Asus ROG Strix 1200W Power Supply - Internal - 120 V AC, 230 V AC Input - 3.3 V, 5 V, 12 V, -12 V, 5 V SB Output - 1.20 kW - 1 +12V - (ROG-STRIX-1200G-AURA-GAMING)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Strix 1200W Power Supply
- 1 x Power Cord
- 1 x Motherboard Power Cable (600mm)
- 2 x CPU Cable (650mm)
- 1 x PCI-E Gen 5 16-pin Cable (675 mm)
- 1 x PCI-E (16-pin to 8-pin-8-pin) Cable (675 mm)
- 2 x PCI-E 1-to-1 Cable (675mm)
- 1 x SATA 1-to-2 Cable (400+120mm)
- 1 x SATA 1-to-3 Cable (400+120+120mm)
- 1 x Peripheral 1-to-4 Cable (400+150+150+150mm)
- 1 x Addressable RGB Cable (800mm)
- 1 x User Manual
Specification Compliance: ATX 3.0
Number of Fans: 1
Fan Bearing Type: Dual Ball Fan Bearing
Fan Diameter: 135 mm (5.31")
Features: RGB Lighting,On/Off Switch
Input Voltage: 120 V AC,230 V AC
Number of +12V Rails: 1
Output Voltage: 3.3 V,5 V,12 V,-12 V,5 V SB
Output Voltage Detail: 3.3 V @ 22 A,5 V @ 22 A,-12 V @ 0.3 A,5 V SB @ 3 A,12 V @ 100 A
Output Current: 22 A,100 A,300 mA,3 A
Output Power: 1.20 kW
Number of SATA Power Connectors: 5
PCI Express Connector: Yes
PCI Express Version: 5.0
Number of (4+4 pin) CPU Power Connectors: 2
Form Factor: Internal
Height: 3.39" (86 mm)
Width: 5.91" (150 mm)
Depth: 7.09" (180 mm)
Weight (Approximate): 7.12 lb (3230 g)
Package Contents:
Energy Efficiency Certification: 80 Plus Gold
Limited Warranty: 10 Year
[custom-specifications]
| Specifications | |
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | ROG-STRIX-1200G-AURA-GAMING |
| Manufacturer Website Address | http://www.asus.com |
| Brand Name | Asus ROG |
| Product Line | Strix |
| Product Name | Strix 1200W Power Supply |
| Product Type | Power Supply |
| Technical Information | |
| Specification Compliance | ATX 3.0 |
| Number of Fans | 1 |
| Fan Bearing Type | Dual Ball Fan Bearing |
| Fan Diameter | 135 mm (5.31") |
| Features | RGB Lighting,On/Off Switch |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of +12V Rails | 1 |
| Output Voltage | 3.3 V,5 V,12 V,-12 V,5 V SB |
| Output Voltage Detail | 3.3 V @ 22 A,5 V @ 22 A,-12 V @ 0.3 A,5 V SB @ 3 A,12 V @ 100 A |
| Output Current | 22 A,100 A,300 mA,3 A |
| Output Power | 1.20 kW |
| Interfaces/Ports | |
| Number of SATA Power Connectors | 5 |
| PCI Express Connector | Yes |
| PCI Express Version | 5.0 |
| Number of (4+4 pin) CPU Power Connectors | 2 |
| Physical Characteristics | |
| Form Factor | Internal |
| Height | 3.39" (86 mm) |
| Width | 5.91" (150 mm) |
| Depth | 7.09" (180 mm) |
| Weight (Approximate) | 7.12 lb (3230 g) |
| Miscellaneous | |
| Package Contents |
|
| Energy Efficiency Certification | 80 Plus Gold |
| Warranty | |
| Limited Warranty | 10 Year |
[/custom-specifications]
