Black Box LBH100A-HD-SC-24 Fast Ethernet Media Converter - 2x RJ45 & 1x SC Multimode Fiber - DIN Rail Mount - 2 km Distance
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The LBH100A-HD-SC-24 delivers Fast Ethernet connectivity with a data transfer rate of up to 100 Mbps across supported network cables. It features two RJ45 ports for copper connections and one SC duplex port for multimode fiber, providing a total of three ports for flexible network expansion or device attachment.
The converter operates on DC power and is built for rugged environments, with a hardened temperature design that ensures stable performance in varying conditions. Its fiber optic interface uses 1300 nm wavelength multimode fiber, supporting distances up to 2 km for extended network reach without signal degradation.
This section brings together practical product details such as Total Number of Ports, Network (RJ-45), DVI, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This media converter offers several advantages for network deployments requiring copper-to-fiber conversion. Its hardened temperature design ensures reliability in industrial settings, while the DIN rail mount option simplifies installation in standard racks or enclosures.
Extended Distance Coverage
Supports network extensions up to 2 km using multimode fiber, overcoming copper cable distance limitations for remote device connections.
- 2 km maximum distance
- SC duplex fiber port
- Multimode compatibility
Flexible Mounting Options
Designed for both rack-mountable and rail-mountable installations, providing versatile deployment in various infrastructure setups.
- DIN rail bracket included
- Compact 3.5" x 3" x 1" footprint
- Professional cable management
Deployment / Use Cases
The LBH100A-HD-SC-24 is well-suited for environments where copper and fiber network segments need to be interconnected. Common applications include industrial automation systems, security camera networks, and building management systems where extended distance or electrical isolation is required.
In manufacturing facilities, it can connect PLCs or sensors over fiber to avoid electromagnetic interference. For campus networks, it extends Ethernet connections between buildings using existing fiber infrastructure. The hardened design also makes it appropriate for outdoor enclosures or harsh indoor environments where temperature fluctuations occur.
Industrial Network Integration
Connect factory floor devices to control rooms over fiber for noise immunity and long-distance runs in manufacturing plants.
- Hardened temperature operation
- DIN rail mounting
- 2 km fiber reach
Building-to-Building Links
Extend network connections between separate structures using multimode fiber backbone with copper endpoints in each location.
- Copper-to-fiber conversion
- SC connector compatibility
- Fast Ethernet speed
Physical Profile
The converter has a compact footprint measuring 3.50" (88.90 mm) in height, 3" (76.20 mm) in width, and 1" (25.40 mm) in depth, weighing approximately 4.80 oz (136.08 g). Its small size and lightweight design allow for high-density installations in racks or on DIN rails without consuming excessive space. The form factor supports both rack-mountable and rail-mountable configurations, with the included DIN rail bracket facilitating secure mounting in industrial control panels or network cabinets.
- Width
- 3" (76.20 mm)
- Depth
- 1" (25.40 mm)
- Height
- 3.50" (88.90 mm)
- Weight
- 4.80 oz (136.08 g)
- Length
- 1300 nm
What's in the Box
The package includes the LBH100A-HD-SC-24 transceiver/media converter unit and a DIN rail bracket for mounting. All necessary hardware for installation is provided.
Highlights
- Converts between 2 RJ45 copper ports and 1 SC multimode fiber port
- Supports Fast Ethernet speeds up to 100 Mbps
- Extends network distance up to 2 km using fiber
- Hardened temperature design for industrial environments
- DIN rail mountable with included bracket
- Compact 3.5" x 3" x 1" footprint
- DC powered for flexible installation
- 3-year limited warranty
- TAA compliant and made in the United States
- Environmentally friendly construction
Specifications
| Specifications | |
|---|---|
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | LBH100A-HD-SC-24 |
| Brand Name | Black Box |
| Product Series | LBH100 |
| Product Model | LBH100A-HD-SC-24 |
| Product Name | LBH100A-HD-SC-24 Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 3 |
| Network (RJ-45) | Yes |
| DVI | No |
| USB | No |
| Management Port | No |
| Number of Network (RJ-45) Ports | 2 |
| Number of SC Ports | 1 |
| SC Port Type | Duplex |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Wavelength | 1300 nm |
| Maximum Distance Supported | 2 km (1.24 Mile) |
| Network & Communication | |
| Ethernet Technology | Ethernet,Fast Ethernet |
| Network Technology | 100Base-X,10/100Base-TX |
| Power Description | |
| Power Source | DC |
| Physical Characteristics | |
| Form Factor | Rack-mountable,Rail-mountable |
| Height | 3.50" (88.90 mm) |
| Width | 3" (76.20 mm) |
| Depth | 1" (25.40 mm) |
| Weight (Approximate) | 4.80 oz (136.08 g) |
| Miscellaneous | |
| Package Contents | LBH100A-HD-SC-24 Transceiver/Media Converter DIN Rail Bracket |
| Environmentally Friendly | Yes |
| Country of Origin | United States |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What types of network connections does this media converter support?
The LBH100A-HD-SC-24 supports two RJ45 copper ports for 10/100Base-TX Ethernet connections and one SC duplex port for multimode fiber optic connections. It converts signals between twisted pair copper and optical fiber media, enabling integration of fiber segments into copper-based networks.
What is the maximum distance supported by the fiber port?
The SC multimode fiber port supports network extensions up to 2 kilometers (1.24 miles). This extended reach is ideal for connecting devices across large facilities or between buildings where copper cable distance limitations would otherwise require additional networking equipment.
How is this media converter powered?
This converter operates on DC power. The DC power input provides flexibility for installation in various environments, including industrial settings where DC power sources are commonly available. The power method contributes to the unit's hardened design for reliable operation.
What mounting options are available for installation?
The LBH100A-HD-SC-24 is designed for both rack-mountable and rail-mountable installations. It includes a DIN rail bracket for secure mounting on standard DIN rails commonly found in industrial control panels, making it suitable for high-density deployments in cabinets or enclosures.
What type of fiber optic cable is compatible with this converter?
This converter is compatible with multimode fiber optic cables using SC duplex connectors. It operates at a 1300 nm wavelength, which is standard for multimode fiber applications. The SC port type provides a secure, push-pull connection for reliable fiber optic termination.
What warranty coverage does this product include?
The Black Box LBH100A-HD-SC-24 comes with a 3-year limited warranty. This warranty covers defects in materials and workmanship under normal use, providing assurance of product reliability. The converter is also TAA compliant and manufactured in the United States.
