Axiom JH235A-AX X242 40GbE QSFP+ to QSFP+ DAC Cable - 9. 8 ft Direct Attach Copper for HP 5400R zl2 Series Switches
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This DAC cable operates at a data transfer rate of 40 Gbit/s, making it suitable for backbone connections, switch-to-switch links, and high-bandwidth server connectivity. The QSFP+ form factor provides a compact, high-density solution that maximizes port utilization in modern networking equipment.
The 9.8-foot length (equivalent to 3 meters) offers flexible deployment options within racks, between adjacent racks, or in close-proximity networking scenarios. Direct attach copper technology eliminates the need for separate transceivers, reducing both cost and points of failure in the connection path.
Key Product Advantages
This Axiom DAC cable simplifies network infrastructure by providing a complete, ready-to-use connectivity solution that requires no additional components. The direct copper construction offers lower latency and power consumption compared to optical alternatives while maintaining reliable 40GbE performance.
Cost-Effective Connectivity
Eliminates the need for separate transceivers and fiber optic cables, reducing total deployment costs while maintaining full 40GbE throughput.
- No separate transceivers required
- Lower total cost of ownership
- Simplified inventory management
HP Switch Compatibility
Specifically tested and verified for use with HP 5400R zl2 series switches, ensuring reliable performance in supported network environments.
- Verified HP compatibility
- Reliable switch-to-switch connections
- Supported network topology
Deployment / Use Cases
This 40GbE DAC cable is ideal for connecting compatible switches within data center racks, establishing high-speed links between network aggregation points, and providing backbone connectivity for enterprise network infrastructure. The 9.8-foot length makes it particularly suitable for intra-rack and short-distance inter-rack applications.
Common deployment scenarios include connecting HP 5400R zl2 series switches in stacked configurations, establishing high-bandwidth links between core and distribution switches, and providing 40GbE connectivity for high-performance computing clusters. The cable supports both data center and enterprise networking environments where reliable, high-throughput connections are required.
Data Center Applications
Provides cost-effective 40GbE connectivity between switches and servers within data center racks, supporting high-density network deployments.
Enterprise Networking
Enables high-speed backbone connections between network switches in enterprise environments, supporting bandwidth-intensive applications and services.
Highlights
- 40GbE data transfer rate for high-bandwidth applications
- QSFP+ to QSFP+ direct attach copper cable design
- 9.8-foot (3m) length for flexible deployment
- Compatible with HP 5400R zl2 series switches
- Hot-pluggable QSFP+ connectors on both ends
- Direct copper connection eliminates transceiver costs
- Supports network device and switch connections
- Cost-effective alternative to fiber optic solutions
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axiom Memory Solutions |
| Manufacturer Part Number | JH235A-AX |
| Brand Name | Axiom |
| Product Model | X242 |
| Product Name | X242 40G QSFP+ to QSFP+ 3m DAC Cable (JH235A) |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | QSFP+ |
| Cable Length | 9.8 ft |
| Connector Type on First End | QSFP+ Network |
| Connector on First End Details | QSFP+ Network |
| Connector Type on Second End | QSFP+ Network |
| Connector on Second End Details | QSFP+ Network |
| Device Supported | Network Device,Switch |
| Data Transfer Rate | 40 Gbit/s |
| Miscellaneous | |
| Compatibility | HP 5400R zl2 Series Switch |
FAQ
What is the data transfer rate of this DAC cable?
This Axiom DAC cable supports a data transfer rate of 40 Gbit/s (40GbE), providing high-bandwidth connectivity suitable for backbone connections, switch-to-switch links, and server connectivity in modern network environments.
What specific HP switches is this cable compatible with?
This cable is specifically compatible with HP 5400R zl2 series switches. It has been verified for reliable performance with these switch models, making it ideal for deployments using HP networking infrastructure.
What is the advantage of using a DAC cable over fiber optic solutions?
Direct Attach Copper cables provide a cost-effective alternative to fiber optic solutions by eliminating the need for separate transceivers. They offer lower latency, reduced power consumption, and simplified deployment while maintaining reliable 40GbE performance for short-distance applications.
What is the cable length and how does it affect deployment?
The cable measures 9.8 feet (3 meters), making it suitable for intra-rack connections, short-distance inter-rack links, and close-proximity networking scenarios. This length provides flexibility for most rack-mounted applications while maintaining signal integrity.
