Asus PROART PA401 WOOD TG PWM BLACK ProArt PA401 Wood Edition ATX Case - Tempered Glass Panel - Wood Accents - 4 Drive Bays - 2 x 160mm PWM Fans
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The ProArt PA401 is engineered with attention to thermal management and component compatibility. It supports CPU coolers up to 160mm in height, power supplies up to 170mm in length, and graphics cards up to 315mm in length, accommodating a wide range of high-performance hardware. The case includes a dust filter to maintain internal cleanliness and features like cable clips and a cable management window to simplify building and maintenance.
Front I/O connectivity includes three USB ports: one USB 3.2 Gen 2x2 Type-C port and two USB 3.2 Gen 1 ports, along with separate audio input and output jacks and a microphone port. The window panels are made of tempered glass and are located on both the front and side, providing clear views of internal components from multiple angles.
Key Product Advantages
The ProArt PA401 stands out with its unique material combination and thoughtful design features that enhance both aesthetics and functionality. The wood and tempered glass construction offers a premium look while the pre-installed cooling and ample expansion support practical building needs.
Premium Aesthetic Design
Wood accents and dual tempered glass panels create a sophisticated appearance that complements professional workspaces or high-end gaming setups.
- Front and side tempered glass panels
- Wood material accents
- Clean, modern visual profile
Optimized Cooling Solution
Two 160mm PWM fans provide substantial airflow right out of the box, with support for additional fans in multiple sizes to tailor thermal performance.
- Pre-installed 160mm PWM fans
- Fan speed controller included
- Supports 120mm, 140mm, and 160mm fans
Practical Building Features
Cable management tools and accessible front I/O ports streamline the assembly process and daily use.
- Cable clips and management window
- Front USB 3.2 Gen 2x2 Type-C port
- Separate audio input/output jacks
Deployment / Use Cases
The Asus ProArt PA401 is well-suited for content creation workstations, high-performance gaming systems, and professional computing environments where both visual appeal and hardware capability are important. Its ATX compatibility and seven expansion slots allow for multi-GPU configurations, extensive storage arrays, or specialized add-in cards.
For creative professionals, the case's aesthetic aligns with studio environments while providing the expansion needed for video editing, 3D rendering, or audio production hardware. Enthusiast builders will appreciate the component clearance for high-end cooling solutions and graphics cards, making it ideal for overclocked systems or custom water-cooling setups.
Content Creation Workstation
Ideal for video editors, graphic designers, and 3D artists who need both powerful hardware and a professional-looking enclosure for their workspace.
High-Performance Gaming PC
Supports large graphics cards and multiple storage drives for gaming systems that require both performance and visual presentation.
Physical Profile
The ProArt PA401 measures 19.80" in height, 8.86" in width, and 16.22" in depth, with an approximate weight of 18.98 pounds. Its dimensions provide ample interior space for component installation while maintaining a footprint suitable for desk or floor placement. The tempered glass panels are securely mounted and the wood accents are integrated into the chassis design for durability. The case includes standard mounting points for ATX motherboards and features tool-less drive bay installation where applicable.
- Width
- 8.86" (225 mm)
- Depth
- 16.22" (412 mm)
- Height
- 6.30" (160 mm)
- Weight
- 18.98 lb (8610 g)
- Length
- 6.69" (170 mm)
Highlights
- ATX motherboard support with seven expansion slots
- Four total drive bays (two 2.5", two 2.5"/3.5")
- Two pre-installed 160mm PWM fans with speed controller
- Front and side tempered glass window panels
- Wood material accents for premium aesthetics
- Front I/O with USB 3.2 Gen 2x2 Type-C and audio ports
- Supports CPU coolers up to 160mm and GPUs up to 315mm
- Cable management features including clips and management window
- Dust filter included for reduced maintenance
- Dimensions: 19.80" H × 8.86" W × 16.22" D
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | PROART PA401 WOOD TG PWM BLACK |
| Brand Name | Asus |
| Product Line | ProArt |
| Product Model | PA401 |
| Product Name | ProArt PA401 Wood Edition - Tempered Glass Panel |
| Product Type | Computer Case |
| Technical Information | |
| Motherboard Supported | ATX |
| Number of Fans Supported | 2 |
| Number of Fans Installed | 2 |
| Fan Size Supported | 4.72" (120 mm),5.51" (140 mm),6.30" (160 mm) |
| Installed Fan Size | 6.30" (160 mm) |
| Installed Fan Size Details | 2 x 160mm |
| Features | Dust Filter,Fan Speed Controller,Reset Button,Cable Clip,Cable Management |
| Window Panel | Yes |
| Window Panel Location | Front,Side Panel |
| Bays | |
| Number of Internal 2.5" Bays | 2 |
| Number of Internal 2.5"/3.5" Bays | 2 |
| Number of Total Expansion Bays | 4 |
| I/O Expansions | |
| Total Number of Expansion Slots | 7 |
| Interfaces/Ports | |
| Total Number of USB Ports | 3 |
| USB Port Details | 1 x USB 3.2 Gen 2x2 Type C,2 x USB 3.2 Gen 1 |
| Front USB | Yes |
| Total Number of Audio In Ports | 1 |
| Front Audio In | Yes |
| Total Number of Audio Out Ports | 1 |
| Front Audio Out | Yes |
| Microphone | Yes |
| Physical Characteristics | |
| Product Material | Wood,Tempered Glass |
| Cooler Type | Fan Cooler |
| Maximum CPU Cooler Height | 6.30" (160 mm) |
| Maximum PSU Length | 6.69" (170 mm) |
| Maximum GPU Length | 12.40" (315 mm) |
| Height | 19.80" (503 mm) |
| Width | 8.86" (225 mm) |
| Depth | 16.22" (412 mm) |
| Weight (Approximate) | 18.98 lb (8610 g) |
User Manual
FAQ
What motherboard sizes does the Asus ProArt PA401 support?
The ProArt PA401 supports ATX motherboards, which is the standard full-size motherboard format. This provides seven expansion slots for adding graphics cards, sound cards, capture cards, or other PCIe devices. ATX compatibility ensures broad hardware support and ample space for component layout and cable routing within the case.
How many fans come pre-installed in this case?
Two 160mm PWM fans are pre-installed in the ProArt PA401. These fans provide immediate airflow for system cooling and operate quietly with PWM control for adjustable speeds. The case also supports additional fans in 120mm, 140mm, and 160mm sizes, allowing for expanded cooling configurations if needed.
What types of drive bays are available?
The case includes four total drive bays: two dedicated to 2.5" drives (typically SSDs) and two that accommodate either 2.5" or 3.5" drives (for SSDs or HDDs). This flexible storage configuration supports multiple storage devices, enabling combinations like fast NVMe/SSD boot drives with larger HDDs for data storage.
What front panel connectivity does the case offer?
The front I/O panel includes three USB ports: one USB 3.2 Gen 2x2 Type-C port for high-speed data transfer and two USB 3.2 Gen 1 ports. It also features separate 3.5mm audio input and output jacks plus a microphone port, providing convenient access for headphones, microphones, and USB devices without reaching to the rear of the case.
What are the maximum component dimensions supported?
The ProArt PA401 supports CPU coolers up to 160mm tall, power supplies up to 170mm long, and graphics cards up to 315mm long. These clearances accommodate most high-performance air coolers, standard ATX power supplies, and large gaming or workstation graphics cards, ensuring compatibility with a wide range of components.
What materials are used in the case construction?
The case features a combination of wood and tempered glass materials. Wood accents provide distinctive aesthetic appeal, while tempered glass panels on the front and side offer scratch-resistant viewing windows to showcase internal components. The tempered glass is more durable than standard acrylic and maintains clarity over time.
