Cisco C1200-24P-4G-RF Catalyst 24-Port Gigabit PoE+ Managed Switch - Layer 3 - 4 SFP Slots - 195W PoE Budget - 1U Rack-Mountable - Refurbished
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates at Layer 3, supporting advanced routing protocols and VLAN management for segmented network traffic. It delivers Gigabit Ethernet speeds across all 24 RJ-45 ports, with backward compatibility for 10/100/1000Base-T and 1000Base-X fiber connections via the four SFP slots. The shared SFP slot architecture allows flexible uplink configuration using optical fiber for long-distance links or copper for short-haul connections.
Power over Ethernet is fully implemented with a 195W budget, enabling simultaneous power delivery to multiple PoE and PoE+ devices without external power injectors. The switch consumes 236.40W under typical load and accepts dual-voltage input (120V AC or 230V AC), providing deployment flexibility across different power infrastructures. A single internal power supply supports the unit, with comprehensive IEEE standards compliance ensuring interoperability in mixed-vendor networks.
This section brings together practical product details such as Features, Total Number of Network Ports, Network (RJ-45), Uplink Port, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Catalyst C1200-24P-4G delivers enterprise-grade features in a compact 1U footprint. Its fanless construction eliminates moving parts for increased reliability and silent operation, ideal for environments where noise is a concern. The switch supports a broad range of IEEE standards including 802.3af/at for PoE, 802.1Q for VLANs, and 802.3ad for link aggregation, ensuring compatibility with modern network equipment.
High-Density PoE+ Deployment
With 24 PoE+ ports and a 195W budget, this switch powers and connects numerous devices like VoIP phones, cameras, and access points from a single chassis, simplifying cabling and reducing power outlet requirements.
Layer 3 Managed Flexibility
Full Layer 3 capabilities enable advanced routing, QoS, and security features, allowing network administrators to optimize traffic flow, implement access controls, and create scalable network architectures.
Fiber-Ready Expansion
Four SFP slots support fiber optic modules for high-speed uplinks or backbone connections, extending network reach beyond copper limitations and providing future-proof scalability.
Deployment / Use Cases
This switch excels in small to medium business networks requiring both data connectivity and device power. Its 24 PoE+ ports make it perfect for office deployments where VoIP phone systems, wireless access points, and security cameras need centralized power and network access. The Layer 3 capabilities support inter-VLAN routing for segmented departments or guest networks, while the SFP slots enable fiber connections to servers or upstream switches in distributed campus environments.
Educational institutions can deploy these switches in classrooms or administrative areas to support digital learning tools and campus security systems. Retail environments benefit from the PoE capabilities for point-of-sale systems and inventory management devices, with the rack-mountable design keeping equipment organized in server rooms or network closets. The refurbished status with lifetime warranty provides a cost-effective solution for organizations extending their network infrastructure while maintaining enterprise-grade reliability.
Physical Profile
The switch measures 1.73" (43.94 mm) in height, 17.50" (444.50 mm) in width, and 11.77" (298.96 mm) in depth, fitting standard 19-inch rack cabinets with 1U of vertical space. Its 7.78 lb (3530 g) weight makes it manageable for installation in rack-mounted configurations. The front panel provides clear port labeling and status indicators, while the rear houses the power input and grounding point. The all-metal construction ensures durability in rack environments, with ventilation designed for passive cooling in the fanless design.
- Width
- 17.50" (444.50 mm)
- Depth
- 11.77" (298.96 mm)
- Height
- 1.73" (43.94 mm)
- Weight
- 7.78 lb (3530 g)
Highlights
- 24 Gigabit Ethernet PoE+ ports for connecting and powering network devices
- 195W total PoE budget supports multiple PoE+ devices simultaneously
- Four SFP slots for fiber optic or copper uplink expansion
- Layer 3 managed switching with advanced routing and security features
- Fanless design for silent operation and increased reliability
- 1U rack-mountable form factor fits standard server cabinets
- Supports optical fiber and twisted pair media for flexible connectivity
- Comprehensive IEEE standards compliance ensures network interoperability
- Dual-voltage input (120V AC/230V AC) for deployment flexibility
- Refurbished condition with lifetime limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | C1200-24P-4G-RF |
| Brand Name | Cisco |
| Product Line | Catalyst |
| Product Series | 1200 |
| Product Model | C1200-24P-4G |
| Product Name | Catalyst C1200-24P-4G Ethernet Switch |
| Product Condition | Refurbished |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Fanless |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet PoE+,4 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-X,10/100/1000Base-T |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Shared SFP Slot | Yes |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1x,IEEE 802.3az,IEEE 802.3ad,IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3x,IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.3af,IEEE 802.3at,IEEE 802.1p,IEEE 802.11ac,IEEE 802.1Q,IEEE 802.1ab |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 195 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply,AC |
| Number of Power Supplies Installed | 1 |
| Power Consumption | 236.40 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.73" (43.94 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 11.77" (298.96 mm) |
| Weight (Approximate) | 7.78 lb (3530 g) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
How many devices can this switch power with PoE?
The switch provides 195W of total PoE budget across its 24 PoE+ ports. This allows it to power multiple PoE and PoE+ devices simultaneously, such as VoIP phones, wireless access points, and security cameras. The exact number depends on each device's power requirements, but the generous budget supports typical office deployments without needing additional power injectors.
What is the difference between Layer 2 and Layer 3 switching on this model?
This switch operates at Layer 3, which means it can perform routing functions between different network segments or VLANs in addition to basic switching. Layer 3 capabilities include support for routing protocols, quality of service (QoS) policies, and advanced security features that go beyond the MAC address-based forwarding of Layer 2 switches. This makes it suitable for more complex network architectures requiring segmentation and traffic management.
Can I use fiber optic connections with this switch?
Yes, the switch includes four SFP (mini-GBIC) slots that support fiber optic transceivers. These slots allow you to connect to fiber optic cabling for uplinks to other switches or to span longer distances than copper Ethernet can support. The shared SFP architecture provides flexibility in configuring your uplink connections based on your network's specific distance and bandwidth requirements.
Is this switch suitable for rack mounting?
Absolutely. The switch is designed for 1U rack mounting with standard 19-inch rack compatibility. Its dimensions of 1.73" height, 17.50" width, and 11.77" depth fit perfectly in server cabinets, and it includes the necessary mounting hardware. The rack-mountable form factor helps organize cabling and saves space in network closets or data centers.
What does 'refurbished' mean for this Cisco switch?
Refurbished means the switch has been professionally tested, cleaned, and restored to full working condition. It undergoes quality checks to ensure all ports, PoE functionality, and management features operate correctly. The refurbished unit comes with a lifetime limited warranty, providing the same reliability as new equipment at a more accessible price point for budget-conscious deployments.
What networking standards does this switch support?
The switch supports comprehensive IEEE standards including 802.3af/at for PoE, 802.1Q for VLAN tagging, 802.3ad for link aggregation, 802.1x for network access control, and 802.3az for energy-efficient Ethernet. It also supports Gigabit Ethernet standards (802.3ab, 802.3z) and spanning tree protocols (802.1D, 802.1w) for network stability. This broad standards compliance ensures interoperability in diverse network environments.
What uplink, SFP, fiber, or media support detail is listed?
The warranty or support detail listed is Yes, giving buyers a clearer picture of expected coverage after purchase.
Does the product support PoE or wireless networking?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
