Asus Q670EM-IM-A Industrial Motherboard - Intel Q670E Chipset - Socket LGA-1700 - Micro ATX - Pentium, Celeron, Core i9, Core i7, Core (90ME06I0-M0UCY0)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Chipset Manufacturer: Intel
Chipset Model: Q670E
Total Processor Supported: 1
Processor Socket: Socket LGA-1700
Processor Generation Supported: 13th Gen,12th Gen
Processor Supported: Pentium,Celeron,Core i9,Core i7,Core i5,Core i3
Number of Memory Slots: 4
Memory Form Factor: UDIMM
Maximum Memory Supported: 128 GB
Memory Speed Supported: 4400 MHz
Memory Technology: DDR5 SDRAM
Total Number of PCI Express Slots: 2
Number of PCI Express x16 Slots: 2
DisplayPort: Yes
Form Factor: Micro ATX
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
- Supports up to 125-watt Intel® 13th/12thGen processors
- 2x PCIe® x16 slots support dual graphic cards
- Four U-DIMM slots for up to 128 GB 4400 MHz DDR5
- Supports four DisplayPort™
- Seven-year longevity supply program
- Advanced I/O and connectivity features
- Wide temperature range endurance: 0-60° C
[custom-specifications]
| Specifications | |
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | 90ME06I0-M0UCY0 |
| Manufacturer Website Address | http://www.asus.com |
| Brand Name | Asus |
| Product Model | Q670EM-IM-A |
| Product Name | Q670EM-IM-A Industrial Motherboard |
| Product Type | Industrial Motherboard |
| Processor & Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | Q670E |
| Total Processor Supported | 1 |
| Processor Socket | Socket LGA-1700 |
| Processor Generation Supported | 13th Gen,12th Gen |
| Processor Supported | Pentium,Celeron,Core i9,Core i7,Core i5,Core i3 |
| Memory | |
| Number of Memory Slots | 4 |
| Memory Form Factor | UDIMM |
| Maximum Memory Supported | 128 GB |
| Memory Speed Supported | 4400 MHz |
| Memory Technology | DDR5 SDRAM |
| I/O Expansions | |
| Total Number of PCI Express Slots | 2 |
| Number of PCI Express x16 Slots | 2 |
| Interfaces/Ports | |
| DisplayPort | Yes |
| Physical Characteristics | |
| Form Factor | Micro ATX |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
[/custom-specifications]
