Black Box LMC1009A-R3 FlexPoint Gigabit Ethernet Media Converter - 1 x RJ-45 to 1 x LC Single-mode 1310 nm - 10 km
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The converter operates at a 1310 nm wavelength on single-mode fiber, supporting transmission distances up to 10 kilometers (6.21 miles). It uses an LC fiber connector for reliable optical connections and an RJ-45 port for copper Ethernet, compatible with 1000Base-T and 1000Base-SX network standards.
Power is supplied via an external adapter, and the device supports multiple installation methods including wall mounting, rack mounting, or standalone placement. Its compact dimensions of 1 inch high by 3 inches wide by 4 inches deep allow for discreet deployment in space-constrained environments.
Relevant factors for this section include Total Number of Ports, Network (RJ-45), Number of LC Ports, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The media converter provides a cost-effective solution for integrating fiber optic cabling into existing copper-based networks. Its TAA compliance and U.S. origin make it suitable for government and enterprise procurement, backed by a one-year limited warranty for reliable operation.
Extended Network Reach
Converts copper Ethernet to fiber optic, enabling network segments to span up to 10 km without signal degradation, ideal for connecting buildings or remote equipment.
- Eliminates copper distance limitations
- Maintains Gigabit speeds over fiber
Flexible Deployment
Supports wall, rack, or external mounting with a compact form factor, allowing installation in telecom closets, data centers, or industrial panels.
- Multiple mounting options
- Small footprint saves space
Deployment / Use Cases
This converter is ideal for scenarios where network segments need to traverse long distances or environments with high electromagnetic interference. It supports Gigabit Ethernet for bandwidth-intensive applications like video surveillance, VoIP systems, or data backup across extended fiber runs.
Installation is straightforward with wall-mounting hardware included, and the external power supply ensures stable operation without overloading network equipment. The device is also suitable for temporary setups or permanent installations in controlled environments.
Campus Network Extension
Connect buildings across a campus or industrial site by converting copper LAN connections to single-mode fiber, overcoming distance limits and electrical interference.
Data Center Interconnect
Integrate fiber backbones with copper-based equipment racks, enabling high-speed links between switches, servers, or storage devices in mixed-media environments.
Physical Profile
The converter has a compact external design measuring 1 inch in height, 3 inches in width, and 4 inches in depth, with a weight of approximately 6.4 ounces. Its lightweight construction and multiple mounting options allow for flexible placement on walls, racks, or shelves, with a finish suitable for professional IT environments.
- Width
- 3" (76.20 mm)
- Depth
- 4" (101.60 mm)
- Height
- 1" (25.40 mm)
- Weight
- 6.40 oz (181.44 g)
- Length
- 1310 nm
Highlights
- Converts RJ-45 copper to LC single-mode fiber for network extension
- Supports Gigabit Ethernet speeds up to 1000 Mbps over 10 km distances
- Operates at 1310 nm wavelength on single-mode fiber optic cable
- Compact design with wall, rack, and external mounting flexibility
- TAA compliant and manufactured in the United States
- Includes a one-year limited warranty for reliable performance
- External power supply for easy installation and maintenance
- Compatible with 1000Base-T and 1000Base-SX network standards
Specifications
| Specifications | |
|---|---|
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | LMC1009A-R3 |
| Brand Name | Black Box |
| Product Line | FlexPoint |
| Product Name | FlexPoint Gigabit Ethernet Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of LC Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Fiber Mode Supported | Single-mode |
| Fiber Optic Cable Wavelength | 1310 nm |
| Maximum Distance Supported | 10 km (6.21 Mile) |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T,1000Base-SX |
| Power Description | |
| Power Source | Power Supply |
| Physical Characteristics | |
| Form Factor | External,Rack-mountable,Wall Mountable |
| Height | 1" (25.40 mm) |
| Width | 3" (76.20 mm) |
| Depth | 4" (101.60 mm) |
| Weight (Approximate) | 6.40 oz (181.44 g) |
| Miscellaneous | |
| Country of Origin | United States |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What does this media converter do?
This converter bridges copper and fiber network segments by converting Gigabit Ethernet signals from an RJ-45 copper port to an LC single-mode fiber optic port. It enables network extension up to 10 km, overcoming the distance limitations of standard copper cabling while maintaining full Gigabit performance.
What type of fiber does it support?
It supports single-mode fiber optic cable with LC connectors, operating at a 1310 nm wavelength. Single-mode fiber is ideal for long-distance transmission up to 10 km, providing low signal loss and high bandwidth for enterprise or campus network applications.
What is the maximum distance supported?
The converter supports distances up to 10 kilometers (6.21 miles) over single-mode fiber. This extended reach makes it suitable for connecting remote buildings, outdoor equipment, or data center interconnects where copper Ethernet would be impractical due to length or interference.
How is the converter powered?
It uses an external power supply, which provides stable operation without drawing power from the network. This separate power source ensures reliable performance and simplifies installation in various environments, such as wall-mounted or rack-mounted setups.
What mounting options are available?
The converter supports wall mounting, rack mounting, and external placement. Its compact dimensions of 1" H x 3" W x 4" D allow for flexible installation in telecom closets, data centers, or industrial panels, with hardware included for secure attachment.
Is this converter TAA compliant?
Yes, the converter is TAA compliant and manufactured in the United States, making it eligible for government and enterprise procurement under Trade Agreements Act requirements. It also comes with a one-year limited warranty for added reliability.
