CyberPower OL6KRT Smart App Online UPS - 6000VA/5400W Double-Conversion - 6U Rack/Tower - Sine Wave - 4 NEMA Outlets - 3-Year Warranty
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The CyberPower OL6KRT Smart App Online UPS is a double-conversion online uninterruptible power supply engineered for critical IT infrastructure protection. With a robust 6000VA/5400W capacity, this unit delivers pure sine wave output and zero transfer time, ensuring seamless power continuity for servers, networking equipment, and data center environments. The double-conversion topology provides complete isolation from input power anomalies, making it ideal for applications where power quality and reliability are non-negotiable.
Designed for flexible deployment, the OL6KRT features a convertible 6U form factor that supports both standard 19-inch rack mounting and standalone tower configurations. The system includes comprehensive management capabilities through an LCD display, USB, serial, and Ethernet connectivity, along with 20 sealed lead-acid batteries that provide reliable backup power. User-configurable output voltage settings from 200V to 240V allow adaptation to various international power standards and equipment requirements, while the included NEMA L6-30P input plug on a 10-foot cord ensures practical installation in diverse environments.
This UPS incorporates advanced protection features including overload protection, EMI/RFI noise filtering, and dataline surge protection for network and telephone lines. The energy-saving ECO Mode achieves up to 96% efficiency, reducing operational costs while maintaining performance. With its black chassis and front-accessible controls, the OL6KRT combines enterprise-grade functionality with practical design for IT managers overseeing server rooms, network closets, and data center operations.
Technical Overview
Power Architecture
Double-conversion online topology provides complete isolation from input power anomalies with 0 ns transfer time and sine wave output for sensitive equipment compatibility. The system maintains a 0.99 input power factor and 0.9 output power factor, with a 3:1 crest factor supporting demanding loads.
- Input Voltage: 120 V AC, 230 V AC
- Output Voltage: 198-292 V AC, user-configurable
- Waveform Type: Pure Sine Wave
Battery System
Twenty 12V sealed lead-acid batteries with 7000 mAh capacity deliver 5.4 minutes at full load and 15 minutes at half load, with replaceable design for extended service life. Smart Battery Management and Fast Charge Technology optimize performance and longevity.
- Replaceable Battery: Yes
- Typical Recharge Time: 4 Hours
- Battery Chemistry: Lead Acid
Protection & Management
Multiple protection layers safeguard connected equipment including backfeed and short circuit protection, EMI/RFI filtering, and dataline surge protection for RJ-11 and RJ-45 connections. Comprehensive monitoring through PowerPanel Business Edition software provides complete visibility into power status.
- Surge Energy Rating: 2430 J
- Circuit Breaker: 30 A
- Network Management: Dry Contact
Key Product Advantages
The OL6KRT combines enterprise-grade power protection with flexible deployment options, offering IT managers reliable backup power for critical systems. The double-conversion technology ensures clean, stable power regardless of input conditions, while the comprehensive monitoring and management capabilities provide complete visibility into power status and battery health.
Management & Monitoring
PowerPanel Business Edition software enables remote monitoring and management, with RMCARD205 pre-installed for network connectivity and optional environmental sensor support.
- LCD Display for Local Status
- Dry Contact Alarm for Battery Mode
- EPO Port for Emergency Shutdown
Protection Features
Multiple protection layers safeguard connected equipment including overload protection, EMI/RFI filtering, and dataline surge protection for network and telephone lines.
- Backfeed and Short Circuit Protection
- Energy Saving ECO Mode
- Connected Equipment Guarantee
Deployment / Use Cases
Designed for demanding IT environments, the OL6KRT is ideal for server rooms, network closets, and data centers where power quality and reliability are critical. The rack/tower convertible design allows flexible installation in standard 19-inch racks or as a standalone tower unit.
This UPS supports generator compatibility and is suitable for applications requiring extended runtime through external battery packs. The configurable output voltage makes it adaptable to various international power standards and equipment requirements.
Server Room Protection
Provides clean, uninterrupted power for rack-mounted servers, storage arrays, and networking equipment with 4 NEMA outlets (2x L6-20R, 2x L6-30R) for flexible equipment connection.
Network Infrastructure
Protects switches, routers, and communication equipment with dataline surge protection for RJ-11 and RJ-45 connections, ensuring network continuity during power events.
Physical Profile
The black 6U chassis measures 10.5" height, 17" width, and 26" depth with a substantial 222.2 lb weight that ensures stability in both rack and tower configurations. The unit includes rack mounting hardware for standard 19-inch rack installation and features front-accessible controls and displays for easy monitoring.
- Width
- 17" (431.80 mm)
- Depth
- 26" (660.40 mm)
- Height
- 6U
- Weight
- 65 dB(A)
- Length
- 10 ft (3048 mm)
What's in the Box
The package includes all necessary components for immediate deployment of the UPS system.
Highlights
- 6000VA/5400W double-conversion online UPS
- Pure sine wave output with 0 ns transfer time
- 6U rack/tower convertible form factor
- 4 NEMA outlets (2x L6-20R, 2x L6-30R)
- 15 minutes runtime at half load, 5.4 minutes at full load
- LCD display with comprehensive status indicators
- USB, serial, Ethernet, and EPO connectivity
- PowerPanel Business Edition management software
- 20 sealed lead-acid batteries, user-replaceable
- 3-year limited warranty with equipment protection
Specifications
| Specifications | |
|---|---|
| Manufacturer | CyberPower Systems, Inc |
| Manufacturer Part Number | OL6KRT |
| Brand Name | CyberPower |
| Product Series | Smart App Online UPS |
| Product Model | OL6KRT |
| Product Name | OL6KRT Smart App Online UPS Systems |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | NEMA L6-20R,NEMA L6-30R |
| Receptacle Detail | 2 x NEMA L6-20R,2 x NEMA L6-30R |
| Transfer Time | 0 ns |
| Dataline Protection | RJ-11,RJ-45 |
| Protection Type | Backfeed,Short Circuit |
| Overload Protection | Yes |
| EMI/RFI Noise Filter | Yes |
| Energy Saving | ECO Mode Efficiency up to 96% |
| Application/Usage | IT Infrastructure,Network,Server Room,Generator |
| Cord Length | 10 ft (3048 mm) |
| Circuit Breaker Current Rating | 30 A |
| Crest Factor | 3:1 |
| Power Description | |
| Load Capacity (VA) | 6 kVA |
| Load Capacity (Watt) | 5.40 kW |
| Input Voltage | 120 V AC,230 V AC |
| Input Voltage Range | 120 V AC - 139 V AC |
| Output Voltage | 198 V AC,292 V AC,200 V AC,208 V AC,220 V AC,230 V AC,240 V AC |
| Input Frequency | 40 Hz,70 Hz |
| Output Frequency | 49.75 Hz,50.25 Hz |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 2430 J |
| Input Power Factor | 0.99 |
| Output Power Factor | 0.9 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | Dry Contact |
| Alarm | Battery Mode |
| Controls/Indicators | |
| Status Indicators | LED Indicators: Power On (White) |
| Interfaces/Ports | |
| Serial Port | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| USB (HID Compliant) Port | Yes |
| EPO Port | Yes |
| Battery Information | |
| Number of Batteries | 20 |
| Battery Characteristics | Sealed |
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 7000 mAh |
| Backup/Run Time (Full Load) | 5.40 Minute |
| Backup/Run Time (Half Load) | 15 Minute |
| Typical Battery Recharge Time | 4 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | -4°F (-20°C) - 113°F (45°C) |
| Maximum Operating Elevation | 10000 ft (3048000 mm) |
| Maximum Storage Elevation | 50000 ft (15240000 mm) |
| Storage Relative Humidity | 0% - 95% |
| Sound Emission (A-Weighted) | 65 dB(A) |
| Thermal Dissipation | 1912 BTU/h |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Rack/Tower |
| Rack Height | 6U |
| Height | 10.50" (266.70 mm) |
| Width | 17" (431.80 mm) |
| Depth | 26" (660.40 mm) |
| Weight (Approximate) | 222.20 lb (100788.22 g) |
| Miscellaneous | |
| Package Contents | Smart App Online OL6KRT 6000VA Tower/Rack Mountable UPS Rack Mounting Hardware USB Cable Serial Cable Phone Cable |
| Energy Star | No |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of the CyberPower OL6KRT UPS?
The CyberPower OL6KRT delivers 6000VA/5400W of double-conversion online power protection. This capacity supports critical IT infrastructure like servers, networking equipment, and data center environments, providing clean sine wave output with zero transfer time for seamless power continuity.
What runtime can I expect from this UPS at different loads?
At full load (5400W), the UPS provides 5.4 minutes of backup runtime. At half load (2700W), runtime extends to 15 minutes. These figures are based on the internal battery system of twenty 12V sealed lead-acid batteries with 7000 mAh capacity, supporting typical server room and network closet requirements.
How many outlets does the OL6KRT have and what types are they?
The UPS includes four NEMA outlets: two NEMA L6-20R and two NEMA L6-30R receptacles. This configuration allows flexible connection of equipment with different plug types, supporting both 20-amp and 30-amp devices commonly found in server racks and data center environments.
What input and output voltage ranges does this UPS support?
The OL6KRT accepts input voltages of 120V AC and 230V AC, with an adjustable range of 120-139V AC. Output voltage is user-configurable between 198-292V AC, specifically supporting 200V, 208V, 220V, 230V, and 240V outputs at ±2% accuracy for compatibility with various international power standards and equipment requirements.
Can this UPS be installed in both rack and tower configurations?
Yes, the OL6KRT features a convertible rack/tower form factor. As a 6U rack-mountable unit, it fits standard 19-inch server racks using the included mounting hardware. Alternatively, it can operate as a standalone tower for environments without rack infrastructure, providing deployment flexibility for different IT environments.
What management and connectivity options are available for monitoring and control?
The UPS offers comprehensive management through an LCD display, USB, serial, and Ethernet ports, plus an EPO (Emergency Power Off) port and dry contact alarm. PowerPanel Business Edition software enables remote monitoring and configuration, while the pre-installed RMCARD205 network card supports network connectivity for complete power status visibility and battery health monitoring.
