CyberPower OL1500RTXL2U Smart App Online UPS - 1500VA/1350W Double-Conversion - 2U Rack/Tower - Sine Wave - 8 NEMA Outlets - LCD
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The CyberPower OL1500RTXL2U Smart App Online UPS is a professional-grade double-conversion uninterruptible power supply engineered for mission-critical equipment protection. This 1500VA/1350W unit delivers pure sine wave output with zero transfer time, ensuring clean, stable power for sensitive electronics during utility power fluctuations or outages. Its true online topology continuously converts incoming AC to DC and back to AC, providing complete isolation from voltage sags, surges, frequency variations, and harmonic distortion.
Designed for both rack-mount and tower deployment, this 2U form factor UPS features comprehensive remote management capabilities through USB, serial, and network interfaces. The integrated LCD display provides real-time status monitoring of power conditions, battery health, and load levels. The included PowerPanel Business Edition software enables advanced power management, automated shutdown procedures, and detailed reporting across connected systems, making it suitable for IT environments requiring reliable power protection and centralized control.
Technical Overview
Double-Conversion Topology
Utilizes true online double-conversion technology that continuously converts incoming AC power to DC and then back to clean AC output. This provides complete isolation from utility power issues including voltage fluctuations, frequency variations, and harmonic distortion, ensuring consistent power quality for connected equipment.
- 0 ns transfer time
- Pure sine wave output
- Input power factor: 0.99
- Output power factor: 0.9
Power Conditioning and Protection
Delivers advanced power protection with EMI/RFI noise filtering, surge protection rated at 1780 joules, and short circuit protection. The ECO Mode achieves greater than 95% efficiency during normal operation to reduce energy consumption while maintaining protection.
- Surge energy rating: 1780 J
- EMI/RFI noise filter: Yes
- Overload protection: Yes
- Crest factor: 3:1
Battery System and Runtime
Equipped with three sealed lead-acid batteries providing reliable backup power. The system supports hot-swappable battery replacement for continuous operation during maintenance, with typical recharge time of 4 hours after complete discharge.
- 3 x 12V batteries
- 9000 mAh capacity
- Replaceable battery: Yes
- Full load runtime: 4 minutes
- Half load runtime: 12.5 minutes
Key Product Advantages
This Smart App Online UPS combines enterprise-grade power protection with flexible deployment options and comprehensive management capabilities. The double-conversion topology ensures maximum equipment protection, while the configurable output voltage and extensive connectivity options make it suitable for diverse IT environments.
Comprehensive Outlet Configuration
Features eight NEMA 5-15R outlets to support multiple connected devices. The 10-foot NEMA 5-15P power cord provides flexible placement options within rack or tower installations.
- 8 x NEMA 5-15R outlets
- NEMA 5-15P plug type
- 10 ft (3048 mm) cord length
Advanced Battery System
Equipped with three sealed lead-acid batteries providing reliable backup power. The system supports hot-swappable battery replacement for continuous operation during maintenance.
- 3 x 12V batteries
- 9000 mAh capacity
- Replaceable battery: Yes
Deployment / Use Cases
The OL1500RTXL2U is engineered for environments requiring reliable power protection for critical equipment. Its dual rack/tower configuration makes it suitable for data centers, server rooms, network closets, and office environments where both form factors may be required.
This UPS is particularly effective for protecting servers, network equipment, telecommunications systems, and other mission-critical devices that demand clean, uninterrupted power. The generator compatibility and wide input voltage range make it suitable for locations with unstable utility power or frequent voltage fluctuations.
Data Center Applications
Ideal for protecting rack-mounted servers, switches, and storage systems in standard 19-inch racks. The 2U height maximizes rack space efficiency while providing substantial power capacity.
- 2U rack height
- 17" width for standard racks
- Remote management capabilities
Office & Commercial Environments
Suitable for tower deployment in server rooms or network closets where rack mounting isn't available. The comprehensive outlet configuration supports multiple workstations or network devices.
- Tower deployment option
- 8 NEMA outlets
- LCD for easy monitoring
Physical Profile
Designed with installation flexibility in mind, this UPS measures 3.5" (88.9 mm) in height, 17" (431.8 mm) in width, and 16.9" (429.26 mm) in depth. The 2U rack height allows efficient use of standard 19-inch rack space, while the tower configuration provides standalone deployment options. Weighing approximately 39.6 lb (17.96 kg), the unit includes mounting hardware for secure rack installation.
- Width
- 17" (431.80 mm)
- Depth
- 16.90" (429.26 mm)
- Height
- 2U
- Weight
- 55 dB(A)
- Length
- 10 ft (3048 mm)
What's in the Box
The package includes all necessary components for immediate deployment and management of the UPS system.
Highlights
- 1500VA/1350W double-conversion online UPS with pure sine wave output
- 2U rack/tower form factor with black finish for professional installations
- Eight NEMA 5-15R outlets with 10-foot NEMA 5-15P power cord
- Zero transfer time and configurable output voltage (100-125V AC)
- Comprehensive remote management via USB, serial, and network interfaces
- LCD display with real-time status monitoring and alarm indicators
- Three sealed lead-acid batteries with replaceable design
- Includes PowerPanel Business Edition software for advanced management
- Data line protection for telephone and network connections
- 3-year limited warranty with Energy Star certification
Specifications
| Specifications | |
|---|---|
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | OL1500RTXL2U |
| Brand Name | CyberPower |
| Product Series | Smart App Online UPS |
| Product Model | OL1500RTXL2U |
| Product Name | OL1500RTXL2U Smart App Online UPS Systems |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 8 x NEMA 5-15R |
| Transfer Time | 0 ns |
| Dataline Protection | RJ-11,RJ-45 |
| Protection Type | Short Circuit |
| Overload Protection | Yes |
| EMI/RFI Noise Filter | Yes |
| Energy Saving | ECO Mode Efficiency >95% |
| Application/Usage | Mission Critical Equipment,Generator |
| Cord Length | 10 ft (3048 mm) |
| Circuit Breaker Current Rating | 15 A |
| Crest Factor | 3:1 |
| Power Description | |
| Load Capacity (VA) | 1.50 kVA |
| Load Capacity (Watt) | 1.35 kW |
| Input Voltage | 120 V AC |
| Input Voltage Range | 60 V AC - 69 V AC,100 V AC - 125 V AC |
| Output Voltage | 100 V AC,110 V AC,115 V AC,120 V AC,125 V AC |
| Input Frequency | 40 Hz,70 Hz |
| Output Frequency | 50 Hz,60 Hz |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 1780 J |
| Input Power Factor | 0.99 |
| Output Power Factor | 0.9 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | Dry Contact,Relay Card,SNMP/HTTP Remote Monitoring |
| Alarm | Battery Mode,Low Battery,Overload,UPS Fault |
| Controls/Indicators | |
| Status Indicators | Power On Line Mode Battery Mode Bypass Mode Fault Replace Battery |
| Interfaces/Ports | |
| Serial Port | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| USB (HID Compliant) Port | Yes |
| EPO Port | Yes |
| Battery Information | |
| Number of Batteries | 3 |
| Battery Characteristics | Sealed |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 9000 mAh |
| Backup/Run Time (Full Load) | 4 Minute |
| Backup/Run Time (Half Load) | 12.50 Minute |
| Typical Battery Recharge Time | 4 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | -4°F (-20°C) - 113°F (45°C) |
| Maximum Operating Elevation | 10000 ft (3048000 mm) |
| Maximum Storage Elevation | 50000 ft (15240000 mm) |
| Operating Humidity | 0% - 90% |
| Storage Relative Humidity | 0% - 95% |
| Sound Emission (A-Weighted) | 55 dB(A) |
| Thermal Dissipation | 478 BTU/h |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| Height | 3.50" (88.90 mm) |
| Width | 17" (431.80 mm) |
| Depth | 16.90" (429.26 mm) |
| Weight (Approximate) | 39.60 lb (17962.26 g) |
| Miscellaneous | |
| Package Contents | Smart App Online OL1500RTXL2U 1500VA 100-125V Sine Wave LCD Rack/Tower UPS PowerPanel Business Edition Software CD User Manual USB Cable Serial Cable Phone Cable Mounting Hardware Registration Card |
| Software Included | PowerPanel® Business |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What processor does this product use?
CyberPower OL1500RTXL2U Smart App Online UPS Systems - 1500VA/1350W, 100 - 125 VAC, NEMA 5-15P, 2U, Rack / Tower, Sine Wave, 8 LCD, (OL1500RTXL2U) is positioned around the processor configuration shown in the , giving buyers a clearer view of expected performance for business workloads and everyday deployment needs.
How much memory is installed?
The installed memory configuration for CyberPower OL1500RTXL2U Smart App Online UPS Systems - 1500VA/1350W, 100 - 125 VAC, NEMA 5-15P, 2U, Rack / Tower, Sine Wave, 8 LCD, (OL1500RTXL2U) should be reviewed alongside your workload needs, especially if you are planning multitasking, heavier applications, or longer lifecycle deployment use.
What storage is included?
The system includes -4°F (-20°C) - 113°F (45°C) of storage for applications, files, and everyday business data.
What display size or resolution is listed?
Display-related specifications help position CyberPower OL1500RTXL2U Smart App Online UPS Systems - 1500VA/1350W, 100 - 125 VAC, NEMA 5-15P, 2U, Rack / Tower, Sine Wave, 8 LCD, (OL1500RTXL2U) for the kind of viewing experience, readability, and workspace fit buyers may expect in business it/ups & power backup/general & industrial ups deployments.
What connectivity options are available?
Connectivity details help confirm how CyberPower OL1500RTXL2U Smart App Online UPS Systems - 1500VA/1350W, 100 - 125 VAC, NEMA 5-15P, 2U, Rack / Tower, Sine Wave, 8 LCD, (OL1500RTXL2U) can integrate with your network, accessories, and surrounding peripherals before rollout or replacement planning.
What operating system or platform is included?
CyberPower OL1500RTXL2U Smart App Online UPS Systems - 1500VA/1350W, 100 - 125 VAC, NEMA 5-15P, 2U, Rack / Tower, Sine Wave, 8 LCD, (OL1500RTXL2U) is described for practical deployment use, and the specification set helps buyers confirm fit, compatibility, and expected day-to-day operation.
