Cisco CS-BRD75P-NR-K9-RF Webex Board Pro 75 - 75" 4K UHD Video Collaboration Display - SIP - H. 323 - Gigabit Ethernet - Wall/Floor Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the Webex Board Pro 75 is a 3840 × 2160 4K UHD display capable of rendering content and video at up to 30 frames per second. The CMOS image sensor captures high-quality video, while internal microphones and speakers handle audio capture and playback without external components. Video encoding supports H.264, H.265, and H.263 standards, with audio encoding covering G.711, G.722, G.722.1, G.729, AAC-LD, and Opus for broad compatibility.
Network connectivity is built around Gigabit Ethernet (10/100/1000Base-T) with wireless LAN available as a secondary option. The board includes one HDMI input and one HDMI output for external source connectivity, plus audio line out, USB, and a single RJ-45 network port. ITU-T recommendations include SIP, H.323, H.460.18/19, and H.264 for enterprise-grade interoperability.
This section brings together practical product details such as ITU-T Recommendation, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Webex Board Pro 75 consolidates multiple collaboration technologies into a unified, professionally integrated system that reduces cable clutter and simplifies IT management. With native Webex optimization and standards-based interoperability, it serves as both a dedicated Webex room device and a compatible endpoint for broader video conferencing ecosystems.
All-in-One Design
Integrates display, camera, microphones, and speakers in one unit for streamlined deployment and consistent performance.
- Eliminates peripheral compatibility issues
- Reduces installation time and complexity
- Provides unified warranty and support
Enterprise-Grade Connectivity
Wired Gigabit Ethernet ensures stable, high-bandwidth connections for video, while wireless LAN offers deployment flexibility.
- Supports bandwidth-intensive 4K video
- Maintains connection quality in crowded RF environments
- Offers fallback connectivity options
Flexible Mounting
Wall and floor mounting options allow installation in various room configurations, from dedicated conference rooms to flexible huddle spaces.
- Adapts to existing room furniture and layouts
- Professional installation options available
- Secure mounting for high-traffic areas
Deployment / Use Cases
The Webex Board Pro 75 is engineered for medium to large meeting rooms where video collaboration is a daily requirement. Its 75-inch display provides clear visibility for in-room participants, while the integrated audio/video components ensure remote attendees experience high-quality interactions. The board functions effectively as the central collaboration hub for team meetings, executive briefings, and cross-location project coordination.
Ideal deployment scenarios include corporate conference rooms, training facilities, boardrooms, and distance learning classrooms. The non-radio configuration makes it particularly suitable for secure government, financial, or healthcare environments where wireless restrictions apply. When paired with Webex Room devices or other SIP/H.323 endpoints, it enables seamless multi-point video conferences with consistent user experience across locations.
Corporate Conference Rooms
Serves as the primary collaboration display for scheduled meetings, supporting both Webex-native and third-party video systems.
Training & Education Spaces
Delivers clear content sharing and remote participant engagement for instructor-led sessions and virtual classrooms.
Physical Profile
The board features a professional-grade enclosure measuring 67.70 inches wide by 43.40 inches high with a slim 3.70-inch depth profile. At approximately 158.73 pounds, it requires appropriate structural support for wall mounting or use with compatible floor stands. The design accommodates both permanent wall installations in dedicated rooms and flexible floor-mounted deployments in multi-purpose spaces. Environmental compliance includes WEEE and RoHS directives, reflecting Cisco's commitment to sustainable manufacturing practices.
- Width
- 67.70" (1719.58 mm)
- Depth
- 3.70" (93.98 mm)
- Height
- 43.40" (1102.36 mm)
- Weight
- 158.73 lb (71998.72 g)
Highlights
- 75-inch 4K UHD display with 3840 × 2160 resolution for crisp content and video
- Integrated CMOS camera, internal microphones, and speakers in one unified device
- Supports SIP, H.323, H.460.18/19, and H.264 video conferencing standards
- Gigabit Ethernet (10/100/1000Base-T) with wireless LAN connectivity option
- Wall mountable and floor mountable for flexible room installation
- Video encoding: H.264, H.265, H.263; Audio encoding: G.711, G.722, G.722.1, G.729, AAC-LD, Opus
- Includes HDMI input and output, audio line out, USB, and RJ-45 network port
- Environmental compliance with WEEE and RoHS directives
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | CS-BRD75P-NR-K9-RF |
| Brand Name | Cisco |
| Product Line | Webex Board Pro |
| Product Model | 75 |
| Product Name | Webex Board Pro 75 - Non Radio |
| Product Condition | Refurbished |
| Product Type | Video Conference Equipment |
| Technical Information | |
| ITU-T Recommendation | SIP,H.323,H.460.18/19,H.264 |
| Camera | |
| Image Sensor Type | CMOS |
| Video | |
| Graphics Modes (Content) | 4K UHD |
| Maximum Video Resolution (Content) | 3840 x 2160 |
| Maximum Frame Rate | 30 fps |
| Video Encoding | H.264,H.265,H.263 |
| Audio | |
| Speaker Form Factor | Internal |
| Microphone Form Factor | Internal |
| Audio Encoding | G.711,G.722,G.722.1,G.729,AAC-LD,Opus |
| Network & Communication | |
| Network Technology | 10/100/1000Base-T |
| Ethernet Technology | Gigabit Ethernet |
| Wireless Specifications | |
| Wireless LAN | Yes |
| Interfaces/Ports | |
| HDMI In | Yes |
| HDMI Out | Yes |
| Audio Line Out | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| Physical Characteristics | |
| Form Factor | Wall Mountable,Floor Mountable |
| Height | 43.40" (1102.36 mm) |
| Width | 67.70" (1719.58 mm) |
| Depth | 3.70" (93.98 mm) |
| Weight (Approximate) | 158.73 lb (71998.72 g) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
What video conferencing protocols does the Webex Board Pro 75 support?
The board supports industry-standard protocols including SIP and H.323 for interoperability with most enterprise video systems, plus H.460.18/19 for firewall traversal and H.264 for video compression. This ensures compatibility with Cisco Webex, other collaboration platforms, and standards-based video conferencing infrastructure.
Does this model include built-in audio components?
Yes, the Webex Board Pro 75 integrates internal microphones and speakers, eliminating the need for external audio peripherals in typical meeting scenarios. The audio system supports multiple encoding standards including G.711, G.722, G.722.1, G.729, AAC-LD, and Opus for high-quality voice transmission.
What mounting options are available for this collaboration board?
The board is designed for both wall mounting and floor mounting, providing flexibility for different room configurations. Wall mounting creates a permanent installation in dedicated conference rooms, while floor mounting with compatible stands allows for repositioning in multi-purpose spaces or rooms without suitable wall surfaces.
What network connectivity options does the board provide?
Primary connectivity is through Gigabit Ethernet (10/100/1000Base-T) via a single RJ-45 port, ensuring stable, high-bandwidth wired connections for 4K video. The board also includes wireless LAN capability for environments where wired connections are impractical or as a secondary connectivity option.
What is the display resolution and refresh capability?
The 75-inch display delivers 3840 × 2160 4K UHD resolution for sharp content and video presentation. It supports a maximum frame rate of 30 frames per second, providing smooth motion for video conferencing and content sharing without motion blur artifacts.
What video inputs and outputs are available on the board?
The board includes one HDMI input for connecting external video sources such as laptops or media players, and one HDMI output for extending the display to additional monitors or recording devices. This allows flexible presentation options while maintaining the integrated collaboration experience.
What camera resolution or video format is listed?
It features a display specification of 3840 x 2160, giving you clear visuals for work and media use.
What field of view or room-coverage detail is listed?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
