 10 Gbps and is designed for high-speed optical networking applications.
Is this XFP module compatible with multimode fiber?
No, this XFP module is designed for single-mode fiber only. Single-mode fiber uses a single wavelength of light to carry data over long distances with minimal signal loss, making it ideal for the 40 km reach supported by this module. For multimode applications, a different transceiver would be required.
