Asus RNUC14RVKI30000UI NUC 14 Pro Barebone System - Mini PC - Intel Core 3100U Hexa-core - 96GB DDR5 - 2x Thunderbolt 4 - Windows 11 - Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the NUC 14 Pro is the Intel Core 3 100U processor featuring six efficiency-optimized cores with a base clock of 1.20 GHz and turbo boost up to 4.70 GHz. The BGA-1744 socket platform supports Intel integrated graphics with shared DDR5 memory, providing capable visual performance for business applications and multimedia tasks.
Memory expansion is handled through two DDR5-5600 SODIMM slots supporting up to 96GB total capacity. Storage connectivity includes two M.2 slots with NVMe support for high-speed solid-state drives, ensuring rapid system responsiveness and data access.
Relevant factors for this section include AI-powered, Number of Processors Installed, Processor Socket, Processor Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The NUC 14 Pro combines modern connectivity with compact design to create a versatile barebone platform suitable for various deployment scenarios. Its balanced specification set addresses the core needs of business computing while offering expansion flexibility for future requirements.
Modern Interface Suite
Includes two Thunderbolt 4 ports for high-speed peripheral connectivity and display output, plus a 20Gbps USB 3.2 Gen2x2 Type-C port for fast data transfers.
- 5 total USB ports
- 2.5 Gigabit Ethernet
- Wi-Fi 6 wireless
Easy Deployment Features
The included VESA mount hardware allows secure attachment to monitors or mounting surfaces, while the compact dimensions minimize desk space requirements.
- VESA mount included
- Small footprint
- Lightweight design
Deployment / Use Cases
The Asus NUC 14 Pro Barebone System excels in environments where space efficiency and modern connectivity are priorities. Its compact form factor and comprehensive port selection make it suitable for office workstations, digital signage controllers, and home entertainment systems.
Business users will appreciate the Windows 11 compatibility for modern productivity applications, while the 2.5GbE networking and Thunderbolt 4 ports provide future-ready connectivity for high-speed peripherals and network storage. The system's low thermal design power and efficient operation make it ideal for always-on applications and energy-conscious deployments.
Office Workstation
Configure with memory and storage to create a responsive desktop system for productivity applications, video conferencing, and general business computing tasks.
Compact Media Center
Use the HDMI output and Thunderbolt ports to connect displays and audio equipment, creating a space-saving entertainment system with modern connectivity.
Physical Profile
The NUC 14 Pro features a sleek black chassis measuring just 4.61" wide × 4.41" deep × 1.46" high (117 × 112 × 37 mm), with a weight of approximately 1.04 pounds (470 grams). This compact design allows placement in tight spaces while maintaining adequate thermal performance through intelligent cooling design. The included VESA mount plate enables secure attachment to compatible monitor mounts or wall brackets for clean installation aesthetics.
- Width
- 4.61" (117 mm)
- Depth
- 4.41" (112 mm)
- Height
- 1.46" (37 mm)
- Weight
- 1.04 lb (470 g)
What's in the Box
The barebone system package includes all essential components for setup and deployment:
Highlights
- Intel Core 3 100U hexa-core processor with 4.70 GHz turbo boost
- Supports up to 96GB DDR5-5600 memory across two SODIMM slots
- Dual M.2 NVMe slots for high-speed storage expansion
- Two Thunderbolt 4 ports for high-speed peripheral connectivity
- 2.5 Gigabit Ethernet and Wi-Fi 6 (802.11ax) wireless networking
- Compact Mini PC form factor with VESA mount compatibility
- Windows 11 operating system support
- Comprehensive USB connectivity including 20Gbps Type-C port
- Low 25W thermal design power for efficient operation
- Three-year limited warranty with RoHS environmental compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | RNUC14RVKI30000UI |
| Brand Name | Asus |
| Product Line | NUC 14 Pro |
| Product Model | NUC14RVKi3 |
| Product Name | NUC 14 Pro Barebone System |
| Product Type | Barebone System |
| Technical Information | |
| AI-powered | Yes |
| Processor | |
| Number of Processors Installed | 1 |
| Processor Socket | Socket BGA-1744 |
| Processor Manufacturer | Intel |
| Processor Type | Core 3 |
| Processor Model | 100U |
| Processor Core | Hexa-core (6 Core) |
| Processor Speed | 1.20 GHz |
| Maximum Turbo Speed | 4.70 GHz |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Maximum Memory Supported | 96 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-5600/PC5-44800 |
| Total Number of Memory Slots | 2 |
| Controllers | |
| Controller Type | NVMe |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Memory Technology | DDR5 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.3 |
| I/O Expansions | |
| Number of M.2 Interfaces | 2 |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 5 |
| Number of USB 3.2 Gen 2 Ports | 3 |
| USB Type-C (Front) | Yes |
| USB Type-C Detail | 1 x USB 3.2 Gen2x2 Type C (20Gbps) |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of Thunderbolt 4 Ports | 2 |
| Operating System | |
| Operating System Supported | Windows 11 |
| Power Description | |
| Maximum Power Supply Wattage | 90 W |
| Thermal Design Power | 25 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Mini PC |
| Height | 1.46" (37 mm) |
| Width | 4.61" (117 mm) |
| Depth | 4.41" (112 mm) |
| Weight (Approximate) | 1.04 lb (470 g) |
| Miscellaneous | |
| Package Contents | NUC 14 Pro Barebone System Power Adapter Power Cord Warranty Card Quick Start Guide VESA Mount VESA Mount plate |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What processor does the Asus NUC 14 Pro use?
The system features an Intel Core 3 100U hexa-core processor with six efficiency cores. It operates at a base frequency of 1.20 GHz with turbo boost capability up to 4.70 GHz, providing balanced performance for business applications and multitasking scenarios while maintaining power efficiency.
How much memory can I install in this barebone system?
The NUC 14 Pro supports up to 96GB of DDR5 memory across two SODIMM slots. It uses DDR5-5600 (PC5-44800) memory technology, offering improved bandwidth and efficiency compared to previous DDR4 standards. This capacity supports demanding multitasking and application workloads in business environments.
What storage options are available?
The system includes two M.2 slots supporting NVMe solid-state drives. This interface provides significantly faster data transfer rates compared to SATA connections, enabling quick system boot times, rapid application loading, and efficient handling of large files. The dual slots allow for storage configuration flexibility.
What connectivity ports does the NUC 14 Pro include?
Connectivity includes five USB ports (three USB 3.2 Gen 2, one USB 3.2 Gen2x2 Type-C at 20Gbps), two Thunderbolt 4 ports, HDMI output, 2.5 Gigabit Ethernet, and wireless capabilities with Wi-Fi 6 (802.11ax) and Bluetooth 5.3. This comprehensive port selection supports modern peripherals and high-speed data transfers.
Is this system compatible with Windows 11?
Yes, the Asus NUC 14 Pro Barebone System supports Windows 11 installation. The Intel Core 3 processor platform meets Windows 11 system requirements, providing a modern operating system foundation for business applications, security features, and productivity tools in office and professional environments.
Can I mount this Mini PC behind a monitor?
Yes, the package includes a VESA mount and mounting plate that allows secure attachment to compatible monitor mounts or wall brackets. The compact dimensions of 4.61" × 4.41" × 1.46" and lightweight design at 1.04 pounds make it ideal for space-saving installations where desk space is limited or clean aesthetics are desired.
