Aruba JL686B#B2E Instant On 1930 48G Class4 PoE Switch - 48 Ports - 4 SFP+ Uplinks - 370W PoE Budget - Smart Managed
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Layer 2 switch supports a comprehensive suite of networking standards, including IEEE 802.3af/at for PoE, 802.1Q for VLANs, and 802.1x for network access control. It provides full wire-speed switching on all ports, supporting 10/100/1000Base-T copper and 10GBase-X fiber connections via the SFP+ slots for high-performance uplinks.
The integrated 370-watt PoE budget efficiently powers connected devices, while the dual input voltage (120/230 V AC) offers deployment flexibility. Advanced features like Auto Denial of Service (DoS) prevention and energy-efficient Ethernet (802.3az) contribute to network security and reduced operational costs.
This section brings together practical product details such as Features, Total Number of Network Ports, Network (RJ-45), Uplink Port, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Aruba Instant On 1930 switch stands out with its balanced combination of port density, PoE power, and management simplicity. Its smart managed interface offers essential configuration and monitoring tools without the complexity of fully managed switches, making it accessible for IT generalists while providing the control needed for reliable network operations.
High-Density PoE+ Ready
With 48 PoE+ ports and a 370W budget, this switch can power an entire suite of PoE devices simultaneously, simplifying cabling and reducing the need for additional power injectors or outlets near endpoints.
Flexible High-Speed Uplinks
The four SFP+ slots support 1G or 10G fiber or DAC connections, providing scalable bandwidth for aggregating traffic to core switches or servers, future-proofing your network infrastructure.
Versatile Deployment Options
Beyond standard 1U rack mounting, the switch can be installed on a wall, placed on a tabletop, or mounted in a cabinet, offering adaptability for space-constrained or unconventional IT environments.
Deployment / Use Cases
This switch is engineered for environments requiring reliable, high-density connectivity with integrated power delivery. It serves as an excellent access layer switch for office networks, connecting and powering employee workstations, IP phones, and wireless access points across multiple floors or departments.
In retail or education settings, it can support point-of-sale systems, digital signage, and surveillance cameras. For small to medium-sized businesses, it provides a cost-effective core switch solution when combined with its high-speed uplinks, handling inter-VLAN routing and server connectivity with ease.
This section brings together practical product details such as Features, Total Number of Network Ports, Network (RJ-45), Uplink Port, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
The switch features a compact, standard 1U rack-mountable design with dimensions of 1.73" (H) x 17.42" (W) x 12.70" (D), fitting seamlessly into most server racks. Its solid metal construction ensures durability, while the multiple mounting options provide installation flexibility for various scenarios. Weighing approximately 10.12 lb, it is manageable for a single technician to install.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.73" (43.90 mm), 17.42" (442.50 mm), 12.70" (322.60 mm), 10.12 lb (4590 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.42" (442.50 mm)
- Depth
- 12.70" (322.60 mm)
- Height
- 1.73" (43.90 mm)
- Weight
- 10.12 lb (4590 g)
Highlights
- 48 Gigabit Ethernet PoE+ ports for high-density device connectivity.
- 4 SFP+ uplink slots supporting 1G/10G fiber or DAC connections.
- 370W total PoE budget to power IP phones, APs, and cameras.
- Smart managed interface for VLANs, QoS, and network monitoring.
- Layer 2 switching with comprehensive IEEE standards support.
- 1U rack-mountable design with wall/table/cabinet mounting options.
- Energy Efficient Ethernet (EEE) reduces power consumption during low activity.
- Auto Denial of Service (DoS) prevention enhances network security.
- Dual voltage input (120/230 V AC) for global deployment flexibility.
- RoHS compliant for environmentally responsible manufacturing.
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | JL686B#B2E |
| Brand Name | Aruba |
| Product Line | Instant On |
| Product Series | 1930 |
| Product Name | Instant On 1930 48G Class4 PoE 4SFP/SFP+ 370W Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Plug and Play,Energy Efficient,Auto Denial of Service (DoS) Prevention |
| Interfaces/Ports | |
| Total Number of Network Ports | 48 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet PoE+,4 x 10 Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3af,IEEE 802.3at,IEEE 802.3x,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1x,IEEE 802.3az,IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.1ab |
| Management & Protocols | |
| Manageable | Yes |
| Switch Management Type | Smart Managed |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 370 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply,AC |
| Power Consumption | 520 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable,Wall Mountable,Table Top,Cabinet Mount,Under Table |
| Height | 1.73" (43.90 mm) |
| Width | 17.42" (442.50 mm) |
| Depth | 12.70" (322.60 mm) |
| Weight (Approximate) | 10.12 lb (4590 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
How many devices can this switch power with PoE?
The switch has a 370-watt PoE budget distributed across its 48 Gigabit Ethernet ports. Each port supports the IEEE 802.3at (PoE+) standard, delivering up to 30 watts per port. This allows it to power numerous devices like IP phones, wireless access points, and security cameras simultaneously, with the exact number depending on the individual power requirements of each connected device.
What are the SFP+ uplink ports used for?
The four SFP+ uplink ports provide high-speed connectivity for linking this switch to core network switches, servers, or storage arrays. They support both 1 Gigabit and 10 Gigabit speeds using compatible SFP+ transceivers for fiber optic cables or Direct Attach Copper (DAC) cables. This enables scalable bandwidth aggregation and reduces bottlenecks in your network backbone.
Is this switch easy to manage for someone without deep networking experience?
Yes, as a smart managed switch, it offers a web-based interface that simplifies configuration of essential features like VLANs, Quality of Service (QoS), port monitoring, and PoE management. It provides more control than an unmanaged switch but avoids the complexity of CLI-based fully managed switches, making it suitable for IT generalists or small business owners.
Can this switch be mounted in a standard server rack?
Absolutely. The switch is designed for standard 1U rack mounting, with dimensions that fit typical 19-inch server racks. It includes the necessary mounting brackets. Additionally, it offers versatile installation options such as wall mounting, tabletop placement, or cabinet mounting, providing flexibility for various deployment environments.
What networking standards does this switch support?
The switch supports a wide range of IEEE standards, including 802.3af/at for PoE, 802.1Q for VLAN tagging, 802.1p for traffic prioritization, 802.1x for network access control, 802.3az for Energy Efficient Ethernet, and 802.1D/w/s for spanning tree protocols. This ensures compatibility with modern network equipment and enables features like VLAN segmentation, QoS, and enhanced security.
What is the power consumption of this switch?
The switch has a maximum power consumption of 520 watts. This includes the power used for its own operation plus the PoE budget delivered to connected devices. It supports dual input voltages (120 V AC and 230 V AC), making it suitable for use in different regions. Features like Energy Efficient Ethernet help reduce power draw during periods of low network activity.
What uplink, SFP, fiber, or media support detail is listed?
The warranty or support detail listed is Yes, giving buyers a clearer picture of expected coverage after purchase.
Does the product support PoE or wireless networking?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
