Bogen M300 Kanto Full Motion TV Wall Mount - Black - 55" Screen Support - 80 lb Load Capacity - 400 x 400 VESA - 135° Swivel + Tilt
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The M300 features a full motion design with 135° of swivel in either direction, enabling flexible positioning to accommodate different room layouts and seating arrangements. The accessible tilt mechanism provides a +10° to -2° viewing angle adjustment, reducing glare and enhancing comfort.
Mounting hardware includes a single stud wall plate with a 5" (12.7 cm) offset, simplifying installation on standard wall studs. Integrated cable management keeps wires organized and out of sight, while adjustable horizontal leveling ensures your TV hangs perfectly straight.
Relevant factors for this section include Device Supported, Number of Displays Supported, Maximum Load Capacity, Product Color. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This wall mount delivers professional-grade functionality with user-friendly features that enhance both installation and daily use. The combination of extensive articulation, solid build quality, and thoughtful design details makes it stand out in its category.
Versatile Articulation
With 135° swivel and adjustable tilt, the M300 allows you to position your TV for optimal viewing from multiple angles, whether you're watching from the center of the room or from adjacent seating areas.
- 135° swivel range
- +10° to -2° tilt adjustment
- Flexible positioning
Robust Construction
Built from solid steel with a durable powder-coated finish, this mount provides reliable support for televisions up to 80 lb while resisting wear and maintaining a sleek appearance.
- Solid steel frame
- Powder-coated black finish
- 80 lb load capacity
Installation Convenience
The single stud wall plate design simplifies mounting on standard 16" stud centers, while integrated cable management and adjustable leveling ensure a clean, professional-looking installation.
- Single stud compatibility
- Integrated cable management
- Adjustable leveling
Deployment / Use Cases
The Kanto M300 is ideal for residential living rooms, bedrooms, and home theaters where flexible viewing angles are desired. Its full motion capabilities make it perfect for spaces with multiple seating areas or where the TV needs to be visible from different parts of the room.
In commercial environments such as waiting rooms, break areas, or small conference rooms, the M300 provides the durability and adjustability needed for shared spaces. The extensive VESA compatibility ensures it works with most flat panel displays commonly used in these settings.
Relevant factors for this section include Device Supported, Number of Displays Supported, Maximum Load Capacity, Product Color. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The mount measures 17" (431.80 mm) in height and width, with a depth of 19.60" (497.84 mm) when fully extended. When retracted, it sits just 2" (5 cm) from the wall, maintaining a low-profile appearance. The black powder-coated steel construction provides both durability and a modern aesthetic that blends with most decor styles.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 17" (431.80 mm), 17" (431.80 mm), 19.60" (497.84 mm), 10.10 lb (4581.28 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17" (431.80 mm)
- Depth
- 19.60" (497.84 mm)
- Height
- 17" (431.80 mm)
- Weight
- 10.10 lb (4581.28 g)
What's in the Box
The package includes all necessary components for installation and operation.
Package contents include Mount Hardware Manuals, Mount. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Fits most flat panel TVs from 26" to 55"
- Supports TVs up to 80 lb (36 kg)
- Accommodates VESA sizes from 100x100 to 400x400
- 135° of swivel in either direction
- +10° to -2° tilt adjustment
- Extends up to 19.6" (49.7 cm) from the wall
- Integrated cable management system
- Adjustable horizontal leveling
- Single stud wall plate with 5" offset
- 5-year manufacturer's warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Kanto |
| Manufacturer Part Number | M300 |
| Brand Name | Kanto |
| Product Model | M300 |
| Product Name | M300 Full Motion TV Wall Mount for 26-inch to 55-inch TVs - Black |
| Packaged Quantity | 1 |
| Product Type | Wall Mount |
| Product Information | |
| Device Supported | TV |
| Number of Displays Supported | 1 |
| Maximum Load Capacity | 80 lb (36287.39 g) |
| Maximum Screen Size Supported | 55" |
| Physical Characteristics | |
| Product Color | Black |
| Product Material | Steel |
| Mounting Pattern | 400 x 400,200 x 200,100 x 100,200 x 100,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,150 x 100,200 x 150 |
| Height | 17" (431.80 mm) |
| Width | 17" (431.80 mm) |
| Depth | 19.60" (497.84 mm) |
| Weight (Approximate) | 10.10 lb (4581.28 g) |
| Miscellaneous | |
| Package Contents | Mount Hardware Manuals |
| Energy Star | No |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What size TVs does the Kanto M300 wall mount support?
The Kanto M300 supports flat panel televisions from 26 inches to 55 inches in screen size. It's designed to accommodate most modern TVs within this range, provided they meet the weight and VESA pattern requirements.
What is the maximum weight capacity of this wall mount?
This wall mount has a maximum load capacity of 80 pounds (approximately 36 kilograms). This includes the weight of your television and any attached accessories, so always verify your TV's specifications before installation.
Which VESA patterns are compatible with the M300 mount?
The M300 accommodates numerous VESA patterns including 400x400, 200x200, 100x100, 200x100, 200x300, 200x400, 300x200, 300x300, 400x200, 150x100, and 200x150. This extensive compatibility ensures it fits most TVs from 26" to 55".
How much does the mount extend from the wall?
When fully extended, the mount reaches 19.6 inches (49.7 cm) from the wall. When retracted, it sits just 2 inches (5 cm) from the wall, providing both flexibility for viewing angles and a clean, low-profile appearance when not in use.
What articulation features does this wall mount offer?
The M300 provides full motion articulation with 135 degrees of swivel in either direction and tilt adjustment from +10 degrees to -2 degrees. This allows for optimal positioning to reduce glare and accommodate viewing from different areas of the room.
What is included in the warranty for this product?
Kanto provides a 5-year limited warranty for the M300 wall mount. This warranty covers defects in materials and workmanship, offering peace of mind for your investment. Always retain your proof of purchase for warranty claims.
