Asus PRO ET700I W7-B-750 ExpertCenter Barebone System - Socket LGA-4677 - Intel Xeon - 1TB DDR5 - 750W PSU - Windows 11 Pro
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This barebone system establishes a high-performance foundation with its Intel W790 chipset architecture, supporting single Intel Xeon processors through the LGA-4677 socket. The memory subsystem features eight DDR5 SDRAM slots capable of supporting up to 1TB total capacity, delivering the bandwidth necessary for memory-intensive professional applications.
Storage management is handled through Serial ATA/600 and NVMe controllers, with RAID 0, 1, 5, and 10 configurations available for performance optimization and data redundancy. The platform includes two M.2 interfaces for high-speed NVMe storage alongside traditional drive bays.
Relevant factors for this section include AI-powered, Number of Processors Supported, Processor Socket, Processor Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ExpertCenter Pro ET700I delivers enterprise-ready features in a barebone format, providing IT departments and system builders with a reliable foundation for custom workstation configurations. Its balanced combination of expansion capabilities, modern connectivity, and professional certifications makes it suitable for a wide range of technical computing scenarios.
Comprehensive Connectivity
Thirteen USB ports including high-speed 20Gbps Type-C front and 10Gbps Type-C rear connections ensure compatibility with modern peripherals and storage devices.
- Dual 2.5 Gigabit Ethernet ports
- Four SATA and two SAS interfaces
- Front and rear USB Type-C with different speeds
Enterprise-Grade Expansion
Five PCIe expansion slots (four x16, one x4) provide substantial graphics and accelerator card support, while six drive bays accommodate diverse storage configurations.
- Support for multiple high-end GPUs
- Flexible storage combinations
- Room for specialized interface cards
Professional Platform Foundation
Intel W790 chipset with LGA-4677 socket establishes a stable base for Intel Xeon processors, complemented by Windows 11 Pro certification and enterprise management capabilities.
- 64-bit processing architecture
- AI-powered features
- Remote management support
Deployment / Use Cases
This barebone system serves as an ideal foundation for professional workstations across multiple industries. Its combination of processor support, memory capacity, and expansion options makes it suitable for engineering design, scientific computation, media production, and financial analysis applications where custom hardware configurations are required.
IT departments can leverage this platform for standardized workstation deployments, taking advantage of the Windows 11 Pro compatibility and enterprise management features. The system's environmental certifications and 3-year warranty provide additional confidence for business deployments where reliability and compliance are essential considerations.
Engineering & Design Workstations
Support for high-core-count Xeon processors and multiple PCIe x16 slots enables configurations with professional graphics cards for CAD, simulation, and 3D rendering applications.
Scientific & Research Computing
1TB DDR5 memory capacity and multiple storage interfaces accommodate data-intensive workloads in research, analytics, and computational science environments.
Physical Profile
The black chassis measures 21.06 inches in height, 9.06 inches in width, and 17.64 inches in depth, providing substantial internal volume for component installation while maintaining a professional appearance. At approximately 31.48 pounds, the system offers a solid foundation for workstation configurations while remaining manageable for IT deployment scenarios.
- Width
- 9.06" (230 mm)
- Depth
- 17.64" (448 mm)
- Height
- 21.06" (535 mm)
- Weight
- 31.48 lb (14280 g)
Highlights
- Supports Intel Xeon processors via LGA-4677 socket with Intel W790 chipset
- Accommodates up to 1TB of high-speed DDR5 memory across eight slots
- Includes Serial ATA/600, NVMe, and SAS storage controllers with RAID 0,1,5,10 support
- Features 13 USB ports with front 20Gbps and rear 10Gbps Type-C connections
- Provides dual 2.5 Gigabit Ethernet ports for high-speed networking
- Offers five PCIe expansion slots (4 x x16, 1 x x4) for graphics and accelerator cards
- Certified for Windows 11 Pro operating system compatibility
- Includes 750W power supply with 120V/230V AC input flexibility
- Carries Energy Star, EPEAT Bronze, and RoHS environmental certifications
- Backed by 3-year limited warranty for business deployment confidence
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | PRO ET700I W7-B-750 |
| Brand Name | Asus |
| Product Line | ExpertCenter Pro |
| Product Model | ET700I W7-B-750 |
| Product Name | ExpertCenter Pro ET700I W7-B-750 Barebone System |
| Product Type | Barebone System |
| Technical Information | |
| AI-powered | Yes |
| Processor | |
| Number of Processors Supported | 1 |
| Processor Socket | Socket LGA-4677 |
| Processor Supported | Xeon |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W790 |
| Memory | |
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 8 |
| Controllers | |
| Controller Type | Serial ATA/600,NVMe |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 5, 10 |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 6 |
| Number of External 5.25" Bays | 1 |
| Number of 3.5" Bays | 3 |
| Total Number of Expansion Slots | 5 |
| Number of PCI Express x4 Slots | 1 |
| Number of PCI Express x16 Slots | 4 |
| Number of M.2 Interfaces | 2 |
| Interfaces/Ports | |
| Total Number of USB Ports | 13 |
| USB Type-C (Front) | Yes |
| USB Type-C (Rear) | Yes |
| USB Type-C Detail | Front: 1 x USB 20 Gbps Type-C port, Rear: 1 x USB 10 Gbps Type-C port |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of SATA Interfaces | 4 |
| Number of SAS Interfaces | 2 |
| Operating System | |
| Operating System Supported | Windows 11 Pro |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Installed | 1 |
| Maximum Power Supply Wattage | 750 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Height | 21.06" (535 mm) |
| Width | 9.06" (230 mm) |
| Depth | 17.64" (448 mm) |
| Weight (Approximate) | 31.48 lb (14280 g) |
| Miscellaneous | |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What processors are compatible with this barebone system?
The system supports Intel Xeon processors through the LGA-4677 socket. This enterprise-grade processor platform is designed for high-performance computing, professional applications, and workloads requiring robust multi-core performance and advanced security features. The Intel W790 chipset provides the foundation for these processors with support for PCIe lanes, memory channels, and enterprise management capabilities.
How much memory can this system support and what type?
This barebone system supports up to 1 terabyte (TB) of DDR5 SDRAM memory across eight memory slots. DDR5 technology provides higher bandwidth and improved power efficiency compared to previous generations, making it suitable for memory-intensive applications such as virtualization, large dataset processing, and professional creative workflows. The substantial memory capacity allows for demanding workstation configurations.
What storage interfaces and configurations are available?
The system includes multiple storage interfaces: Serial ATA/600 for traditional hard drives and SSDs, NVMe for high-speed solid-state storage via two M.2 interfaces, and SAS for enterprise storage devices. RAID 0, 1, 5, and 10 configurations are supported, allowing for performance optimization, data redundancy, or a combination of both. Four SATA and two SAS interfaces provide flexibility for various storage combinations.
What expansion capabilities does this barebone system offer?
Expansion capabilities include five PCIe slots (four x16 and one x4) for graphics cards, accelerators, or specialized interface cards. The chassis provides six drive bays (one 5.25-inch and three 3.5-inch) for storage devices. Thirteen USB ports, including front and rear Type-C connections at different speeds, ensure comprehensive peripheral connectivity. Dual 2.5 Gigabit Ethernet ports support high-speed networking requirements.
What operating systems are compatible with this system?
The system is certified for Windows 11 Pro, providing a professional operating system environment with enterprise management features, security enhancements, and compatibility with business applications. This certification ensures proper driver support and system stability for professional workstation deployments where reliable operation is essential.
What power supply is included and what are the physical dimensions?
A 750-watt power supply is installed, providing sufficient power for processor, memory, storage, and expansion card configurations. The power supply accepts both 120V and 230V AC input. The black chassis measures 21.06 inches in height, 9.06 inches in width, and 17.64 inches in depth, weighing approximately 31.48 pounds. These dimensions provide substantial internal space for components while maintaining a professional appearance suitable for office environments.
