CradlePoint RX30-PoE Managed Accessory - 8 Ports - Manageable - Gigabit Ethernet - 1000Base-T - 2 Layer Supported - 23 W Power - 60 W (MB-RX30-POE)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Total Number of Network Ports: 8
Network (RJ-45): Yes
Port/Expansion Slot Details: 4 x Gigabit Ethernet PoE,4 x Gigabit Ethernet Network
Media Type Supported: Twisted Pair
Ethernet Technology: Gigabit Ethernet
Network Technology: 1000Base-T
Layer Supported: 2
Networking Standards: IEEE 802.3bt
Manageable: Yes
PoE (RJ-45) Port: Yes
PoE Budget: 60 W
Input Voltage: 9 V DC,36 V DC
Power Source: PoE
Power Consumption: 23 W
Height: 1.18" (30 mm)
Width: 5.98" (152 mm)
Depth: 6.81" (173 mm)
Weight (Approximate): 1.85 lb (840 g)
- Expand your network capacity with the help of 8 networking ports and transfer your data quickly and easily
- No need for power lines and outlets, the switch is capable of obtaining power from the PoE source
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Managed switch provides a reliable foundation for your network
- Gigabit Ethernet port for ultra-fast network speeds
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
[custom-specifications]
| Specifications | |
| Manufacturer | ERICSSON |
| Manufacturer Part Number | MB-RX30-POE |
| Manufacturer Website Address | http://www.ericsson.com |
| Brand Name | CradlePoint |
| Product Series | RX30 |
| Product Model | RX30-POE |
| Product Name | RX30-PoE Managed Accessory |
| Packaged Quantity | 1 |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet PoE,4 x Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3bt |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 60 W |
| Input Voltage | 9 V DC,36 V DC |
| Power Source | PoE |
| Power Consumption | 23 W |
| Physical Characteristics | |
| Height | 1.18" (30 mm) |
| Width | 5.98" (152 mm) |
| Depth | 6.81" (173 mm) |
| Weight (Approximate) | 1.85 lb (840 g) |
[/custom-specifications]
[custom-options]
| Product | CradlePoint Power Supply - External - 12 V DC Output - 1 +12V Rails |
| SKU | 170870-000 |
| Sale Price | $145.95 |
| Product | CradlePoint Data/Power Cord - For Switch - 18 Gauge - 9.8 ft (3 m) Cord Length - Molex / Bare Wire |
| SKU | 170858-000 |
| Sale Price | $49.95 |
| Product | CradlePoint GPIO & Power Cable, 2×3, 3 meters, 18AWG - 10 ft (3.05 m) Data Transfer/Power Cable for PoE Switch, Dock - 18 AWG - Black |
| SKU | 170872-000 |
| Sale Price | $49.95 |
[/custom-options]
[custom-user-manual]
Available Documentation:
Additional-pdf1
[/custom-user-manual]
| Qty | Price | Available |
|---|
