Asus RNUC12WSKI50000 NUC 12 Pro Barebone System - Intel Core i5-1240P 12th Gen - 64GB DDR4 - 2.5GbE - WiFi 6 - Thunderbolt 4 - VESA Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This NUC 12 Pro model is engineered with a balanced set of modern I/O and expansion capabilities. It supports up to 64GB of DDR4-3200 memory across two slots, providing ample headroom for multitasking and application performance. Storage flexibility is offered through two M.2 interfaces supporting NVMe drives and a SATA port for additional 2.5" or 3.5" drives, managed by integrated NVMe and Serial ATA controllers.
Connectivity is a standout feature, with 2.5 Gigabit Ethernet for high-speed wired networking, latest-generation wireless including WiFi 6 (802.11ax) and Bluetooth 5.3 for stable peripheral connections, and future-ready ports like dual Thunderbolt 4 for high-speed data transfer and display output. The system also includes HDMI, seven USB ports (three USB 3.2 and three USB 2.0), and an RJ-45 network port.
Relevant factors for this section include Processor Type, Processor Generation, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Asus NUC 12 Pro combines a powerful 12th Gen Intel processor with extensive connectivity in a remarkably small chassis, offering a compelling solution for environments where space is at a premium but performance requirements are not.
Modern Processor Architecture
The Intel Core i5-1240P brings 12 cores and Intel's hybrid architecture to the compact form factor, enabling efficient handling of everyday business applications, light content creation, and multitasking without the bulk of a traditional desktop.
- 12-core (Dodeca-core) design
- Up to 4.40 GHz turbo speed
- 64-bit processing support
Comprehensive Connectivity Suite
From high-speed Thunderbolt 4 ports to 2.5 Gigabit Ethernet and WiFi 6, this system ensures fast data transfers, reliable network access, and seamless peripheral integration, reducing bottlenecks in workflow.
- Dual Thunderbolt 4 for 40 Gbps data
- 2.5GbE for wired network performance
- WiFi 6 for improved wireless throughput
Flexible Deployment Options
The compact dimensions and included VESA bracket enable versatile mounting behind displays, under desks, or in confined spaces, making it suitable for digital signage, kiosks, or minimalist office setups.
- VESA mount included
- Small footprint: under 5" in width and depth
- Low 35W thermal design power
Deployment / Use Cases
The Asus NUC 12 Pro barebone system is well-suited for a range of commercial and professional scenarios where a small, quiet, and capable computing platform is required. Its balance of processing power, modern I/O, and compact design makes it adaptable to both fixed and flexible workspace configurations.
In office environments, it serves as a discreet desktop PC for general productivity, video conferencing, and departmental applications. For retail and hospitality, it can power digital signage, point-of-sale systems, or self-service kiosks, often mounted out of sight. In educational or lab settings, its small size allows for clustered deployments or integration into limited-space workstations. Home users may appreciate it as a compact media center or home office PC that minimizes desk clutter.
Office Productivity Hub
Deploy as a primary workstation for email, document editing, web browsing, and video calls, leveraging the Core i5 processor and fast connectivity for smooth daily operations.
Digital Signage & Kiosk Controller
Use in retail, corporate lobbies, or public spaces to drive displays, with VESA mounting for hidden installation and reliable performance for continuous operation.
Physical Profile
The NUC 12 Pro measures 4.41 inches wide, 4.61 inches deep, and 1.46 inches high (112 x 117 x 37 mm), making it one of the smallest capable desktop platforms available. This compact size is achieved without sacrificing critical ports or cooling, thanks to efficient thermal design with a 35W TDP.
The chassis is designed for discreet placement, and the included VESA bracket allows secure mounting to the back of compatible monitors or under desks, freeing up valuable workspace. The small footprint and low power consumption make it an environmentally conscious choice for energy-efficient deployments.
- Width
- 4.41" (112 mm)
- Depth
- 4.61" (117 mm)
- Height
- 1.46" (37 mm)
What's in the Box
The package includes the Asus NUC 12 Pro NUC12WSKi5 barebone system and a VESA mounting bracket, providing everything needed to start building a compact computing solution after adding memory, storage, and an operating system.
Highlights
- Intel Core i5-1240P 12th Gen processor with 12 cores and up to 4.40 GHz turbo speed
- Supports up to 64GB DDR4-3200 memory across two slots for multitasking performance
- Dual Thunderbolt 4 ports for high-speed data transfer and display connectivity
- 2.5 Gigabit Ethernet, WiFi 6 (802.11ax), and Bluetooth 5.3 for comprehensive networking
- Compact form factor: 4.41" x 4.61" x 1.46" (112 x 117 x 37 mm) with VESA mount included
- Flexible storage options with two M.2 interfaces (NVMe) and one SATA port
- Wide OS support: Windows 11/10, Red Hat Linux, Ubuntu 20.04 LTS
- Seven USB ports total (3x USB 3.2, 3x USB 2.0) plus HDMI for peripheral connectivity
- 35W thermal design power for energy-efficient operation
- RoHS compliant and environmentally friendly construction
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | RNUC12WSKI50000 |
| Brand Name | Asus |
| Product Line | NUC 12 Pro |
| Product Model | NUC12WSKI5 |
| Product Name | NUC 12 Pro NUC12WSKi5 Barebone System |
| Product Type | Barebone System |
| Processor | |
| Processor Type | Core i5 |
| Processor Generation | 12th Gen |
| Processor Model | i5-1240P |
| Processor Core | Dodeca-core (12 Core) |
| Maximum Turbo Speed | 4.40 GHz |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Total Number of Memory Slots | 2 |
| Intel Optane Memory Ready | No |
| Controllers | |
| Controller Type | NVMe,Serial ATA |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.3 |
| I/O Expansions | |
| Number of M.2 Interfaces | 2 |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 3.2 Ports | 3 |
| Number of Onboard USB 2.0 Ports | 3 |
| Network (RJ-45) | Yes |
| Number of SATA Interfaces | 1 |
| Number of Thunderbolt 4 Ports | 2 |
| Operating System | |
| Operating System Supported | Windows 11 Home,Windows 11 Pro,Windows 10 Home,Windows 10 IoT Enterprise,Windows 10 Pro,Red Hat Linux,Ubuntu 20.04 LTS |
| Power Description | |
| Thermal Design Power | 35 W |
| Physical Characteristics | |
| Height | 1.46" (37 mm) |
| Width | 4.41" (112 mm) |
| Depth | 4.61" (117 mm) |
| Miscellaneous | |
| Package Contents | NUC 12 Pro NUC12WSKi5 Barebone System VESA Bracket |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
What processor is in the Asus NUC 12 Pro RNUC12WSKI50000?
This barebone system features an Intel Core i5-1240P processor from the 12th Generation. It is a dodeca-core (12-core) CPU with a maximum turbo speed of 4.40 GHz, supporting 64-bit processing. This processor provides a balance of performance and efficiency for everyday computing tasks, light creative work, and business applications in a compact form factor.
How much memory can this NUC 12 Pro support?
The Asus NUC 12 Pro supports up to 64GB of DDR4 SDRAM. It has two memory slots that accept DDR4-3200/PC4-25600 modules. This capacity allows for smooth multitasking and handling of memory-intensive applications, making it suitable for office productivity, digital signage, or light development work where RAM headroom is beneficial.
What storage options are available on this barebone system?
Storage expansion is provided through two M.2 interfaces that support NVMe drives for high-speed storage, and one SATA interface for connecting traditional 2.5" or 3.5" hard drives or SSDs. The system includes NVMe and Serial ATA controllers, offering flexibility to configure storage based on speed, capacity, and budget requirements. Note that storage drives are not included with the barebone kit.
What networking and connectivity features does it include?
Connectivity is comprehensive: wired networking via 2.5 Gigabit Ethernet, wireless with WiFi 6 (IEEE 802.11ax) and Bluetooth 5.3, and high-speed ports including two Thunderbolt 4 ports, three USB 3.2 ports, three USB 2.0 ports, HDMI, and an RJ-45 network port. This suite supports fast data transfers, reliable internet access, and connection to a wide range of peripherals and displays.
Which operating systems are supported by this NUC 12 Pro?
The hardware supports multiple operating systems, including Windows 11 Home, Windows 11 Pro, Windows 10 Home, Windows 10 IoT Enterprise, Windows 10 Pro, Red Hat Linux, and Ubuntu 20.04 LTS. This broad compatibility allows deployment in diverse environments, from standard office workstations to Linux-based servers or specialized industrial applications. The operating system is not pre-installed, so users can load their preferred version.
How can I mount or install this compact system?
The Asus NUC 12 Pro is designed for versatile installation. Its small dimensions (4.41" wide x 4.61" deep x 1.46" high) allow it to fit in tight spaces. The package includes a VESA bracket, enabling secure mounting to the back of compatible monitors or under desks for a clean, space-saving setup. This makes it ideal for digital signage, kiosks, or minimalist office environments where desk space is limited.
