AXIS Q1808-LE 10 Megapixel Outdoor Network Camera - Color - Bullet - 393.70 ft (120 m) Infrared Night Vision - H.264M (MPEG-4 Part - (02507-001)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Q1808-LE Bullet Camera
- Installation Guide
- Terminal Block connector
- RJ45 Cable
- Connector Guard
- Cable Gaskets
- Owner Authentication Key
HD Recording: Yes
Night Vision: Yes
Night Vision Distance: 393.70 ft (120 m)
Night Vision Type: Infrared
Camera Iris: Auto,P-iris
Wide Dynamic Range Detail: 120 dB
Infrared (IR) Cut-off Filter: Yes
Languages Support: Simplified Chinese,English,German,French,Spanish,Italian,Russian,Japanese,Korean,Portuguese,Polish,Traditional Chinese,Dutch,Czech,Swedish,Finnish,Turkish,Thai,Vietnamese
Image Sensor Type: RGB CMOS
Image Sensor Size: 4/3"
Color Supported: Color
Field of View: Horizontal field of view: 21°-7° Vertical field of view: 12°-4°
Effective Camera Resolution: 10 Megapixel
Video Formats: H.264M (MPEG-4 Part 10/AVC),H.264H (MPEG-4 Part 10/AVC),Motion JPEG,H.264B (MPEG-4 Part 10/AVC),H.265 (MPEG-H Part 2/HEVC) Main Profile,H.264,H.265,Zipstream,H.264M,H.264B,H.264H
Maximum Video Resolution: 3712 x 2784
Maximum Frame Rate: 60 fps
Shortest Shutter Speed: 1/45500 Second
Longest Shutter Speed: 2 Second
PTZ Modes: Digital PTZ
Connectivity Technology: Wired
Remote Management: Yes
Ethernet Technology: Gigabit Ethernet
Protocols: ONVIF,IPv4,MQTT,IPv6 USGv6,ICMPv4/ICMPv6,HTTP,HTTPS,TLS,DiffServ (QoS),FTP,SFTP,CIFS/SMB,SMTP,mDNS (Bonjour),UPnP,SNMPv1/v2c/v3 (MIB2),DNS/DNSv6,DDNS,NTP,NTS,RTSP,RTP,SRTP/RTSPS,TCP,UDP,IGMPv1/v2/v3,RTCP,ICMP,DHCPv4/v6,ARP,SSH,LLDP,SIP,CDP,MQTT v3.1.1,ZeroConf,IEEE 802.1AR,IEEE 802.1X (EAP-TLS)
Storage Type: Memory Card
Network (RJ-45): Yes
Maximum Power Consumption: 51 W
Input Voltage: 10 V DC,28 V DC,20 V AC,24 V AC
Power Source Type: PoE,AC,DC
Form Factor: Bullet
Durability: Impact Resistant
Weight (Approximate): 7.05 lb (3200 g)
Minimum Operating Temperature: -40°F (-40°C)
Maximum Operating Temperature: 140°F (60°C)
Minimum Storage Temperature: -40°F (-40°C)
Maximum Storage Temperature: 140°F (60°C)
Maximum Operating Humidity: 100%
Minimum Storage Humidity: 5%
Maximum Storage Humidity: 95%
Features: Wide Dynamic Range,Day/Night,Video Management System,Motion Detection,Multi-view Stream,Audio Compression,HTTPS Encryption,Privacy Masking,White Balance,PTZ
Indoor/Outdoor: Outdoor
Package Contents:
Impact Protection Rating: IK10,IK08
Ingress Protection Rating: IP66,IP67
TAA Compliant: Yes
Environmental Compliance: Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS)
Limited Warranty: 5 Year
- For remote surveillance needs, this network camera is best suited
- Up to 3712 x 2784 resolution for surveillance in real-time
- Features RGB CMOS sensor
- Provides night vision of objects at a distance of up to 393.70 ft (120 m)
[custom-specifications]
| Specifications | |
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 02507-001 |
| Manufacturer Website Address | http://www.axis.com |
| Brand Name | AXIS |
| Product Model | Q1808-LE |
| Product Name | Q1808-LE Bullet Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 393.70 ft (120 m) |
| Night Vision Type | Infrared |
| Camera Iris | Auto,P-iris |
| Wide Dynamic Range Detail | 120 dB |
| Infrared (IR) Cut-off Filter | Yes |
| Languages Support | Simplified Chinese,English,German,French,Spanish,Italian,Russian,Japanese,Korean,Portuguese,Polish,Traditional Chinese,Dutch,Czech,Swedish,Finnish,Turkish,Thai,Vietnamese |
| Display & Graphics | |
| Image Sensor Type | RGB CMOS |
| Image Sensor Size | 4/3" |
| Color Supported | Color |
| Field of View | Horizontal field of view: 21°-7° Vertical field of view: 12°-4° |
| Effective Camera Resolution | 10 Megapixel |
| Video | |
| Video Formats | H.264M (MPEG-4 Part 10/AVC),H.264H (MPEG-4 Part 10/AVC),Motion JPEG,H.264B (MPEG-4 Part 10/AVC),H.265 (MPEG-H Part 2/HEVC) Main Profile,H.264,H.265,Zipstream,H.264M,H.264B,H.264H |
| Maximum Video Resolution | 3712 x 2784 |
| Maximum Frame Rate | 60 fps |
| Exposure | |
| Shortest Shutter Speed | 1/45500 Second |
| Longest Shutter Speed | 2 Second |
| PTZ Modes | Digital PTZ |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Protocols | ONVIF,IPv4,MQTT,IPv6 USGv6,ICMPv4/ICMPv6,HTTP,HTTPS,TLS,DiffServ (QoS),FTP,SFTP,CIFS/SMB,SMTP,mDNS (Bonjour),UPnP,SNMPv1/v2c/v3 (MIB2),DNS/DNSv6,DDNS,NTP,NTS,RTSP,RTP,SRTP/RTSPS,TCP,UDP,IGMPv1/v2/v3,RTCP,ICMP,DHCPv4/v6,ARP,SSH,LLDP,SIP,CDP,MQTT v3.1.1,ZeroConf,IEEE 802.1AR,IEEE 802.1X (EAP-TLS) |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 51 W |
| Input Voltage | 10 V DC,28 V DC,20 V AC,24 V AC |
| Power Source Type | PoE,AC,DC |
| Physical Characteristics | |
| Form Factor | Bullet |
| Durability | Impact Resistant |
| Weight (Approximate) | 7.05 lb (3200 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 100% |
| Minimum Storage Humidity | 5% |
| Maximum Storage Humidity | 95% |
| Miscellaneous | |
| Features | Wide Dynamic Range,Day/Night,Video Management System,Motion Detection,Multi-view Stream,Audio Compression,HTTPS Encryption,Privacy Masking,White Balance,PTZ |
| Indoor/Outdoor | Outdoor |
| Package Contents |
|
| Impact Protection Rating | IK10,IK08 |
| Ingress Protection Rating | IP66,IP67 |
| TAA Compliant | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
User-Manual
[/custom-user-manual]
