ASRock NUC BOX-1135G7 Barebone PC - Intel Core i5-1135G7 Quad-Core - 64 GB DDR4 Max - Wi-Fi 6 - Thunderbolt 4
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At its core, the NUC BOX-1135G7 utilizes a quad-core Intel Core i5-1135G7 processor with Intel Turbo Boost Technology 2.0, reaching up to 4.20 GHz. The platform supports up to 64 GB of dual-channel DDR4-3200 memory, ensuring smooth multitasking and application responsiveness.
Integrated Intel Iris Xe Graphics provides capable visual performance for office productivity, media playback, and light graphical workloads. The system includes both Wi-Fi 6 and Bluetooth 5.2 for modern wireless connectivity, alongside dual Ethernet ports (Gigabit and 2.5 Gigabit) for wired network flexibility.
This section brings together practical product details such as Processor Type, Processor Generation, Processor Model, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
This barebone PC combines a powerful 11th Gen Intel processor with extensive connectivity in a remarkably compact chassis. The inclusion of Thunderbolt 4 offers high-speed data transfer and display capabilities, while dual Ethernet ports provide networking redundancy or segmentation options.
Modern Wireless Standards
Wi-Fi 6 (802.11ax) delivers faster wireless speeds and improved efficiency in congested environments, while Bluetooth 5.2 ensures stable connections with peripherals.
- Reduced latency
- Better range
- Lower power consumption
Flexible Storage Options
With both M.2 and SATA interfaces, users can configure storage to match performance and capacity needs, from NVMe SSDs for speed to larger SATA drives for bulk storage.
Comprehensive Video Outputs
HDMI and DisplayPort connections support multiple monitor setups, making this system suitable for productivity environments, digital signage, or control room applications.
Deployment / Use Cases
The ASRock NUC BOX-1135G7 excels in environments where space is at a premium but performance cannot be compromised. Its compact dimensions and VESA mount compatibility allow for discreet installation behind monitors, under desks, or on walls.
Ideal use cases include office workstations, digital signage players, thin client hosts, light-duty point-of-sale systems, and home theater PCs. The system's support for Windows 10 and Windows 11 ensures compatibility with current business software and security updates.
This section brings together practical product details such as Processor Type, Processor Generation, Processor Model, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
Measuring just 4.33" wide by 4.63" deep by 1.88" high (110 x 117.5 x 47.85 mm), the NUC BOX-1135G7 occupies minimal desk space. The compact box PC form factor weighs approximately 2.2 lb (1000 g), facilitating easy placement and mounting.
The included VESA mount bracket enables secure attachment to monitor backs or walls, creating clean, cable-managed installations ideal for professional environments.
- Width
- 4.33" (110 mm)
- Depth
- 4.63" (117.50 mm)
- Height
- 1.88" (47.85 mm)
- Weight
- 2.20 lb (1000 g)
What's in the Box
This barebone system ships with all necessary components for basic setup and installation.
Highlights
- 11th Gen Intel Core i5-1135G7 quad-core processor with up to 4.20 GHz turbo speed
- Supports up to 64 GB of DDR4-3200 memory for responsive multitasking
- Wi-Fi 6 (802.11ax) and Bluetooth 5.2 for modern wireless connectivity
- Dual Ethernet ports: Gigabit and 2.5 Gigabit for network flexibility
- Thunderbolt 4 port for high-speed data transfer and display connectivity
- Compact box PC form factor with VESA mount bracket included
- Windows 10 and Windows 11 operating system support
- Multiple video outputs: HDMI and DisplayPort for multi-monitor setups
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASRock, Inc |
| Manufacturer Part Number | NUC BOX-1135G7 |
| Brand Name | ASRock |
| Product Line | NUC |
| Product Model | BOX-1135G7 |
| Product Name | NUC BOX-1135G7 Fanned BOX |
| Product Type | Barebone System |
| Processor | |
| Processor Type | Core i5 |
| Processor Generation | 11th Gen |
| Processor Model | i5-1135G7 |
| Processor Core | Quad-core (4 Core) |
| Maximum Turbo Speed | 4.20 GHz |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Display & Graphics | |
| Graphics Controller Model | Iris Xe Graphics |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,2.5 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.2 |
| I/O Expansions | |
| Number of M.2 Interfaces | 1 |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 5 |
| Number of USB 3.2 Gen 2 Type-A Ports | 4 |
| Number of USB 3.2 Gen 2 Type-C Ports | 1 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| DisplayPort | Yes |
| Number of SATA Interfaces | 1 |
| Number of Thunderbolt 4 Ports | 1 |
| Operating System | |
| Operating System Supported | Windows 10,Windows 11 |
| Power Description | |
| Maximum Power Supply Wattage | 90 W |
| Physical Characteristics | |
| Form Factor | Box PC |
| Height | 1.88" (47.85 mm) |
| Width | 4.33" (110 mm) |
| Depth | 4.63" (117.50 mm) |
| Weight (Approximate) | 2.20 lb (1000 g) |
| Miscellaneous | |
| Package Contents | NUC BOX-1135G7 Fanned BOX 1 x 19V/90W Power Adapter 1 x VESA mount bracket |
User Manual
FAQ
What processor does the ASRock NUC BOX-1135G7 use?
This barebone PC features an 11th Generation Intel Core i5-1135G7 quad-core processor. This CPU operates at a base frequency with turbo boost capabilities up to 4.20 GHz, providing efficient performance for everyday computing tasks, office applications, and light multimedia workloads.
How much memory can this system support?
The NUC BOX-1135G7 supports a maximum of 64 GB of DDR4 memory running at 3200 MHz. This dual-channel memory architecture allows for smooth multitasking and responsive application performance, making the system suitable for business environments where multiple applications run simultaneously.
What wireless connectivity options are included?
The system includes both Wi-Fi 6 (802.11ax) and Bluetooth 5.2. Wi-Fi 6 provides faster wireless speeds, improved efficiency in congested networks, and better battery life for connected devices. Bluetooth 5.2 offers enhanced range and stability for wireless peripherals like keyboards, mice, and headphones.
Does this barebone PC have Thunderbolt connectivity?
Yes, the NUC BOX-1135G7 includes one Thunderbolt 4 port. Thunderbolt 4 supports high-speed data transfer up to 40 Gbps, dual 4K display output, and power delivery, making it ideal for connecting high-performance storage, docking stations, or external graphics solutions.
What operating systems are supported?
This system is compatible with both Windows 10 and Windows 11 operating systems. This dual support ensures businesses can deploy with their current Windows 10 environment while having a clear upgrade path to Windows 11 for future security updates and feature enhancements.
Can this PC be mounted behind a monitor?
Yes, the compact box PC form factor includes a VESA mount bracket in the package. This allows for secure attachment to the back of compatible monitors or walls, creating clean, space-saving installations ideal for offices, retail environments, and digital signage applications.
What processor or platform detail is listed?
This product uses the 11th Gen processor for everyday performance and multitasking.
