Cambium Networks SFP-1G-LX SFP Module - 1000Base-LX Gigabit Ethernet - Single-mode Fiber
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP module operates on the 1000Base-LX standard, providing a full-duplex Gigabit Ethernet link over single-mode optical fiber. The LX designation indicates long-wavelength (1310nm) operation, optimized for distances up to 10 kilometers under typical conditions, though actual reach depends on fiber quality and network design.
The module interfaces via a standard LC duplex connector, ensuring compatibility with common fiber patch panels and cabling. It supports digital diagnostics monitoring (DDM) capabilities for real-time performance tracking, including temperature, voltage, bias current, and optical power levels, aiding in proactive network management.
Key Product Advantages
This transceiver offers significant performance and reliability benefits for fiber-based network deployments. Its design prioritizes high-speed data integrity and operational stability in demanding environments.
High-Speed Performance
Delivers up to 1000Mbps data transfer rates, which is approximately 10x faster than standard Fast Ethernet connections, reducing latency and improving throughput for bandwidth-intensive applications.
- Gigabit Ethernet speed
- Low latency
- Full-duplex operation
Extended Reach with Single-Mode Fiber
Utilizes single-mode fiber to transmit data over distances up to 10 kilometers with minimal signal attenuation, ideal for connecting geographically dispersed network nodes or campus backbones.
- Long-distance capability
- Minimal signal loss
- Stable performance over miles
Seamless Compatibility
Specifically coded for Cambium Networks cnMatrix EX2000 series switches, ensuring plug-and-play functionality without configuration hassles. This includes models like EX2010, EX2028, EX2052, and their PoE variants.
- Pre-tested compatibility
- No firmware tweaks needed
- Supports various switch models
Deployment / Use Cases
The SFP-1G-LX module is versatile for various networking scenarios that require reliable, high-speed fiber connectivity. Its single-mode fiber support makes it particularly effective in environments where distance and signal integrity are critical.
Common deployments include uplinks between switches in enterprise networks, backbone connections in data centers, and links for service provider access networks. It is also suitable for connecting network equipment across buildings in campus settings or for extending network reach in industrial applications.
Enterprise Network Uplinks
Use as uplink modules in Cambium cnMatrix switches to aggregate traffic from access layers to core switches, ensuring high bandwidth and reduced bottlenecks in office or campus networks.
Data Center Interconnects
Deploy in data centers to connect switches or servers over fiber, supporting high-throughput applications like virtualization, storage networking, and cloud services with low latency.
Highlights
- 1000Base-LX Gigabit Ethernet SFP module for up to 1000Mbps data transfer
- Single-mode fiber support for long-distance connections up to 10 km
- Hot-pluggable design with LC duplex connector for easy installation
- Compatible with Cambium Networks cnMatrix EX2000 series switches
- Digital diagnostics monitoring (DDM) for real-time performance tracking
- Ideal for data networking, optical network backbones, and enterprise uplinks
- Minimal signal loss and durable performance over fiber optic cable
- Supports audio/video and data applications over extended distances
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cambium Networks |
| Manufacturer Part Number | SFP-1G-LX |
| Brand Name | Cambium Networks |
| Product Name | SFP (mini-GBIC) Module |
| Product Type | SFP (mini-GBIC) |
| Technical Information | |
| Application/Usage | Data Networking,Optical Network |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Interfaces/Ports Details | 1 x 1000Base-LX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-LX |
| Miscellaneous | |
| Compatibility | Cambium Networks cnMatrix EX2000 Series Switches: EX2010 EX2016M-P EX2010-P EX2028-P EX2028 EX2052-P EX2052 EX2052R-P / CRPS |
FAQ
What is the maximum data transfer speed of this SFP module?
This Cambium Networks SFP-1G-LX module supports Gigabit Ethernet with a data transfer rate of up to 1000 Mbps using 1000Base-LX technology. It provides full-duplex operation, allowing simultaneous data transmission and reception at this speed over single-mode fiber optic cables.
What type of fiber optic cable does this module require?
The module requires single-mode fiber optic cable with LC duplex connectors. Single-mode fiber is designed for long-distance transmissions, typically supporting distances up to 10 kilometers, and uses a single wavelength of light (1310 nm) to minimize signal loss and maintain data integrity over extended reaches.
Which Cambium Networks switches are compatible with this SFP?
This SFP module is compatible with Cambium Networks cnMatrix EX2000 series switches, including models such as EX2010, EX2016M-P, EX2010-P, EX2028-P, EX2028, EX2052-P, EX2052, and EX2052R-P. It is pre-coded for these switches to ensure plug-and-play functionality without additional configuration.
Does this SFP module support digital diagnostics monitoring?
Yes, the SFP-1G-LX module includes digital diagnostics monitoring (DDM) capabilities. This allows network administrators to monitor real-time parameters like temperature, voltage, bias current, and optical power levels through compatible switch interfaces, aiding in proactive maintenance and troubleshooting.
