Cisco C9200CX-8P-2XGH-E Catalyst Compact Switch - 10 Ports - 8 PoE+ - 2x SFP+ - Layer 3240W PoE - Fanless
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch provides 10 total network ports, with a detailed breakdown of 8 Gigabit Ethernet PoE+ ports for connecting and powering devices like IP phones, wireless access points, and security cameras, plus 2 dedicated 10 Gigabit Ethernet ports and 2 additional Gigabit Ethernet ports for high-speed uplinks or aggregation. The integrated 2 SFP+ slots support fiber or copper transceivers for extended reach or backbone connections, offering flexibility in media type with support for both optical fiber and twisted pair.
Operating at Layer 3, the switch supports advanced routing protocols for scalable network design, enabling inter-VLAN routing and efficient traffic management. It is compliant with a comprehensive set of networking standards including IEEE 802.3af/at/bt for PoE, 802.1Q for VLANs, 802.3ad for link aggregation, and 802.1x for network access control, ensuring interoperability and security in mixed-vendor environments.
Key Product Advantages
The C9200CX-8P-2XGH-E combines high-density PoE, compact size, and enterprise-grade features to address common network challenges efficiently. Its fanless operation eliminates moving parts, reducing failure points and enabling silent deployment in noise-sensitive areas like classrooms or offices.
Substantial PoE+ Capacity
With 8 PoE+ ports and a 240W budget, this switch can power multiple PoE devices simultaneously, simplifying cabling and reducing the need for separate power adapters at edge locations.
- Supports IEEE 802.3af/at devices
- Ideal for VoIP phones, APs, cameras
- Centralized power management
Flexible Deployment Options
The compact, lightweight design supports rack mounting, wall mounting, or under-table installation, allowing it to fit into tight spaces while maintaining professional cable management.
- 1.73" height for dense racks
- Wall mount brackets optional
- Under-table mounting for discreet placement
High-Speed Uplink Readiness
Dual 10 Gigabit Ethernet ports and SFP+ slots provide ample bandwidth for uplinks to core switches or servers, preventing bottlenecks in growing networks.
- 10GBase-X and 10/100/1000Base-T support
- SFP+ for fiber or DAC connections
- Future-proofs network backbone
Deployment / Use Cases
This switch is engineered for scenarios requiring a blend of PoE, compact footprint, and Layer 3 capabilities. It serves as an ideal access layer switch in small to medium-sized business networks, branch offices, or retail environments where connecting and powering edge devices is a primary need.
In educational settings, it can support classrooms with IP phones, wireless access points, and interactive displays, leveraging its silent fanless design. For retail, it powers POS systems, security cameras, and digital signage while providing reliable connectivity for back-office operations. Its Layer 3 functionality also makes it suitable for smaller core or distribution roles in segmented networks, handling routing between VLANs for improved performance and security.
Physical Profile
The switch features a compact, durable chassis measuring 1.73 inches in height, 10.60 inches in width, and 9.60 inches in depth, with a weight of 6.60 pounds. This slim 1U profile maximizes rack space efficiency while the included mounting options support versatile placement. The fanless design not only reduces noise but also minimizes dust intake, contributing to long-term reliability in various environments.
- Width
- 10.60" (269.24 mm)
- Depth
- 9.60" (243.84 mm)
- Height
- 1.73" (43.94 mm)
- Weight
- 6.60 lb (2993.71 g)
Highlights
- 10 total network ports with 8 PoE+ ports for device power and connectivity
- 240W total PoE budget to support multiple powered devices simultaneously
- 2 SFP+ slots for high-speed fiber or copper uplink expansion
- Layer 3 routing capability for scalable network design and inter-VLAN routing
- Fanless, silent operation ideal for office or classroom environments
- Compact, 1U form factor with rack, wall, and under-table mounting options
- Supports 10 Gigabit Ethernet on dedicated ports for high-bandwidth uplinks
- Redundant power supply support for increased availability in critical deployments
- Comprehensive IEEE standards compliance for interoperability and security
- Managed via Cisco IOS for advanced configuration, monitoring, and troubleshooting
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | C9200CX8P2XGHE |
| Brand Name | Cisco |
| Product Line | Catalyst |
| Product Series | 9200 |
| Product Model | C9200CX-8P-2XGH |
| Product Name | Catalyst C9200CX-8P-2XGH Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Fanless |
| Interfaces/Ports | |
| Total Number of Network Ports | 10 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | No |
| Stack Port | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+,2 x 10 Gigabit Ethernet Network Port,2 x Gigabit Ethernet Network Port |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-X,10/100/1000Base-T |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 2 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.1ae,IEEE 802.3bz,IEEE 802.3an,IEEE 802.3bt,IEEE802.3af |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 240 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply,AC,PoE+,DC |
| Redundant Power Supply Supported | Yes |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Power Consumption | 315 W |
| Input Receptacles | IEC 60320 C14 |
| Physical Characteristics | |
| Form Factor | Rack-mountable,Wall Mountable,Under Table,Compact |
| Height | 1.73" (43.94 mm) |
| Width | 10.60" (269.24 mm) |
| Depth | 9.60" (243.84 mm) |
| Weight (Approximate) | 6.60 lb (2993.71 g) |
User Manual
FAQ
How many PoE+ ports does this switch have and what is the total PoE budget?
This Cisco Catalyst switch includes 8 Gigabit Ethernet ports that support PoE+ (IEEE 802.3at), delivering up to 30W per port. The total PoE budget is 240W, allowing it to power multiple devices such as IP phones, wireless access points, and security cameras simultaneously without requiring separate power adapters.
What types of uplink ports are available on this switch?
The switch provides two 10 Gigabit Ethernet ports and two additional Gigabit Ethernet ports dedicated for uplinks. It also includes two SFP+ slots that support fiber or direct-attach copper transceivers, offering flexible options for connecting to core switches, servers, or extending the network over longer distances.
Does this switch support Layer 3 routing and what are the benefits?
Yes, this is a Layer 3 managed switch. Layer 3 support enables advanced routing functions like inter-VLAN routing, static routing, and dynamic routing protocols. This allows for more scalable network designs, improved traffic segmentation, and reduced reliance on a core router for internal traffic, enhancing overall network performance and management.
Is the switch fanless and what are the advantages of this design?
Yes, this switch features a fanless design. The absence of fans eliminates noise, making it suitable for quiet environments like offices, libraries, or classrooms. It also reduces mechanical failure points, minimizes dust accumulation inside the chassis, and lowers maintenance requirements, contributing to higher reliability and longer operational life.
What are the physical dimensions and mounting options for this switch?
The switch measures 1.73 inches in height, 10.60 inches in width, and 9.60 inches in depth, with a weight of 6.60 pounds. It is designed for flexible installation, supporting standard 19-inch rack mounting (occupying 1U of space), wall mounting using optional brackets, or under-table mounting for discreet placement in space-constrained locations.
Can this switch support redundant power supplies for increased reliability?
Yes, the switch supports redundant power supplies. It comes with one power supply installed but has the capability to support a second power supply for redundancy. This feature allows for continuous operation in case one power supply fails, which is critical for maintaining network availability in business or enterprise environments.
