CyberPower PDU20BT6F8R Basic 14-Outlet Vertical Rack PDU - NEMA L5-20P to 5-20R - 120V AC - 1U Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This PDU operates at 120V AC input and output, compatible with standard North American power systems. The NEMA L5-20P plug connects to a 20-amp circuit, delivering consistent power through 14 NEMA 5-20R receptacles.
The vertical mounting orientation optimizes rack space, while the 1U height minimizes footprint in standard server racks. The design includes a cord retention tray to manage cables neatly, reducing clutter and improving airflow.
Relevant factors for this section include PDU Type, Plug/Connector Type, Receptacle Type, Input Voltage. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
This PDU offers straightforward power distribution with essential protection features, making it a cost-effective solution for organized rack environments.
High-Density Outlet Layout
With 14 receptacles arranged front and rear, this PDU maximizes connectivity in limited rack space, supporting multiple devices without external power strips.
- 6 front outlets
- 8 rear outlets
- Reduces cable clutter
Robust Construction
The industrial-grade metal housing withstands physical stress and heat, ensuring long-term reliability in server rooms and data centers.
- Metal housing
- Durable design
- Suitable for high-demand use
Environmental Compliance
This PDU meets RoHS standards, restricting hazardous substances for safer disposal and environmental responsibility.
- RoHS compliant
- Environmentally friendly
- Reduces toxic waste
Deployment / Use Cases
This PDU is ideal for vertical rack installations where space efficiency and reliable power distribution are priorities. It suits environments requiring multiple power connections in a compact form factor.
Common applications include data center server racks, network equipment cabinets, and telecommunications installations. The split front/rear receptacle design allows flexible device placement, catering to both accessible and hard-to-reach equipment.
Relevant factors for this section include PDU Type, Plug/Connector Type, Receptacle Type, Input Voltage. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Data Center Racks
Deploy in standard 19-inch server racks to power servers, switches, and storage devices, leveraging the vertical orientation for optimized cable management.
Network Closets
Use in smaller network rooms to consolidate power for routers, modems, and patch panels, ensuring clean and organized power delivery.
Physical Profile
The PDU measures 1.75 inches in height, 17.50 inches in width, and 2.25 inches in depth, fitting neatly into 1U rack spaces. Its vertical design and lightweight construction at 4.60 pounds facilitate easy installation and adjustment in rack environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1U, 17.50" (444.50 mm), 2.25" (57.15 mm), 4.60 lb (2086.52 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.50" (444.50 mm)
- Depth
- 2.25" (57.15 mm)
- Height
- 1U
- Weight
- 4.60 lb (2086.52 g)
What's in the Box
The package includes the PDU unit and a cord retention tray for secure cable management.
Package contents include Basic PDU20BT6F8R 14-Outlets PDU Cord Retention Tray, Basic PDU20BT6F8R 14-Outlets PDU. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Basic PDU with 14 NEMA 5-20R output receptacles (6 front, 8 rear)
- 120V AC input and output voltage for standard North American power
- Vertical mounting orientation and 1U rack height for space-efficient installation
- Overload protection to safeguard connected equipment
- Rugged industrial-grade metal housing for durability
- NEMA L5-20P plug type for 20-amp circuit compatibility
- Includes cord retention tray for organized cable management
- RoHS compliant and environmentally friendly
- Lifetime limited warranty for long-term reliability
- Lightweight design at 4.60 pounds for easy handling
Specifications
| Specifications | |
|---|---|
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | PDU20BT6F8R |
| Brand Name | CyberPower |
| Product Model | PDU20BT6F8R |
| Product Name | Basic PDU20BT6F8R 14-Outlets PDU |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Basic |
| Plug/Connector Type | NEMA L5-20P |
| Receptacle Type | NEMA 5-20R |
| Receptacle Detail | 14 x NEMA 5-20R |
| Protection Type | Overload Protection |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Physical Characteristics | |
| Mounting Orientation | Vertical |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Height | 1.75" (44.45 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 2.25" (57.15 mm) |
| Weight (Approximate) | 4.60 lb (2086.52 g) |
| Miscellaneous | |
| Package Contents | Basic PDU20BT6F8R 14-Outlets PDU Cord Retention Tray |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the input voltage of this PDU?
The CyberPower PDU20BT6F8R operates at 120V AC input voltage, compatible with standard North American electrical systems. This ensures it can connect directly to typical wall outlets or power sources in data centers and server rooms without requiring voltage conversion.
How many outlets does this PDU have and how are they arranged?
This PDU features 14 NEMA 5-20R outlets, with 6 located on the front and 8 on the rear. This split configuration allows flexible device placement, making it easier to power both accessible and hard-to-reach equipment in rack environments while minimizing cable clutter.
Is this PDU rack-mountable and what are its dimensions?
Yes, this PDU is designed for vertical rack mounting with a 1U height. Its dimensions are 1.75 inches in height, 17.50 inches in width, and 2.25 inches in depth, fitting standard 19-inch server racks. The compact size optimizes space usage in data centers and network closets.
Does this PDU include any protection features?
This PDU includes overload protection to safeguard connected devices from electrical surges and excessive current. This feature helps prevent damage to sensitive equipment like servers and networking gear, ensuring stable operation in critical IT environments.
What type of plug does this PDU use?
The PDU uses a NEMA L5-20P plug, which is designed for 20-amp circuits. This plug type is common in commercial and data center settings, providing a secure connection to power sources that support higher amperage for demanding equipment loads.
What warranty comes with this PDU?
CyberPower provides a lifetime limited warranty for this PDU, covering defects in materials and workmanship. This warranty offers long-term assurance for reliability, making it a dependable choice for continuous use in business and IT infrastructure applications.
