AXIS 02634-001 P3737-PLE Panoramic 5MP 2K Network Camera - White - Zipstream - H. 265 - PoE - IP66/67 - IK09
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera captures video at up to 2560 x 1440 resolution at 30 frames per second, ensuring clear and fluid footage. The 1/2.7" CMOS sensor provides high sensitivity with a fixed iris, while the varifocal lens offers a 3.2mm to 8.1mm focal length range with 2.5x optical zoom, allowing precise framing adjustments. The camera supports a comprehensive set of video codecs including H.265 (HEVC) Main Profile, H.264 variants, and Motion JPEG, giving flexibility for different recording and streaming requirements.
Network connectivity is handled through a Gigabit Ethernet port with support for IPv4/IPv6, HTTP/HTTPS, RTSP, SNMP v1/v2c/v3, and numerous other protocols for integration with VMS platforms and network management systems. Storage expansion is available via memory card, and the camera includes advanced imaging features such as Wide Dynamic Range, 3D Digital Noise Reduction, and backlight compensation to maintain image quality in challenging lighting conditions.
Key Product Advantages
The P3737-PLE combines high-resolution imaging with intelligent features to deliver superior surveillance performance while reducing operational costs. Its panoramic design eliminates blind spots, and the advanced compression technologies significantly lower bandwidth and storage requirements without compromising video quality.
Advanced Video Compression
Zipstream technology dynamically optimizes video encoding to reduce bandwidth and storage usage by up to 50% or more compared to standard H.264, while H.265 (HEVC) provides additional efficiency for high-resolution streams.
- Bandwidth optimization
- Storage savings
- Maintains image quality
Robust Environmental Protection
With IP66/67 ratings against dust and water ingress and IK09 impact resistance, this camera withstands harsh outdoor and industrial environments, ensuring continuous operation in challenging conditions.
- Weatherproof design
- Vandal resistance
- Wide temperature range
Intelligent Analytics Features
Built-in detection capabilities including motion, human, and vehicle detection enable proactive security monitoring, while features like cross-line detection support perimeter protection applications.
- Smart detection
- Reduced false alarms
- Enhanced situational awareness
Deployment / Use Cases
This camera is ideal for medium to large-scale surveillance installations where comprehensive coverage, high image quality, and reliability are paramount. Its panoramic capability makes it particularly suitable for monitoring wide areas such as parking lots, warehouses, retail spaces, and building perimeters where multiple fixed cameras would otherwise be required.
The PoE functionality simplifies deployment in both new and retrofit installations by eliminating separate power runs, while the robust environmental ratings ensure performance in outdoor applications exposed to weather, dust, and potential vandalism. Integration with existing network video management systems is straightforward thanks to extensive protocol support and ONVIF compatibility.
Perimeter Security
Monitor building exteriors, fences, and gates with the wide field of view and advanced detection features that trigger alerts for unauthorized access attempts.
- Wide coverage area
- Cross-line detection
- Tamper alerts
Critical Infrastructure
Deploy in industrial facilities, transportation hubs, and utility sites where environmental durability and reliable 24/7 operation are essential for security monitoring.
- Harsh environment rated
- Continuous operation
- Remote management
Physical Profile
The camera features a durable white housing designed for both aesthetic integration and functional protection. With dimensions accommodating the four-sensor panoramic array and varifocal lens system, it provides comprehensive coverage from a single mounting point. The included mounting hardware and cable gaskets ensure secure installation and weatherproof cable connections when deployed outdoors or in demanding environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4.41 lb (2000 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 4.41 lb (2000 g)
- Length
- 3.2 mm (0.13")
What's in the Box
The package includes all necessary components for installation and operation of the camera system.
Package contents include P3737-PLE Panoramic Camera installation guide connector guard cable gaskets, P3737-PLE Panoramic Camera. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 5-megapixel resolution delivers detailed 2K video at 2560 x 1440
- Panoramic design with four sensors provides wide 134°-47° diagonal field of view
- Zipstream compression technology reduces bandwidth and storage requirements
- H.265 (HEVC) support for efficient high-resolution video streaming
- PoE (Power over Ethernet) enabled for simplified single-cable installation
- IP66/67 and IK09 ratings for weatherproof and vandal-resistant operation
- Wide operating temperature range from -30°C to 50°C
- Advanced imaging features including WDR, 3D DNR, and backlight compensation
- Built-in detection for motion, humans, and vehicles with cross-line capability
- 5-year limited warranty with TAA compliance for government deployments
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 02634-001 |
| Brand Name | AXIS |
| Product Line | Panoramic |
| Product Series | P37 |
| Product Model | P3737-PLE |
| Product Name | P3737-PLE Panoramic Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | 2K |
| Camera Iris | Fixed |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.7" |
| Color Supported | Color |
| Field of View | Horizontal field of view: 99°-37° Vertical field of view: 70°-28° Diagonal field of view: 134°-47° |
| Effective Camera Resolution | 5 Megapixel |
| Number of Sensors | 4 |
| Video | |
| Video Formats | Zipstream,Motion JPEG,H.265 (MPEG-H Part 2/HEVC) Main Profile,H.264B (MPEG-4 Part 10/AVC),H.264M (MPEG-4 Part 10/AVC),H.264H (MPEG-4 Part 10/AVC),H.264B,H.264M,H.264H,H.265B,H.265H,H.265M |
| Maximum Video Resolution | 2560 x 1440 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 3.2 mm (0.13") |
| Maximum Focal Length | 8.1 mm (0.32") |
| Lens Included | Yes |
| Minimum Aperture | f/3.2 |
| Maximum Aperture | f/1.9 |
| Optical Zoom | 2.5x |
| Exposure | |
| Shortest Shutter Speed | 1/28000 Second |
| Longest Shutter Speed | 1.5 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Protocols | IPv4,IPv6 USGv6,ICMPv4/ICMPv6,HTTP,HTTPS,TLS,FTP,SFTP,SMTP,SNMP (v1/v2c/v3),DNSv6,DNS,NTP,RTSP,IGMPv1/v2/v3,DHCPv4/v6,LLDP,MQTT,SMB/CIFS,mDNS (Bonjour),UPnP,SNMPv1/v2c/v3 (MIB2),DNS/DNSv6,DDNS,NTS,RTP,SRTP/RTSPS,TCP,UDP,RTCP,ICMP,DHCPv6,ARP,SSH,CDP,MQTT v3.1.1,UDP/TCP/TLS,IEEE 802.1X,IEEE 802.1AR |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 23.30 W |
| Power Source Type | PoE |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Durability | Tamper Resistant |
| Weight (Approximate) | 4.41 lb (2000 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Maximum Operating Humidity | 100% |
| Miscellaneous | |
| Features | Back Light Compensation (BLC),Highlight Compensation (HLC),Wide Dynamic Range,3D Digital Noise Reduction,Noise Detection,Mirror,Password Protection,Cross Line Detection,Vehicle Detection,Human Detection,Motion Detection |
| Package Contents | P3737-PLE Panoramic Camera installation guide connector guard cable gaskets |
| Impact Protection Rating | IK09 |
| Ingress Protection Rating | IP66,IP67 |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the maximum resolution and frame rate of this camera?
The AXIS P3737-PLE captures video at up to 2560 x 1440 resolution (2K) at 30 frames per second. This combination provides detailed imagery with smooth motion representation, suitable for identifying subjects and activities in surveillance applications.
How does the panoramic design work and what are the benefits?
This camera incorporates four image sensors that work together to create a panoramic view with a diagonal field of view ranging from 47° to 134°. This design eliminates blind spots between multiple cameras and provides comprehensive coverage from a single mounting point, reducing installation complexity and hardware costs.
What video compression formats does this camera support?
The camera supports multiple compression formats including H.265 (HEVC) Main Profile, H.264 variants (H.264B, H.264M, H.264H), Motion JPEG, and Axis Zipstream technology. This flexibility allows optimization for different network conditions, storage requirements, and compatibility with various video management systems.
What are the environmental protection ratings and what do they mean?
The camera carries IP66/67 ratings for protection against dust and water ingress, making it suitable for outdoor use in rain and temporary submersion. It also has an IK09 impact resistance rating, which means it can withstand 5 joules of impact energy (equivalent to a 1.7kg mass dropped from 300mm), providing vandal resistance for public installations.
How is the camera powered and what are the installation requirements?
The camera is powered via Power over Ethernet (PoE), which delivers both data and power through a single Ethernet cable. This simplifies installation by eliminating the need for separate power wiring. The camera requires a PoE switch or injector that complies with IEEE 802.3af/at standards and has a maximum power consumption of 23.30 watts.
What intelligent detection features are built into this camera?
The camera includes multiple detection capabilities: motion detection for general activity monitoring, human detection to distinguish people from other moving objects, vehicle detection for traffic monitoring, and cross-line detection for perimeter protection. These features reduce false alarms and enable more efficient monitoring by focusing attention on relevant events.
