Cisco CS-KIT-EQ-4K-K9 Room Kit EQ PTZ 4K Video System - 80MP Camera - 4K UHD - 60 fps - Gigabit Ethernet - RoomOS - Large Room
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This video conferencing system leverages industry-standard protocols and encoding technologies to ensure interoperability and high performance. It supports ITU-T recommendations including H.460.18/19, H.239, H.323, SIP, H.235v3, and H.245, facilitating secure and reliable connections across diverse network environments.
Video encoding options include H.264, H.265, H.263, and H.264 AVC, allowing efficient bandwidth usage without compromising quality. Audio encoding spans G.711, G.722, G.729, G.722.1, AAC-LD, and Opus, ensuring compatibility with various audio systems and clear voice transmission.
Connectivity is comprehensive, with three HDMI inputs and outputs for flexible display management, six Gigabit Ethernet ports for network integration, and three USB 3.0 ports for peripheral expansion. Dual-stream capability supports simultaneous presentation and video feeds, enhancing meeting dynamics.
This section brings together practical product details such as ITU-T Recommendation, Features, Room Size, Camera Resolution, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Room Kit EQ PTZ 4K stands out with its high-resolution camera and advanced processing, designed to meet the demands of professional video conferencing. Its integration of audio and video technologies ensures participants experience clear, immersive interactions without technical distractions.
Superior Visual Clarity
The 80MP camera and 4K UHD resolution deliver sharp, detailed video, while the 60 fps frame rate eliminates motion blur and flickering, crucial for dynamic presentations and boardroom discussions.
Robust Audio Performance
Internal microphones and speakers, combined with echo cancellation and noise reduction, provide clear audio capture and playback, reducing background noise and enhancing speech intelligibility.
Flexible Deployment Options
Wall and ceiling mountable form factors allow for versatile installation in large rooms, optimizing camera angles and room aesthetics without compromising functionality.
Deployment / Use Cases
This system is ideal for organizations requiring reliable, high-quality video conferencing in formal and collaborative settings. Its large-room capacity and professional features make it suitable for enterprises, educational institutions, and government agencies.
In boardrooms, it facilitates executive meetings and client presentations with crisp video and audio. For training sessions or webinars, the dual-stream capability allows presenters to share content while maintaining video presence. In huddle rooms or conference halls, its mounting flexibility and connectivity support seamless integration with existing AV infrastructure.
This section brings together practical product details such as ITU-T Recommendation, Features, Room Size, Camera Resolution, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Corporate Boardrooms
Enhance decision-making with clear video and audio, supporting remote participation and document sharing across global teams.
Educational & Training Centers
Deliver engaging virtual lessons or workshops with high-resolution visuals and reliable connectivity, accommodating large audiences.
Physical Profile
The system features a compact design with dimensions of 18.60" width, 8" depth, and 1.70" height, weighing approximately 5.10 pounds. This slim profile facilitates discreet installation on walls or ceilings, minimizing visual intrusion in meeting spaces. The build includes a Kensington lock slot for security, protecting against unauthorized removal in shared environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.70" (43.18 mm), 18.60" (472.44 mm), 8" (203.20 mm), 5.10 lb (2313.32 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 18.60" (472.44 mm)
- Depth
- 8" (203.20 mm)
- Height
- 1.70" (43.18 mm)
- Weight
- 5.10 lb (2313.32 g)
What's in the Box
The package includes essential components for setup and operation, ensuring a complete out-of-the-box experience.
Highlights
- 80-megapixel CMOS camera for high-resolution video capture
- 4K UHD live video at 60 fps for smooth, flicker-free visuals
- Internal microphones and speakers with advanced audio processing
- Gigabit Ethernet and Wireless LAN for flexible connectivity
- Supports Microsoft Teams and Zoom for unified communications
- Wall and ceiling mountable design for versatile installation
- Includes Room Navigator for intuitive control
- Environmentally compliant with RoHS and WEEE standards
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | CS-KIT-EQ-4K-K9 |
| Brand Name | Cisco |
| Product Name | Room Kit EQ PTZ 4K |
| Product Type | Video Conference Equipment |
| Technical Information | |
| ITU-T Recommendation | H.460.18/19,H.239,H.323,SIP,H.235v3,H.245 |
| Features | Noise Reduction,Ultrasound Technology,Dual Stream,Kensington Lock,Echo Cancellation |
| Room Size | Large |
| Camera | |
| Camera Resolution | 80 Megapixel |
| Image Sensor Size | 1/1.7 |
| Image Sensor Type | CMOS |
| Video | |
| Graphics Modes (Live) | 4K UHD |
| Maximum Video Resolution (Live) | 3840 x 2160 |
| Maximum Frame Rate | 60 fps |
| Video Encoding | H.264,H.265,H.263,H.264 AVC |
| Audio | |
| Speaker Form Factor | Internal |
| Microphone Form Factor | Internal |
| Audio Encoding | G.711,G.722,G.729,G.722.1,AAC-LD,Opus |
| Network & Communication | |
| Network Technology | 10/100/1000Base-T |
| Ethernet Technology | Gigabit Ethernet |
| Wireless Specifications | |
| Wireless LAN | Yes |
| Interfaces/Ports | |
| HDMI In | Yes |
| HDMI Out | Yes |
| Audio Line In | Yes |
| Audio Line Out | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| Number of Network (RJ-45) Ports | 6 |
| Number of HDMI Inputs | 3 |
| Number of HDMI Outputs | 3 |
| Number of Audio Line In | 3 |
| Number of Audio Line Out | 1 |
| Number of USB 3.0 Ports | 3 |
| Operating System | |
| Operating System Supported | RoomOS,RoomOS 11.1.2 |
| Physical Characteristics | |
| Form Factor | Wall Mountable,Ceiling Mountable |
| Height | 1.70" (43.18 mm) |
| Width | 18.60" (472.44 mm) |
| Depth | 8" (203.20 mm) |
| Weight (Approximate) | 5.10 lb (2313.32 g) |
| Miscellaneous | |
| Package Contents | CodecEQ Quad Camera or Cisco PTZ 4K Camera Wall mount for Quad Camera Power adapter (for Quad Camera) Region power cord Selection of one Room Navigator table-stand or Room Navigator wall-mount control unit |
| Application/Usage | Video Conferencing,Boardroom,Presentation |
| Unified Communications Platform | Microsoft Teams,Zoom |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 90 Day |
User Manual
FAQ
What camera resolution does the Cisco Room Kit EQ PTZ 4K support?
The system features an 80-megapixel camera with a 1/1.7-inch CMOS sensor, delivering high-resolution imaging suitable for detailed video in large room environments. This resolution ensures clear visuals even when zoomed or displayed on large screens.
What video quality and frame rate can I expect from this system?
It supports 4K UHD video at a maximum resolution of 3840 x 2160 and a frame rate of 60 frames per second. This combination provides sharp, smooth video without flickering, ideal for dynamic presentations and boardroom meetings.
How does the audio system perform in this video conferencing setup?
Audio is handled by internal microphones and speakers, with encoding for G.711, G.722, G.729, G.722.1, AAC-LD, and Opus. Features like noise reduction and echo cancellation enhance clarity, ensuring participants hear and are heard without background interference.
What connectivity options are available on the Room Kit EQ PTZ 4K?
Connectivity includes three HDMI inputs and outputs, six Gigabit Ethernet ports, three USB 3.0 ports, and audio line in/out ports. It also supports Wireless LAN, offering flexible integration with displays, networks, and peripherals for comprehensive meeting setups.
Which unified communications platforms is this system compatible with?
It is compatible with Microsoft Teams and Zoom, running on RoomOS for stable performance. This allows seamless integration into existing collaboration workflows, supporting video calls, screen sharing, and team meetings across these popular platforms.
What are the mounting options for installation in a large room?
The system is designed for wall or ceiling mounting, with a compact form factor that facilitates discreet placement. This flexibility helps optimize camera angles and room layout, making it adaptable to various large-room configurations like boardrooms or conference halls.
What camera resolution or video format is listed?
It features a display specification of 80 Megapixel, giving you clear visuals for work and media use.
What field of view or room-coverage detail is listed?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
