Ortronics PAN-SFP-PLUS-BXD-A Palo SFP+ Module - 10GbE BX LC Duplex Single-mode 20 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ transceiver operates on the 10GBase-BX standard, which utilizes bidirectional transmission over a single strand of single-mode fiber. The module features one LC duplex port, providing a straightforward plug-and-play integration into compatible SFP+ slots on network equipment. Its 10 Gbit/s maximum data transfer rate ensures efficient handling of data-intensive tasks such as server-to-server links, storage area networks, and backbone connections.
The module's single-mode fiber compatibility allows for long-distance transmission with high signal integrity, making it suitable for campus networks, metropolitan area networks, and data center interconnects. Its design adheres to industry-standard SFP+ mechanical and electrical specifications, ensuring broad compatibility with a wide range of networking hardware from major vendors.
Key Product Advantages
The Ortronics Palo SFP+ Module offers several distinct advantages for network architects and IT managers seeking reliable, high-performance fiber connectivity. Its 10GBase-BX technology optimizes fiber utilization by enabling bidirectional communication over a single fiber strand, reducing cabling costs and complexity while maintaining full 10GbE performance.
Extended Reach with Single-mode Fiber
Supports distances up to 20 kilometers, ideal for connecting geographically dispersed network segments without signal boosters or repeaters.
- Minimal signal loss over long distances
- Suitable for campus and metro networks
High-Speed Data Transfer
Delivers 10 Gbps throughput, ensuring smooth data flow for bandwidth-intensive applications like video streaming, large file transfers, and virtualized environments.
Standardized Compatibility
Built to SFP+ MSA specifications, ensuring interoperability with a wide array of switches, routers, and network interface cards from leading manufacturers.
Deployment / Use Cases
This SFP+ module is tailored for scenarios where high-speed, long-distance fiber links are essential. It serves as a critical component in modern network infrastructure, enabling seamless connectivity between core network devices across extended physical separations.
Common deployment environments include data center interconnects, where it links top-of-rack switches to aggregation layers; enterprise campus networks, connecting buildings across a large site; and telecommunications networks, providing backhaul links for service providers. Its 10GBase-BX technology is particularly valuable in fiber-constrained installations, as it maximizes existing fiber plant efficiency.
Data Center Interconnects
Connect servers and storage arrays across data hall segments with high-bandwidth, low-latency links that support virtualization and cloud workloads.
Enterprise Backbone Links
Establish reliable connections between network distribution layers in large office complexes or educational campuses, ensuring consistent performance for user access and applications.
Physical Profile
The module features a compact, industry-standard SFP+ form factor with dimensions of 0.50" (12.80 mm) in height, 0.54" (13.70 mm) in width, and 2.23" (56.60 mm) in depth. This small footprint allows for high-density deployment in switch chassis and modular networking equipment, maximizing port utilization without sacrificing performance. The robust construction ensures reliable operation in typical data center and enterprise environments.
- Width
- 0.54" (13.70 mm)
- Depth
- 2.23" (56.60 mm)
- Height
- 0.50" (12.80 mm)
Highlights
- 10 Gigabit Ethernet SFP+ optical transceiver for high-speed data networking
- 10GBase-BX technology supports bidirectional transmission over single-mode fiber
- LC duplex connector interface for standard fiber optic cabling
- Maximum reach of 20 kilometers (12.43 miles) for long-distance links
- Hot-pluggable design for easy installation and maintenance without downtime
- Single-mode fiber compatibility ensures low signal loss over extended distances
- Maximum data transfer rate of 10 Gbit/s for bandwidth-intensive applications
- RoHS compliant and environmentally friendly manufacturing
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | PAN-SFP-PLUS-BXD-A |
| Brand Name | Approved Networks |
| Product Name | Palo SFP+ Module |
| Product Type | SFP+ |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 10GBase-BX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-BX |
| Maximum Distance Supported | 20 km (12.43 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.50" (12.80 mm) |
| Width | 0.54" (13.70 mm) |
| Depth | 2.23" (56.60 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
FAQ
What is the maximum distance this SFP+ module supports?
The Ortronics PAN-SFP-PLUS-BXD-A Palo SFP+ Module supports a maximum distance of 20 kilometers (approximately 12.43 miles) over single-mode fiber. This extended reach makes it suitable for connecting network equipment across large campuses, between data centers, or in metropolitan area networks without requiring intermediate signal regeneration.
What type of fiber and connector does this module use?
This module is designed for use with single-mode fiber optic cables and features an LC duplex connector interface. The LC connector is a small form-factor connector widely used in high-density networking environments, providing reliable optical coupling for 10GBase-BX bidirectional transmission over a single fiber strand.
What is 10GBase-BX technology and how does it work?
10GBase-BX is a Ethernet standard that enables 10 Gigabit Ethernet transmission over single-mode fiber using bidirectional communication. It utilizes different wavelengths for transmit and receive signals on the same fiber strand, effectively doubling the capacity of the fiber plant. This technology reduces cabling requirements and costs while maintaining full 10 Gbps performance, making it ideal for fiber-constrained installations.
Is this SFP+ module hot-pluggable?
Yes, this SFP+ module is hot-pluggable, meaning it can be inserted or removed from a compatible SFP+ port without powering down the networking equipment. This feature allows for easy installation, replacement, or upgrades during network maintenance windows without causing service interruptions, enhancing operational flexibility in live environments.
