Product Features
Technical Overview
This patch panel features 48 total ports, with 48 RJ-45 ports for network connections and 48 RJ-11 ports for telephone lines. The punchdown termination method allows for secure and organized cable management, reducing clutter and improving airflow in rack installations.
The panel is designed for 2U rack mounting in standard 19" racks, with dimensions of 3.50" height, 19" width, and 2.40" depth. Its compact profile maximizes rack space efficiency while providing full port accessibility for patching and maintenance.
This section brings together practical product details such as Total Number of Ports, Number of Network (RJ-45) Ports, Number of RJ-11 Ports, Product Material, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The JPM5E48A offers a high-density solution for network infrastructure, combining Ethernet and telephone termination in a single unit. Its punchdown design ensures reliable connections and simplifies cable organization, reducing installation time and maintenance overhead.
Dual-Port Support
Provides both RJ-45 and RJ-11 ports, allowing for consolidated network and telephone cabling in one panel.
- 48 RJ-45 ports for Ethernet
- 48 RJ-11 ports for telephone
Rack-Optimized Design
Engineered for 2U rack mounting with standard 19" width, fitting seamlessly into existing rack infrastructure.
- Saves rack space
- Standard mounting hardware
Deployment / Use Cases
This patch panel is ideal for environments requiring organized cable termination for both data and voice networks. It serves as a central patching point in data centers, office buildings, educational facilities, and telecommunications rooms.
Common deployments include server rack installations, network closet setups, and structured cabling systems where high port density and reliable termination are critical. The panel supports CAT5e cabling for Gigabit Ethernet and standard telephone lines, making it versatile for mixed-use networking.
Data Center Racking
Use in server racks to terminate incoming and outgoing network cables, providing a clean and manageable patching interface.
Office Network Closets
Deploy in network closets to consolidate Ethernet and telephone lines from workstations, reducing cable sprawl and improving accessibility.
Physical Profile
The panel is constructed from metal, offering durability and stability in rack-mounted environments. Its dimensions are optimized for 2U rack space, with a weight of 2.10 lb for easy handling during installation. The design includes standard mounting points for secure attachment to 19" racks.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 3.50" (88.90 mm), 19", 2.40" (60.96 mm), 2.10 lb (952.54 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 19"
- Depth
- 2.40" (60.96 mm)
- Height
- 3.50" (88.90 mm)
- Weight
- 2.10 lb (952.54 g)
What's in the Box
The package includes the CAT5e patch panel, along with 12-24 and 10-32 screws for rack mounting, and cable ties for organized cable management.
Highlights
- 48 total ports with RJ-45 and RJ-11 support
- Punchdown termination for secure cable connections
- 2U rack-mount design for 19" racks
- Metal construction for durability
- Unshielded CAT5e compatibility
- Includes mounting screws and cable ties
- Compact dimensions: 3.50" H x 19" W x 2.40" D
- 2-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | JPM5E48A |
| Brand Name | Black Box |
| Product Model | JPM5E48A |
| Product Name | CAT5e Patch Panel, Punchdown - 2U, Unshielded, 48-Port |
| Product Condition | New |
| Product Type | Network Patch Panel |
| Interfaces/Ports | |
| Total Number of Ports | 48 |
| Number of Network (RJ-45) Ports | 48 |
| Number of RJ-11 Ports | 48 |
| Physical Characteristics | |
| Product Material | Metal |
| Compatible Rack Unit | 2U |
| Compatible Rack Width | 19" |
| Height | 3.50" (88.90 mm) |
| Width | 19" (482.60 mm) |
| Depth | 2.40" (60.96 mm) |
| Weight (Approximate) | 2.10 lb (952.54 g) |
| Miscellaneous | |
| Package Contents | CAT5e Patch Panel, Punchdown - 2U, Unshielded, 48-Port 12-24, 10-32 Screws Cable Ties |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What types of ports does this patch panel support?
The Black Box JPM5E48A supports 48 RJ-45 ports for Ethernet network connections and 48 RJ-11 ports for telephone lines. This dual-port design allows for consolidated termination of both data and voice cabling in a single panel.
Is this patch panel compatible with standard rack equipment?
Yes, the panel is designed for 2U rack mounting in standard 19" wide racks. It includes mounting holes for 12-24 and 10-32 screws, ensuring compatibility with most rack hardware and easy integration into existing infrastructure.
What cabling standard does this panel support?
This patch panel supports CAT5e unshielded twisted pair (UTP) cabling. It is optimized for punchdown termination of CAT5e cables, which are commonly used for Gigabit Ethernet and telephone applications in structured cabling systems.
What is included in the package with the patch panel?
The package includes the CAT5e punchdown patch panel, 12-24 and 10-32 screws for rack mounting, and cable ties for cable management. These accessories ensure you have the necessary hardware for installation and organization.
What are the dimensions and weight of this patch panel?
The panel measures 3.50" in height, 19" in width, and 2.40" in depth, with a weight of approximately 2.10 lb (952.54 g). These compact dimensions make it suitable for high-density rack installations while remaining lightweight for easy handling.
What warranty coverage does this product have?
The Black Box JPM5E48A comes with a 2-year limited warranty. This warranty covers defects in materials and workmanship, providing assurance of product reliability and support for network infrastructure deployments.
