Black Box LBH100AE-H-SSC Dual Port Media Converter - Single-mode SC Duplex to RJ45 Ethernet - 40 km - Rail/Rack Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter operates with 10/100Base-TX and 100Base-X network technologies, delivering Fast Ethernet performance up to 100 Mbps. It supports both optical fiber and twisted pair media, ensuring compatibility with diverse cabling environments. The single-mode fiber interface uses SC duplex connectors for reliable optical signal transmission.
The device features a total of three ports: one SC duplex port for fiber input/output and two RJ45 ports for copper Ethernet connections. This configuration allows bidirectional conversion between fiber and copper segments, facilitating network expansion without replacing existing copper cabling.
This section brings together practical product details such as Total Number of Ports, Network (RJ-45), DVI, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The LBH100AE-H-SSC media converter offers distinct advantages for network integration projects. Its ability to extend single-mode fiber connections up to 40 km eliminates distance limitations of copper cabling while maintaining Ethernet compatibility. The dual RJ45 ports provide flexibility for connecting multiple copper devices or creating redundant links.
Extended Reach
Supports 40 km fiber distances, far exceeding standard copper Ethernet limitations for backbone and long-haul connections.
- Single-mode fiber for long-distance transmission
- Maintains signal integrity over extended runs
Flexible Deployment
Rail and rack mounting options with compact dimensions enable installation in space-constrained environments like network racks or enclosures.
- 3.50" H x 3" W x 1" D footprint
- Suitable for data centers and industrial settings
Standards Compliance
Meets TAA requirements and environmental standards, making it appropriate for government and enterprise deployments with specific compliance needs.
- TAA Compliant for government contracts
- Environmentally friendly design
Deployment / Use Cases
This media converter is ideal for scenarios where fiber optic backbone segments need to interface with copper-based network equipment. Common applications include connecting fiber runs from building-to-building or campus networks to copper switches, routers, or end devices within facilities.
In industrial environments, it can bridge fiber-optic networks that are resistant to electromagnetic interference with standard Ethernet devices. The rail-mountable design makes it suitable for control panels or network cabinets where space is limited but reliable media conversion is essential for operational continuity.
Campus Network Extension
Extend fiber backbone connections between buildings up to 40 km while maintaining connectivity to copper-based network equipment within each facility.
Industrial Networking
Integrate fiber-optic networks in manufacturing or utility environments with copper Ethernet devices, leveraging fiber's immunity to electrical noise in harsh conditions.
Physical Profile
The converter features a compact design measuring 3.50 inches in height, 3 inches in width, and 1 inch in depth, with a lightweight construction of approximately 4.80 ounces. Its rail-mountable and rack-mountable form factor allows flexible installation in standard network racks, DIN rails, or enclosures. The small footprint conserves valuable rack space while providing robust media conversion capabilities in dense deployment environments.
- Width
- 3" (76.20 mm)
- Depth
- 1" (25.40 mm)
- Height
- 3.50" (88.90 mm)
- Weight
- 4.80 oz (136.08 g)
Highlights
- Converts single-mode SC duplex fiber to RJ45 Ethernet connections
- Supports distances up to 40 km (24.85 miles) for extended network reach
- Features 2 RJ45 ports and 1 SC duplex port for flexible connectivity
- Operates with 10/100Base-TX technology at up to 100 Mbps data rates
- Rail-mountable and rack-mountable form factor for versatile installation
- AC power source with compact 3.50" H x 3" W x 1" D dimensions
- TAA Compliant and manufactured in the United States
- Backed by a 3-year limited warranty for reliable performance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | LBH100AE-H-SSC |
| Brand Name | Black Box |
| Product Series | LBH100 |
| Product Model | LBH100AE-H-SSC |
| Product Name | LBH100AE-H-SSC Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 3 |
| Network (RJ-45) | Yes |
| DVI | No |
| USB | No |
| Management Port | No |
| Number of Network (RJ-45) Ports | 2 |
| Number of SC Ports | 1 |
| SC Port Type | Duplex |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Fiber Mode Supported | Single-mode |
| Maximum Distance Supported | 40 km (24.85 Mile) |
| Network & Communication | |
| Ethernet Technology | Ethernet,Fast Ethernet |
| Network Technology | 10/100Base-TX,100Base-X |
| Power Description | |
| Power Source | AC |
| Physical Characteristics | |
| Form Factor | Rail-mountable,Rack-mountable |
| Height | 3.50" (88.90 mm) |
| Width | 3" (76.20 mm) |
| Depth | 1" (25.40 mm) |
| Weight (Approximate) | 4.80 oz (136.08 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Country of Origin | United States |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What does this media converter actually convert?
This converter transforms signals between single-mode fiber optic connections using SC duplex connectors and standard RJ45 Ethernet copper connections. It enables communication between fiber backbone segments and copper-based network equipment, bridging different media types while maintaining Ethernet protocol compatibility.
What is the maximum distance supported by this converter?
The converter supports fiber optic connections up to 40 kilometers (approximately 24.85 miles). This extended reach capability allows network segments to span longer distances than possible with standard copper Ethernet cabling, making it suitable for campus, industrial, or backbone applications where distance is a factor.
How many ports does this media converter have and what types?
The converter has three total ports: one SC duplex port for fiber optic connections and two RJ45 ports for copper Ethernet connections. This configuration allows bidirectional conversion between fiber and copper media, with the dual RJ45 ports providing flexibility for connecting multiple copper devices or creating link options.
What network speeds does this converter support?
It supports 10/100Base-TX and 100Base-X network technologies, delivering Fast Ethernet performance up to 100 Mbps. This speed is suitable for most business network applications including file transfers, VoIP, and general data communication between fiber and copper network segments.
How is this converter mounted or installed?
The converter features both rail-mountable and rack-mountable form factors. Its compact dimensions of 3.50 inches high by 3 inches wide by 1 inch deep allow installation in standard network racks, on DIN rails, or in enclosures. This flexible mounting supports deployment in data centers, telecom closets, or industrial control panels where space optimization is important.
What compliance and warranty does this product include?
The converter is TAA Compliant, making it suitable for government contracts requiring Trade Agreements Act compliance. It is manufactured in the United States and includes a 3-year limited warranty. The environmentally friendly design also meets standards for reduced environmental impact in enterprise deployments.
