AXIOM MEMORY JD092B-AX Axiom 10GBASE-SR SFP+ Transceiver for HP - 10GbE Multi-mode Fiber LC Connector
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ transceiver operates on the 10GBASE-SR standard, which specifies short-reach transmission over multi-mode fiber optic cables. It uses 850 nm wavelength optics to achieve data rates up to 10 Gbps, suitable for distances typically up to 300 meters on OM3 fiber or 400 meters on OM4 fiber, depending on cable quality and network conditions.
The module's electrical interface complies with SFP+ MSA and IEEE 802.3ae specifications, ensuring interoperability with compliant host devices. It supports digital diagnostic monitoring (DDM) functions for real-time performance tracking, including temperature, voltage, and optical power levels, facilitating proactive network management.
Key Product Advantages
The JD092B-AX transceiver offers several advantages for network deployments requiring high-speed fiber connectivity. Its MSA compliance guarantees reliable performance and compatibility with HP networking gear, reducing integration risks and ensuring seamless operation in mixed-vendor environments.
High-Speed Data Transfer
Delivers up to 10 Gbps throughput, enabling efficient handling of large data volumes, video streaming, and virtualization workloads without network bottlenecks.
- Supports 10 Gigabit Ethernet technology
- Ideal for bandwidth-intensive applications
Fiber Optic Reliability
Utilizes multi-mode fiber optic media for stable, long-distance data transmission with immunity to electromagnetic interference, ensuring consistent network performance in challenging environments.
- LC connector for secure fiber attachment
- Multi-mode support for cost-effective cabling
Deployment / Use Cases
This transceiver is engineered for scenarios demanding high-bandwidth, low-latency connections between network switches, routers, servers, and storage arrays. It excels in data center interconnects, where 10 Gbps fiber links aggregate traffic from multiple servers or connect top-of-rack switches to core networking infrastructure.
Common use cases include upgrading existing HP networks to 10 Gigabit speeds, extending network segments over fiber optic cabling in campus environments, and supporting high-performance computing clusters that require rapid data exchange between nodes. Its small form factor and low power consumption make it suitable for high-density switch configurations.
Data Center Networking
Connect HP switches to servers or storage systems over multi-mode fiber, providing scalable bandwidth for virtualized environments and cloud applications.
Network Backbone Expansion
Extend network reach between buildings or floors using fiber optic cabling, leveraging the transceiver's 10 Gbps capability for backbone links.
Physical Profile
The JD092B-AX transceiver features a compact SFP+ form factor with dimensions of 0.49" (12.50 mm) height, 0.53" (13.40 mm) width, and 2.21" (56.10 mm) depth, weighing approximately 0.59 oz (16.78 g). Its lightweight and slim design allows for high port density in network switches, minimizing rack space usage while maintaining robust construction for reliable operation in varied temperature and humidity conditions.
- Width
- 0.53" (13.40 mm)
- Depth
- 2.21" (56.10 mm)
- Height
- 0.49" (12.50 mm)
- Weight
- 0.59 oz (16.78 g)
Highlights
- 10 Gigabit Ethernet technology for data transfer up to 10 Gbps
- Compatible with multi-mode fiber optic cabling for reliable long-distance connections
- Single LC connector supports duplex fiber optic links
- MSA compliant for broad interoperability with HP networking equipment
- RoHS certified, meeting environmental standards for hazardous substance restriction
- Compact SFP+ form factor ideal for high-density network deployments
- Supports digital diagnostic monitoring for real-time performance tracking
- Designed for data networking and optical network applications
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axiom Memory Solutions |
| Manufacturer Part Number | JD092B-AX |
| Brand Name | Axiom |
| Product Model | JD092B-AX |
| Product Name | 10GBASE-SR SFP+ Transceiver for HP - JD092B |
| Product Type | SFP+ |
| Technical Information | |
| Application/Usage | Data Networking,Optical Network |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC 10GBASE-SR Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Ethernet Technology | 10 Gigabit Ethernet |
| Physical Characteristics | |
| Height | 0.49" (12.50 mm) |
| Width | 0.53" (13.40 mm) |
| Depth | 2.21" (56.10 mm) |
| Weight (Approximate) | 0.59 oz (16.78 g) |
| Miscellaneous | |
| Compatibility | MSA Compliant |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
FAQ
What is the data transfer rate of this SFP+ transceiver?
This transceiver supports 10 Gigabit Ethernet technology, delivering data transfer rates up to 10 Gbps. It is designed for high-bandwidth applications such as data center interconnects, server networking, and backbone links, ensuring efficient handling of large data volumes without network congestion.
What type of fiber optic cable does this transceiver use?
The JD092B-AX transceiver is compatible with multi-mode fiber optic cables, which have a thicker diameter to carry multiple wavelengths of light. This supports high bandwidth transmission over distances typically up to 300-400 meters, making it suitable for short to medium-range network segments in enterprise environments.
Is this transceiver compatible with HP networking equipment?
Yes, this transceiver is specifically designed for HP networking equipment and is MSA compliant, ensuring broad compatibility with HP switches and routers that accept SFP+ modules. It integrates seamlessly into existing HP network infrastructures for reliable 10 Gbps connectivity.
What connector type does this SFP+ transceiver have?
It features a single LC connector for duplex fiber optic connections. The LC connector is widely used in high-density networking environments due to its small size and secure attachment, providing stable signal transmission for data networking and optical network applications.
