Aruba JL724B#AKM CX 6200F 24G 4SFP+ Switch - 24-Port Managed Gigabit Layer 3 with PoE & 10Gb Uplinks
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates at Layer 3, providing IP routing capabilities that enhance network segmentation, performance, and management beyond basic Layer 2 switching. Its switching fabric supports wire-speed throughput across all ports, ensuring low-latency forwarding for data, voice, and video traffic. The four SFP+ expansion slots accept 10GbE optical or DAC modules, offering flexible uplink options for high-bandwidth aggregation or fiber backbone connections.
Power over Ethernet (PoE) support on RJ-45 ports allows direct powering of compatible devices like IP phones, wireless access points, and security cameras, simplifying deployments and reducing cabling. The integrated power supply accepts 120-230V AC input and consumes a maximum of 59 watts, contributing to energy-efficient operation. Comprehensive management is enabled through CLI, Web GUI, and support for protocols like SNMP, LLDP, and sFlow for network visibility and control.
Key Product Advantages
The Aruba CX 6200F combines high port density, advanced feature sets, and reliable hardware design to address core networking demands in business and campus settings.
Scalable Uplink Flexibility
Four SFP+ slots provide 10 Gigabit uplink capacity, enabling high-speed connections to network cores, storage arrays, or other switches without bottlenecking aggregated traffic from the 24 Gigabit downlink ports.
- Supports 10GBase-X fiber or DAC modules
- Future-proofs network backbone expansion
- Reduces oversubscription in stacked or aggregated topologies
Unified Management & Security
Aruba CX OS delivers a consistent management experience with built-in automation, role-based access, and integrated network analytics. Layer 3 routing supports VLANs, QoS, and ACLs for traffic segmentation and policy enforcement.
- Single OS across Aruba CX switches
- Dynamic segmentation for IoT and user groups
- Centralized policy management via Aruba Central (optional)
PoE-Powered Deployment Simplicity
PoE support on Gigabit Ethernet ports eliminates separate power supplies for connected devices, reducing installation time, cabling clutter, and points of failure in IP telephony and wireless deployments.
- Powers standards-compliant PoE/PoE+/UPoE devices
- Simplifies ceiling or wall-mounted AP and camera installs
- Integrates with power management and monitoring tools
Deployment / Use Cases
This switch is designed for roles requiring reliable access-layer switching with growth capacity and advanced traffic handling. Its 24-port base with PoE makes it ideal for connecting end-user devices in office floors, classrooms, or retail spaces, while the 10Gb uplinks ensure smooth backhaul to distribution or core layers.
In server room or small data center contexts, it can serve as a top-of-rack switch for rack-mounted servers and storage, leveraging Layer 3 features for inter-VLAN routing and low-latency East-West traffic. For converged networks, PoE capabilities support unified infrastructure for voice, video, and data over a single cable plant.
Enterprise Access Layer
Deploy in wiring closets to connect desktops, IP phones, and wireless APs, with uplinks to aggregation switches. Layer 3 features enable local routing between departmental VLANs.
Mid-Size Business Core
Use as a compact core switch for smaller networks, routing between multiple VLANs and providing 10Gb uplinks to servers, storage, and internet gateways.
Physical Profile
The switch features a standard 1U rack-mountable chassis with a black finish, designed for installation in 19-inch equipment racks. Its compact depth of 11.20 inches allows fitting in shallow cabinets or enclosed racks. Front-panel layout includes all 24 RJ-45 ports, four SFP+ slots, management ports, and status LEDs for at-a-glance monitoring. The built-in power supply and quiet fan assembly support continuous operation in controlled office or data center environments.
- Width
- 17.42" (442.50 mm)
- Depth
- 11.20" (284.50 mm)
- Height
- 1.72" (43.70 mm)
- Weight
- 8.31 lb (3770 g)
Highlights
- 24 Gigabit Ethernet ports for high-density device connectivity
- 4 SFP+ slots supporting 10 Gigabit uplinks for backbone aggregation
- Layer 3 switching with IP routing for advanced network segmentation
- PoE support on RJ-45 ports to power IP phones, APs, and cameras
- Managed via Aruba CX OS with CLI, Web GUI, and SNMP
- Rack-mountable 1U form factor for standard 19-inch installations
- Dual-voltage power supply (120-230V AC) with 59W max consumption
- Comprehensive IEEE standards support for interoperability and security
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | JL724B#AKM |
| Brand Name | Aruba |
| Product Series | CX 6200 |
| Product Model | CX6200F |
| Product Name | CX 6200F 24G 4SFP+ Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network Port,4 x 10 Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP |
| Shared SFP Slot | Yes |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3,IEEE 802.3bt,IEEE 802.3at,IEEE 802.3az,IEEE 802.3ad,IEEE 802.1s,IEEE 802.1D,IEEE 802.1w,IEEE 802.1ab,IEEE 802.1Q,IEEE 802.1v,IEEE 802.1x,IEEE 802.1ae,IEEE 802.3af,IEEE 802.1ak,IEEE 802.1AX,IEEE 802.1t,IEEE 802.3z |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply |
| Power Consumption | 59 W |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Height | 1.72" (43.70 mm) |
| Width | 17.42" (442.50 mm) |
| Depth | 11.20" (284.50 mm) |
| Weight (Approximate) | 8.31 lb (3770 g) |
User Manual
FAQ
What are the main port configurations on this Aruba switch?
This switch provides 24 Gigabit Ethernet RJ-45 ports for connecting end devices and four SFP+ expansion slots for 10 Gigabit uplinks. The RJ-45 ports support 10/100/1000 Mbps speeds over twisted pair cabling, while the SFP+ slots accept optical or DAC modules for 10GBase-X fiber or copper connections.
Does this switch support Power over Ethernet (PoE)?
Yes, the switch includes PoE support on its RJ-45 ports, compliant with IEEE 802.3af/at/bt standards. This allows it to deliver power to compatible devices like IP phones, wireless access points, and security cameras, simplifying installations by eliminating separate power adapters.
What is the significance of Layer 3 switching on this model?
Layer 3 switching enables IP routing between VLANs and subnets directly at the switch level, improving network performance and reducing reliance on a separate router for inter-VLAN traffic. It supports features like static routing, ACLs, and QoS for advanced traffic management and segmentation in business networks.
How many uplink ports are available, and what speeds do they support?
There are four uplink ports provided via SFP+ slots, each supporting 10 Gigabit Ethernet speeds. These uplinks are used for high-bandwidth connections to core switches, servers, or storage, ensuring aggregated traffic from the 24 downlink ports does not create bottlenecks.
Is this switch manageable, and what management options are included?
Yes, it is a fully manageable switch. Management options include a command-line interface (CLI), web-based graphical interface, and support for SNMP, LLDP, and sFlow for monitoring. It runs Aruba CX OS, which provides consistent management features across the CX series and supports automation and cloud integration.
What are the physical dimensions and rack mounting details?
The switch measures 1.72 inches high, 17.42 inches wide, and 11.20 inches deep, fitting a standard 1U rack space in 19-inch equipment racks. It includes rack-mount ears for secure installation and has a weight of approximately 8.31 pounds, making it suitable for deployment in wiring closets or data centers.
What uplink, SFP, fiber, or media support detail is listed?
The warranty or support detail listed is Yes, giving buyers a clearer picture of expected coverage after purchase.
Does the product support PoE or wireless networking?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
