Aruba S0M87A#ABA CX 6200F 24G Class 4 PoE 4SFP+ 370W Switch - 24 Port Gigabit - 4 x 10G SFP+ - Layer 3 Managed
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates at Layer 3, providing routing between VLANs and IP subnets without requiring an external router. It supports a comprehensive set of networking standards including IEEE 802.3bt for high-power PoE, IEEE 802.3ad for link aggregation, and IEEE 802.1Q for VLAN tagging, ensuring interoperability and advanced feature support.
The four SFP+ slots offer flexible uplink options, supporting 10GBase-X fiber or DAC connections for high-speed backbone links. The switch is manageable via CLI, web interface, or network management software, allowing for granular control over configuration, monitoring, and security policies.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Uplink Port, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Aruba CX 6200F switch delivers a balanced combination of port density, PoE power, and uplink speed, making it ideal for environments requiring reliable connectivity and device powering.
High PoE Budget
With 370W of PoE budget, this switch can power multiple high-demand devices simultaneously, such as PTZ cameras, multi-radio access points, and IP phones, without needing additional power injectors.
- Supports PoE++ (802.3bt) for up to 90W per port
- Efficient power management reduces energy costs
Scalable Uplinks
The four 10G SFP+ slots provide high-speed connectivity to network cores, servers, or aggregation switches, preventing bottlenecks and supporting future bandwidth growth.
- Flexible fiber or copper uplink options
- Enables link aggregation for increased throughput
Enterprise Management
As a fully managed Layer 3 switch, it offers advanced features like QoS, ACLs, SNMP monitoring, and sFlow for detailed traffic analysis, ensuring network reliability and security.
- CLI and web-based management
- Supports network automation tools
Deployment / Use Cases
This switch is well-suited for deployments where a mix of wired connectivity, PoE device support, and high-speed uplinks are required. Its 1U rack-mountable design integrates seamlessly into standard server racks, making it a practical choice for organized IT environments.
Typical use cases include office networks supporting VoIP systems and wireless access points, retail environments with IP cameras and POS systems, and educational institutions connecting classrooms and administrative offices. The TAA compliance also makes it suitable for government and public sector procurement where regulatory requirements must be met.
Unified Office Network
Deploy as the core switch for a small to medium office, providing connectivity for desktops, printers, and IP phones while powering wireless access points for seamless mobility.
Surveillance and Security
Ideal for security installations, powering multiple high-resolution IP cameras and NVRs over PoE, with 10G uplinks ensuring smooth video streaming to monitoring stations.
Physical Profile
The switch features a compact 1U form factor with dimensions of 1.72" (H) x 17.42" (W) x 11.98" (D), designed for standard 19-inch rack mounting. Its weight of 9.68 lb ensures stable installation without excessive load on rack rails. The built-in power supply and fan assembly provide reliable operation in typical server room or wiring closet environments.
- Width
- 17.42" (442.50 mm)
- Depth
- 11.98" (304.30 mm)
- Height
- 1.72" (43.70 mm)
- Weight
- 9.68 lb (4390 g)
What's in the Box
The package includes all necessary components for immediate deployment.
Highlights
- 24 Gigabit Ethernet ports for high-density connectivity
- 4 x 10G SFP+ uplink slots for high-speed backbone links
- 370W PoE budget supports power-hungry devices like cameras and APs
- Layer 3 managed switching enables advanced routing and VLANs
- 1U rack-mountable design fits standard server racks
- Supports both twisted pair and optical fiber media
- TAA compliant for government and public sector procurement
- Built-in power supply with 120V/230V input voltage support
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | S0M87A#ABA |
| Brand Name | HPE |
| Product Series | CX 6200 |
| Product Name | CX 6200F 24G Class 4 PoE 4SFP+ 370W Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network,4 x 10Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP |
| Shared SFP Slot | Yes |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3,IEEE 802.3bt,IEEE 802.3at,IEEE 802.3az,IEEE 802.3ad,IEEE 802.1s,IEEE 802.1D,IEEE 802.1w,IEEE 802.1ab,IEEE 802.1Q,IEEE 802.1v,IEEE 802.1x,IEEE 802.1ae,IEEE 802.3af,IEEE 802.1ak,IEEE 802.1AX,IEEE 802.1t,IEEE 802.3z |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE Budget | 370 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply |
| Power Consumption | 65 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Cabinet Mount,Rack-mountable,Surface Mount |
| Height | 1.72" (43.70 mm) |
| Width | 17.42" (442.50 mm) |
| Depth | 11.98" (304.30 mm) |
| Weight (Approximate) | 9.68 lb (4390 g) |
| Miscellaneous | |
| Package Contents | CX 6200F 24G Class 4 PoE 4SFP+ 370W Switch 2 x Post Rack Kit |
| TAA Compliant | Yes |
FAQ
How many devices can this switch power with PoE?
The switch has a 370W PoE budget, which can power multiple PoE devices simultaneously. The exact number depends on the power requirements of each device; for example, it could support around 24 standard 15.4W PoE devices or fewer high-power devices like 802.3bt cameras or access points. The switch supports PoE (802.3af), PoE+ (802.3at), and PoE++ (802.3bt) standards.
What are the uplink options on this switch?
This switch includes four 10 Gigabit SFP+ uplink slots. These slots support SFP+ modules for 10GBase-X fiber connections (multimode or singlemode) or direct attach copper cables. The uplinks provide high-speed connectivity to core switches, servers, or network storage, preventing bottlenecks in aggregated traffic.
Is this switch Layer 2 or Layer 3?
This is a Layer 3 managed switch. It supports routing between VLANs and IP subnets, static routing, and dynamic routing protocols like OSPF. Layer 3 functionality allows for improved network segmentation, reduced latency for inter-VLAN traffic, and more efficient use of network resources compared to Layer 2-only switches.
What rack mounting options are available?
The switch is designed for 1U rack mounting in standard 19-inch racks. It includes two post rack kits in the package for front-mount installation. The form factor also supports cabinet mounting and surface mounting, providing flexibility for various deployment scenarios in server rooms, wiring closets, or network cabinets.
What management interfaces does this switch support?
The switch supports multiple management interfaces including a command-line interface (CLI) via console port or SSH, a web-based graphical interface (GUI), and SNMP for network management systems. This allows administrators to configure VLANs, QoS, security policies, monitor performance, and perform firmware updates remotely.
What is the power consumption of this switch?
The switch has a typical power consumption of 65 watts. This includes the power for the switch itself plus the PoE budget allocated to connected devices. The built-in power supply supports 120V and 230V AC input, making it suitable for use in North America and international regions without needing a voltage converter.
