Ortronics NTSFP-LX-40-A Red Lion SFP Module - LC Duplex 1000Base-EX Singlemode 40 km Gigabit Ethernet Fiber Transceiver
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP module leverages 1000Base-EX network technology, which is optimized for long-wavelength (1310 nm) transmission over singlemode fiber. The LC duplex interface ensures precise optical alignment and low insertion loss, critical for maintaining signal integrity over the supported 40 km reach. The module operates at a consistent 1 Gbit/s data rate, aligning with Gigabit Ethernet standards for seamless integration into existing network architectures.
The transceiver is designed for hot-pluggable installation, allowing for easy deployment and maintenance without disrupting network operations. It supports digital diagnostics monitoring (DDM) capabilities, enabling real-time performance tracking of parameters such as optical power, temperature, and voltage. This feature enhances network management by providing visibility into module health and link performance, aiding in proactive maintenance and troubleshooting.
Key Product Advantages
The Ortronics NTSFP-LX-40-A offers distinct advantages for network professionals seeking reliable, long-distance fiber connectivity. Its 40 km reach capability reduces the need for intermediate repeaters or additional networking equipment, simplifying infrastructure and lowering total cost of ownership. The module's compliance with industry-standard SFP specifications ensures interoperability with a wide range of networking hardware from major vendors.
Extended Reach Performance
With support for distances up to 40 km, this module enables direct connections between geographically dispersed sites, ideal for campus networks, metropolitan area networks (MANs), and data center interconnects.
- Eliminates need for signal boosters
- Maintains high signal integrity over long runs
- Reduces latency in backbone links
Robust Compatibility
Designed to work with Ortronics Red Lion and other compatible networking platforms, this SFP module undergoes rigorous testing to ensure reliable performance in diverse network environments.
- Hot-pluggable for easy installation
- Low power consumption
- RoHS compliant for environmental safety
Deployment / Use Cases
This SFP module is well-suited for deployments requiring high-speed, long-distance fiber optic connections. In enterprise networks, it can link separate buildings within a campus, providing Gigabit Ethernet backbone connectivity that supports data-intensive applications like video conferencing, large file transfers, and virtual desktop infrastructure (VDI).
For data center operators, the module facilitates inter-rack or inter-data center connections, enabling efficient server-to-server communication and storage area network (SAN) extensions. Its singlemode fiber compatibility makes it appropriate for service provider networks, where it can be used in access or aggregation layers to deliver broadband services to remote locations. Additionally, the module supports audio/video transmission applications, making it useful for broadcast and media production environments that require high-bandwidth, low-latency links over extended distances.
Physical Profile
The Ortronics NTSFP-LX-40-A features a compact design with dimensions of 0.33 inches in height, 0.53 inches in width, and 2.23 inches in depth (8.50 mm x 13.40 mm x 56.65 mm). This small form factor allows for high-density installations in network switches and routers, maximizing port utilization without sacrificing performance. The module's sturdy construction ensures durability in various operating conditions, from controlled data center environments to industrial settings.
- Width
- 0.53" (13.40 mm)
- Depth
- 2.23" (56.65 mm)
- Height
- 0.33" (8.50 mm)
Highlights
- SFP module with LC duplex connector for singlemode fiber optic networks
- Supports 1000Base-EX technology for Gigabit Ethernet at 1 Gbit/s data transfer rate
- Maximum reach of 40 km (24.85 miles) for long-distance connectivity
- Hot-pluggable design for easy installation and maintenance without network downtime
- Digital diagnostics monitoring (DDM) for real-time performance tracking
- Compatible with Ortronics Red Lion and other SFP-supported networking platforms
- RoHS compliant and environmentally friendly
- Lifetime limited warranty for long-term reliability assurance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | NTSFP-LX-40-A |
| Brand Name | Approved Networks |
| Product Name | Red Lion SFP Module |
| Product Type | SFP |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 1000Base-EX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-EX |
| Maximum Distance Supported | 40 km (24.85 Mile) |
| Maximum Data Transfer Rate | 1 Gbit/s |
| Physical Characteristics | |
| Height | 0.33" (8.50 mm) |
| Width | 0.53" (13.40 mm) |
| Depth | 2.23" (56.65 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of fiber optic cable is compatible with this SFP module?
This SFP module is designed for use with singlemode fiber optic cables. Singlemode fiber supports longer distances and higher bandwidth compared to multimode fiber, making it ideal for the 40 km reach capability of this module. Ensure your fiber infrastructure uses LC duplex connectors to match the module's interface.
What is the maximum data transfer rate supported by this module?
The Ortronics NTSFP-LX-40-A supports a maximum data transfer rate of 1 Gbit/s, which aligns with Gigabit Ethernet standards. This speed is sufficient for high-bandwidth applications such as data backups, video streaming, and enterprise network traffic, providing reliable performance over its 40 km distance.
Does this SFP module support digital diagnostics monitoring (DDM)?
Yes, this SFP module includes digital diagnostics monitoring (DDM) capabilities. DDM allows network administrators to monitor real-time parameters like optical power, temperature, and voltage, enabling proactive maintenance and troubleshooting. This feature enhances network reliability by providing visibility into module performance and health.
What is the warranty coverage for this SFP module?
This SFP module comes with a lifetime limited warranty. This warranty covers defects in materials and workmanship for the duration of the product's life, offering long-term assurance and support. It reflects the manufacturer's confidence in the module's durability and performance in networking environments.
