Aten VE814A-ATA HDMI HDBaseT Extender - Dual Output 4K@100m - 492 ft Range - Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This extender delivers pristine 4K video at a maximum resolution of 4096 x 2160 pixels, ensuring sharp detail and vibrant color reproduction for presentations, media playback, and live feeds. It supports a single HDMI input on the transmitter and provides three HDMI outputs on the receiver, enabling simultaneous distribution to multiple displays without signal degradation.
The unit incorporates four RJ-45 network ports to facilitate extended control and integration capabilities, including IR pass-through and RS-232 serial communication for system automation. All video, audio, and control data is transmitted over a single Cat6a cable, simplifying cable management and reducing installation complexity compared to traditional HDMI over fiber or coaxial solutions.
Relevant factors for this section include Connectivity Technology, Number of Input Devices Supported, Number of Output Devices Supported, Graphics Modes. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The VE814A-ATA eliminates the limitations of standard HDMI cables by enabling reliable long-range 4K video distribution over cost-effective structured cabling. Its dual-output capability allows one source to drive multiple displays seamlessly, perfect for boardrooms or retail environments where consistent content across screens is critical.
Extended Reach with Clarity
Transmit 4K signals up to 492 feet without compressors or repeaters, maintaining full bandwidth and zero latency for real-time applications.
- No signal compression
- Supports 4K@60Hz
- HDCP 2.2 compliant
Simplified Installation
Utilize existing Cat6a infrastructure for video, audio, power, and control, reducing cable clutter and installation time.
- Single cable for all signals
- Standard RJ-45 connectors
- Plug-and-play setup
Deployment / Use Cases
This extender is engineered for professional AV environments where distance, signal integrity, and multi-display support are paramount. Its robust design and flexible connectivity make it suitable for a wide range of installation scenarios.
In corporate settings, deploy it in conference rooms to extend laptop or media player signals to large displays or video walls across the room. For digital signage networks, use it to distribute content from a central media server to multiple screens throughout a facility, ensuring synchronized playback without individual sources at each display.
Conference & Training Rooms
Extend presenter laptop feeds to wall-mounted displays or projectors located far from the lectern, with support for high-resolution slides and video.
Digital Signage & Retail
Drive multiple advertising displays from a single media player, simplifying content management and ensuring uniform branding across locations.
What's in the Box
The package includes all necessary components for immediate deployment, ensuring a complete out-of-the-box solution.
Highlights
- Transmits 4K video up to 492 feet over Cat6a cable
- HDBaseT Class A standard for reliable long-range signal integrity
- Dual output capability with 1 HDMI input and 3 HDMI outputs
- Includes four RJ-45 ports for control and network integration
- Rack-mountable transmitter and receiver for professional installations
- Supports IR and RS-232 control pass-through for system automation
- Plug-and-play setup with no software configuration required
- Environmentally friendly design and manufacturing
Specifications
| Specifications | |
|---|---|
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | VE814A-ATA |
| Brand Name | ATEN |
| Product Line | VanCryst |
| Product Model | VE814A |
| Product Name | HDMI HDBaseT Extender with Dual Output (4K@100m) (HDBaseT Class A) |
| Product Type | Video Extender Transmitter/Receiver |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Input Devices Supported | 1 |
| Number of Output Devices Supported | 1 |
| Maximum Operating Distance | 492.13 ft (150000 mm) |
| Video | |
| Graphics Modes | 4K |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| HDMI In | Yes |
| HDMI Out | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 3 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Twisted Pair Cable Standard | Category 6a |
| Physical Characteristics | |
| Transmitter Height | 1.14" (28.96 mm) |
| Transmitter Width | 3.98" (101.09 mm) |
| Transmitter Depth | 5.35" (135.89 mm) |
| Receiver Height | 1.14" (28.96 mm) |
| Receiver Width | 3.98" (101.09 mm) |
| Receiver Depth | 5.35" (135.89 mm) |
| Form Factor | Rack-mountable |
| Transmitter Weight (Approximate) | 15.87 oz (450 g) |
| Receiver Weight (Approximate) | 1.04 lb (470 g) |
| Miscellaneous | |
| Package Contents | 1 x VE814AT Transmitter 1 x VE814AR Receiver 1 x IR Transmitter Cable 1 x IR Receiver Cable 2 x RS-232 Terminal Blocks 2 x Power Adapters 1 x User Instructions |
| Environmentally Friendly | Yes |
User Manual
FAQ
What is the maximum distance this extender can transmit a 4K signal?
The ATEN VE814A-ATA supports a maximum operating distance of 492.13 feet (150 meters) when using Category 6a twisted-pair Ethernet cable. This extended range allows you to place source equipment far from displays without signal loss, making it suitable for large venues like auditoriums, conference halls, or distributed digital signage networks.
How many displays can I connect to a single source with this extender?
This extender features dual output capability, providing three HDMI outputs on the receiver unit. You can connect up to three displays simultaneously to a single HDMI source, enabling multi-screen setups for presentations, video walls, or mirrored content across different rooms without requiring additional splitters or distribution amplifiers.
What type of cable do I need for installation?
The extender requires standard Category 6a twisted-pair Ethernet cable (Cat6a) to achieve its maximum distance and performance. Cat6a cable supports the high bandwidth needed for 4K video transmission over long runs and is widely available, cost-effective, and easy to terminate, simplifying both new installations and upgrades to existing structured cabling infrastructure.
Is this extender rack-mountable?
Yes, both the transmitter and receiver are designed with a rack-mountable form factor. Their compact dimensions (1.14" height) allow them to be installed in standard 19-inch equipment racks using optional rack shelves or direct mounting kits. This design ensures clean integration into AV racks, server rooms, or equipment closets for professional installations.
Does the extender support control signals like IR or RS-232?
Yes, the VE814A-ATA includes support for IR (infrared) and RS-232 serial control pass-through. The package includes IR transmitter and receiver cables, plus RS-232 terminal blocks, allowing you to remotely control source devices (like Blu-ray players or media servers) from the display location. This is essential for integrated AV systems where centralized control is required.
What video resolutions and formats are supported?
The extender supports 4K video at a maximum resolution of 4096 x 2160 pixels, covering common 4K formats used in professional and consumer applications. It is compatible with HDCP 2.2 for protected content playback and handles high-bandwidth signals without compression, ensuring full fidelity for detailed graphics, video feeds, and presentations.
