Asus PN41-BBF5000ATL Mini PC Barebone System - Intel Celeron N5100 Quad-Core - DDR4 - 2. 5GbE - 7x USB
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the PN41-BBF5000ATL is Intel's Celeron N5100 processor, featuring four execution cores with a base clock of 1.10 GHz and turbo frequency up to 2.80 GHz. This 11th Generation processor architecture provides improved performance per watt compared to previous generations, making it well-suited for always-on applications.
The system supports DDR4-3200 memory through standard SODIMM slots, enabling fast data access for responsive system performance. Graphics are handled by integrated Intel HD Graphics with shared system memory, capable of driving displays through HDMI and DisplayPort-over-USB-C connections.
Relevant factors for this section include Processor Type, Processor Generation, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The PN41-BBF5000ATL combines compact dimensions with modern connectivity options, making it ideal for deployment scenarios where space is at a premium but performance cannot be compromised.
Compact Form Factor
Measuring just 4.53" x 4.53" x 1.93" (115mm x 115mm x 49mm), this Mini PC occupies minimal desk or mounting space while delivering full computing capabilities.
- VESA mount compatible
- Low-profile design
- Efficient thermal management
Modern Connectivity Suite
With 2.5 Gigabit Ethernet and multiple USB 3.1 ports including Type-C with quick charge and DisplayPort output, the system supports contemporary peripherals and networking requirements.
- High-speed networking
- Multiple display support
- Fast peripheral connectivity
Platform Flexibility
As a barebone system, the PN41-BBF5000ATL allows customization of memory, storage, and operating system to match specific application requirements and budget constraints.
- DDR4 memory support
- M.2 storage compatible
- Windows 10/11 ready
Deployment / Use Cases
The compact dimensions and flexible configuration of the PN41-BBF5000ATL make it suitable for various deployment scenarios where traditional desktop systems would be impractical.
In digital signage applications, the system's small footprint allows for discreet mounting behind displays while providing sufficient processing power for content playback. For point-of-sale systems, the multiple USB ports accommodate barcode scanners, receipt printers, and payment terminals without requiring additional hubs.
Relevant factors for this section include Processor Type, Processor Generation, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Thin Client Replacement
Deploy as a compact endpoint for virtual desktop infrastructure (VDI) environments, providing local processing for enhanced user experience while maintaining centralized management.
Embedded Computing
Install in kiosks, interactive displays, or industrial control systems where reliable computing in confined spaces is required, with the flexibility to customize memory and storage.
Physical Profile
The PN41-BBF5000ATL features a compact square design measuring 4.53" (115mm) wide by 4.53" (115mm) deep by 1.93" (49mm) high. This minimal footprint allows for placement in tight spaces or mounting behind displays using optional VESA brackets. The system's efficient thermal design maintains reliable operation without requiring extensive ventilation space.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.93" (49 mm), 4.53" (115 mm), 4.53" (115 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 4.53" (115 mm)
- Depth
- 4.53" (115 mm)
- Height
- 1.93" (49 mm)
What's in the Box
The PN41-BBF5000ATL barebone system ships with the essential components needed to begin your custom build.
Package contents include PN41-BBF5000ATL Barebone System Power Adapter, PN41-BBF5000ATL Barebone System. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Celeron N5100 Quad-Core processor with 11th Generation architecture
- Compact Mini PC form factor: 4.53" x 4.53" x 1.93" (115mm x 115mm x 49mm)
- DDR4-3200 memory support for responsive system performance
- 2.5 Gigabit Ethernet for high-speed network connectivity
- 7 USB ports total including USB 3.1 Gen1 and Gen2 Type-C with quick charge
- HDMI output plus DisplayPort via USB-C for multiple display support
- Windows 10 Pro/Home and Windows 11 Pro/Home operating system support
- 65W power supply with Energy Star compliance for efficient operation
- RoHS compliant construction meeting environmental standards
- 1-year limited warranty for peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | PN41-BBF5000ATL |
| Brand Name | Asus |
| Product Series | PN41 |
| Product Model | PN41-BBF5000ATL |
| Product Name | PN41-BBF5000ATL Barebone System |
| Product Type | Barebone System |
| Processor | |
| Processor Type | Celeron |
| Processor Generation | 11th Gen |
| Processor Model | N5100 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 1.10 GHz |
| Maximum Turbo Speed | 2.80 GHz |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Display & Graphics | |
| Graphics Controller Model | HD Graphics |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 3.1 Gen 1 Ports | 4 |
| USB Type-C (Front) | Yes |
| USB Type-C Detail | 1 x USB 3.1 Gen2 Type-C(w/ quick charge), 1 x USB 3.1 Gen2 Type-C(w/ quick charge), 1 x USB 3.1 Gen2 Type-C(w/ DP output) |
| Operating System | |
| Operating System Supported | Windows 10 Pro,Windows 10 Home,Windows 11 Pro,Windows 11 Home |
| Power Description | |
| Maximum Power Supply Wattage | 65 W |
| Physical Characteristics | |
| Form Factor | Mini PC |
| Height | 1.93" (49 mm) |
| Width | 4.53" (115 mm) |
| Depth | 4.53" (115 mm) |
| Miscellaneous | |
| Package Contents | PN41-BBF5000ATL Barebone System Power Adapter |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What components do I need to add to make this barebone system operational?
To complete the PN41-BBF5000ATL barebone system, you will need to install DDR4 SODIMM memory modules, an M.2 storage drive (SSD), and an operating system such as Windows 10 or Windows 11. The system does not include these components, allowing you to customize the memory capacity, storage size, and OS version to match your specific requirements and budget.
What processor generation and model does this Mini PC use?
This system features Intel's 11th Generation Celeron N5100 processor. This quad-core CPU operates at a base frequency of 1.10 GHz with turbo boost capability up to 2.80 GHz. The 11th Generation architecture provides improved performance and power efficiency compared to previous Celeron processors, making it suitable for everyday computing tasks and light multimedia applications.
What type of memory does the PN41-BBF5000ATL support?
The system supports DDR4 SDRAM memory with a standard of DDR4-3200/PC4-25600. It uses standard SODIMM modules, allowing you to install compatible DDR4 memory of your preferred capacity. The memory slots support standard DDR4-3200 speeds, ensuring fast data access for responsive system performance in various applications.
What networking capabilities does this Mini PC offer?
The PN41-BBF5000ATL includes 2.5 Gigabit Ethernet connectivity, providing network speeds up to 2.5 Gbps for fast data transfers and responsive network applications. This represents a significant upgrade over standard Gigabit Ethernet, offering improved performance for network-intensive tasks, file transfers, and modern network environments that support higher speeds.
What display outputs are available on this system?
The system provides multiple display output options including a rear HDMI port and DisplayPort capability through one of the USB 3.1 Gen2 Type-C ports. This allows you to connect up to two displays simultaneously, with the USB-C port supporting DisplayPort output for modern monitors while also providing data transfer and quick charge functionality.
What operating systems are supported by this barebone system?
The PN41-BBF5000ATL supports Windows 10 Pro, Windows 10 Home, Windows 11 Pro, and Windows 11 Home operating systems. You will need to purchase and install your preferred Windows version separately. The system's hardware compatibility with both Windows 10 and Windows 11 ensures you can choose the operating system that best fits your application requirements and licensing preferences.
